The LED wall controller acts as the main system controller and coordinates with all connected tiles to form a canvas. Christie MicroTiles LED tiles are designed to occupy a smaller more manageable install footprint with minimal mechanical and electronics components. The simplicity of the design ensures higher reliability and improved thermal management.
• System Settings—Upgrades the firmware and exports system logs. • Status—Identifies the areas of the array triggering errors or warnings. • Multi-Wall Control—Sends messages to selected MicroTiles LED walls in its list at once for a subset of functions. Device list—Lists all LED wall controllers, Octrollers, and LED tiles in the array.
Do not use chemicals or water to clean the surface of the display. Christie recommends only using dry filtered compressed air to remove loose particles between the LEDs. Additional instructions on how to clean the MicroTiles LED modules can be found in the Maintaining the array (on page 29) section.
Follow these guidelines for optimal daily use to make sure optimal performance of the MicroTiles LED. • MicroTiles LED modules should be powered on and operated daily for a minimum of four hours each day. • When turning on the MicroTiles LED modules, Christie recommends setting brightness levels to a maximum of 80% for the first five minutes.
Page 12
Place a fresh desiccant pack inside each bag. • Do not unpack or remove MicroTiles LED modules from their factory sealed bags until needed. If modules are stored prior to installation, they should remain in their packaging. MicroTiles LED User Guide 020-102835-09 Rev.
Configuring the array Configure the MicroTiles LED array through the web user interface. Operating the LCD front panel Some basic settings can be changed from the LCD front panel (IP address, SNMP settings) all other controls are available in the web user interface.
4. To disable Stealth Mode, clear the Stealth Mode checkbox. Accessing the MicroTiles LED web user interface Learn how to access the web user interface. The MicroTiles LED web user interface is supported on the following browsers: ™ • Google Chrome ®...
Use the generated password to access the web user interface. Displaying content on the array Learn the different methods of configuring the input for a MicroTiles LED array. Selecting the input Configure the input for an array with one or more LED wall controllers.
Resetting all tiles to use the primary wall controller (on page 17) Generating an EDID Configure MicroTiles LED to accept the video source in the preferred signal formats. 1. Log into the MicroTiles LED web user interface (web UI). 2. Select Input Selection.
MicroTiles LED modules are equipped with neighbor detection, which automatically determines the location of each module within the canvas and the overall configuration of the canvas. Christie recommends automatically mapping the tiles in the array after the chassis are installed, and after the LED modules are installed on the chassis.
MicroTiles LED uses a frame sequential single input that supports signals up to 1080P. Signals with higher resolution than 1080P, uses a dual-input configuration for displaying 3D content, where two video streams are provided by the video server, with the left eye supplied by one stream and the right eye supplied by the other.
2. Using an appropriate length of QSFP cable, connect the cables from the LED wall controller to the first Octroller. Various lengths of this cable assembly are available from Christie. 3. Connect a QSFP+DAC cable between each Octroller in the array.
Various lengths of CAT 6 unshielded, UTP, 24 AWG pre-terminated cables are available from Christie. Alternatively, a custom length of Ethernet cable can be created using the Christie Cat 6 cable spool (P/N: 161-120104-XX), RJ45 Connect kit (P/N: 161-122106-XX) and Ethernet crimping tool (P/N: 11-121105-XX).
Understand the procedures for performing maintenance on the MicroTiles LED array. Checking the current software version Verify the version of the software running on the MicroTiles LED array. 1. Select System Settings. 2. In the Software area, review the current version and the date of the last update.
Run on version 1.4.0 or higher • Connected to the primary controller The multi-wall control list is only set to one MicroTiles LED wall's web user interface. The list does not replicate to each connected wall's web user interface. Adding a wall Use the web user interface of an existing wall to act as the controller for multiple walls.
10. Select Reboot. 11. In the Reboot dialog, select OK. 12. Log into the MicroTiles LED web user interface containing the Multi-Wall Control wall list. Christie recommends clearing the browser cache after performing a firmware upgrade and before running the new software on the array.
Learn the information and procedures for troubleshooting issues with the MicroTiles LED array. Viewing the status of the entire array To assist with diagnostics, use the status interface to view status information about the Christie MicroTiles LED. 1. Select Status or select the colored bar in the top right corner.
