Technical Reference
020-103050-01
MicroTiles LED
Serial Commands

Advertisement

Table of Contents
loading

Related Manuals for Christie MicroTiles LED

Summary of Contents for Christie MicroTiles LED

  • Page 1 Technical Reference 020-103050-01 MicroTiles LED Serial Commands...
  • Page 2 The warranty does not apply to any product where the serial number has been removed or obliterated. The warranty also does not apply to any product sold by a reseller to an end user outside of the country where the reseller is located unless (i) Christie has an office in the country where the end user is located or (ii) the required international warranty fee has been paid.

  • Page 3: Table Of Contents

    Content Communicating with MicroTiles LED........4 Connection and use.

  • Page 4: Communicating With Microtiles Led

    Refer to the User Manual provided with the product for all cable requirements and other connection details. Understanding message format Commands sent to and from MicroTiles LED are formatted as simple text messages consisting of a three letter command code, an optional four letter subcode, and optional data. Available message types...

  • Page 5: Basic Message Structure

    (PWR!000). Data The value for a given MicroTiles LED state, such as on or off, appears in ASCII- decimal format directly after the request/reply symbol. You can add an optional space after the symbol—such as before the data—in a set message, but data in replies follow the exclamation mark (!) symbol without a space.

  • Page 6: Special Characters For Text

    The acknowledgment is returned after the message has been received and fully executed by MicroTiles LED (such as in the case of a source switch it is not sent until the switch is complete). If the message cannot be executed for some reason (such as invalid parameters, time-out, and so on) a NAK is returned instead (not-acknowledge).

  • Page 7: Error Messages

    = C4h when only the low byte is used = 128 MicroTiles LED collects all of the message bytes as defined in the first byte of the message, then creates its own checksum value for comparison with the checksum included in the controller’s message.

  • Page 8: Product Documentation

    System busy - Try again later Product documentation For installation, setup, and user information, see the product documentation available on the Christie website. Read all instructions before using or servicing this product. 1. Access the documentation from the Christie website: •...

  • Page 9: Serial Api Commands

    Serial API commands The MicroTiles LED commands can be used to modify product settings. BRI–Array Brightness Sets the brightness of the array, from 0 to 100% of the array capacity. Commands Command Description Values BRI <value> Changes the array brightness.

  • Page 10: Gam-Gamma Power Value

    Returns the current count of Wall Controllers in the system. Commands Command Description Values LWC+CURR Returns the current count of Wall Controllers — in the system. (Read-only) MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 11: Oct-Octroller Count

    1 = Turns the array on Examples Get the power status of the array: (PWR+WALL ?) Power on the array: (PWR+WALL 1) MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 12: Sin-Select Input

    SDI Inputs 2, in addition to the options above, the list of available options also include: 4 = SDI Input 1 MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 13 Set the main video on an E1100 to SDI Input 3: (SIN+MAIN 6) Set the E1100 redundant port to SDI Input 4: (SIN+RDNT 4) MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 14: Sst-Status

    (SST+TEMP!020 000 "28 °C" "Environmental Board Temperature") ... Return item 4 of the temperature group: (SST+TEMP?4) Result: SST+TEMP!004 000 "67 BOC" "Main Control Board Temperature" MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 15: Szp-Resize Presets

    0. Examples Display the number of tiles in the currently powered on array: (TIL+CURR) MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...

  • Page 16: Tmd-Time And Date

    Serial API commands TMD–Time and Date Sets the display time and date for all devices in the MicroTiles LED array. Commands Command Description Values TMD+DATE <date> Sets the date for the clock. <date> = String in the following format: YYYY/MM/DD TMD+TIME <time>...

  • Page 17: Uid-User Id

    Set the left coordinate of the signal, in pixels, to 0. (WDM+LFTE 0) Set the height of the video output signal to 1080 pixels. (WDM+HGHT 1080) MicroTiles LED Technical Reference–Serial Commands 020-103050-01 Rev. 1 (10-2019) Copyright 2019 Christie Digital Systems USA, Inc. All rights reserved. ©...
  • Page 18 Corporate offi ces Worldwide offi ces Christie Digital Systems USA, Inc. Africa United Kingdom Columbia Korea (Seoul) ph: 714 236 8610 ph: +27 (0)11 510 0094 ph: +44 (0) 118 977 8000 ph: +57 (318) 447 3179 ph: +82 2 702 1601 Christie Digital Systems Canada Inc.
