Aventics ISO-New Generation Series Repair Instruction

AVENTICS GmbH
Ulmer Straße 4
30880 Laatzen
Phone +49 (0) 5 11-21 36-949
Fax: +49 (0) 511-21 36-505
www.aventics.com
spareparts@aventics.com
Further addresses:
www.aventics.com/contact
The data specified above only serve to
describe the product. No statements
concerning a certain condition or suitability
for a certain application can be derived from
our information. The given information does
not release the user from the obligation of
own judgement and verification. It must be
remembered that our products are subject
to a natural process of wear and aging.
An example configuration is depicted on the
title page. The delivered product may thus
vary from that in the illustration.
Translation of the original operating
instructions. The original operating
instructions were created in the German
language.
R961403362–RAW–001–AC/10.2014
Subject to modifications. © All rights
reserved by AVENTICS GmbH, even and
especially in cases of proprietary rights
applications. It may not be reproduced or
given to third parties without its consent.
1
Reparaturanleitung | Repair instruction
Ersatzteilsatz ISO New Generation
Spare kit ISO New Generation
Leichtläufer / Low Friction Version
Serie ISO-New Generation
R961403362-RAW-001-AC/10.2014,
Replaces: 01.10.2014, DE/EN
Durchmesser / Ersatzteilsatz /
Diameter Spare part kit
Ø 32 R412012554-TRB
R413000122-PRA
Ø 40 R412012558-TRB
R413000123-PRA
Ø 50 R412012562-TRB
R413000124-PRA
Ø 63 R412012566-TRB
R413000125-PRA
Ø 80 R412012570-TRB
R413000126-PRA
Ø 100 R412012574-TRB
R413000127-PRA
Ø 125 R412012578-TRB
R413000128-PRA
Stückliste /
Bill of Material
Tabelle 1 / Table 1
Tabelle 1 / Table 1
Tabelle 1 / Table 1
Tabelle 1 / Table 1
Tabelle 1 / Table 1
Tabelle 1 / Table 1
Tabelle 1 / Table 1
AVENTICS | Serie ISO-New Generation | 10.2014 1
