3.0
SPECIFICATIONS
On-state voltage range
Maximum off-state voltaje
Maximum operation frequency
Typical signal delay
Maximum output voltage
Typical output current
Maximum off-state voltaje
Maximum operation frequency
Typical signal delay
Time of transition to high impedance state
*Time passed since a low in the ENABLE input is detected and the outputs are disabled
4.0
BOARD DESCRIPTION
User's Manual
DIGITAL INPUT SPECIFICATIONS
DIGITAL OUTPUT SPECIFICATIONS
2 to 5V DC
0.8V
4 MHz
10nS
(5V power supply voltage) +
0.5V
24mA
0.44 V
4 MHz
10 nS
12 nS*
Page 2
