Introduction:
CODE3 XTP series LED heads are compact and versatile high intensity
directional LED warning lights suitable for mounting anywhere on a vehicle.
Colorless until illuminated, these discrete LED heads feature a high degree of
environmental and vibration protection.
Additional benefits include low current draw, a long and maintenance free
service life with reliable solid-state operation. LED heads can be controlled
by conventional switches or relays and can also be synchronized to flash with
other compatible CODE3 synchronizing LED products.
IMPORTANT! Read all instructions before installing and using. Installer: This manual must be delivered to the end user.
WARNING!
Failure to install or use this product according to manufacturers recommendations may result in property damage, serious injury, and/or
death to those you are seeking to protect!
Do not install and/or operate this safety product unless you have read and understand the safety information contained in
this manual.
1. Proper installation combined with operator training in the use, care, and maintenance of emergency warning devices are essential to
ensure the safety of emergency personnel and the public.
2. Emergency warning devices often require high electrical voltages and/or currents. Exercise caution when working with live electrical
connections.
3. This product must be properly grounded. Inadequate grounding and/or shorting of electrical connections can cause high current arcing,
which can cause personal injury and/or severe vehicle damage, including fire.
4. Proper placement and installation is vital to the performance of this warning device. Install this product so that output performance of the
system is maximized and the controls are placed within convenient reach of the operator so that s/he can operate the system without losing
eye contact with the roadway.
5. It is the responsibility of the vehicle operator to ensure daily that all features of this product work correctly. In use, the vehicle operator
should ensure the projection of the warning signal is not blocked by vehicle components (i.e., open trunks or compartment doors), people,
vehicles or other obstructions.
6. The use of this or any other warning device does not ensure all drivers can or will observe or react to an emergency warning signal. Never
take the right-of-way for granted. It is your responsibility to be sure you can proceed safely before entering an intersection, drive against
traffic, respond at a high rate of speed, or walk on or around traffic lanes.
7. This equipment is intended for use by authorized personnel only. The user is responsible for understanding and obeying all laws regarding
emergency warning devices. Therefore, the user should check all applicable city, state, and federal laws and regulations. The manufacturer
assumes no liability for any loss resulting from the use of this warning device.
Contents:
Specifications.........01
Installation and Mounting.........02
Wiring Instructions.........02
Programming Flash Patterns.........03
Troubleshooting.........04
Replacement Parts and Accessories.........04
Warranty.........04
Operation Environment:
Ambient Temperature: -40 to 70°C(-40 to 177°F)
Specifications:
Light Head Model
Input Voltage
Work Current
Physical H x W x L
Weight
Available Dual
Amb/Wht, Blue/Amb, Blue/Wht, Red/Amb,
Colors
920-0534-00 Rev. D
XTP4-Dual Stack MC
12-24VDC
1.0A Max @ DC12V or 24V
0.62 in x 2.39 in x 4.72 in
1.58 cm x 6.07 cm x 11.98 cm
0.210 lb (0.10 Kg)
Red/Blue, Red/Wht
Installation and Operation Instructions
XTP SERIES LIGHT HEADS
Dual Stack Multi Colors
Package Contains:
1
Light Head
2
Screws
1
Installation Guide
1
Mounting Gasket
1
Bezel
Page 1 of 4
