1.0

FEATURES

• 34 Inputs and Outputs on 2 ports.
• Full access to all the pins of the Smooth Stepper Board.
• Connects directly to the Smooth Stepper (from Warp9).
The board is provided with sockets that allow the Smooth Stepper Board to be
plugged directly into this board. No ribbon cables required. When using the
Smooth Stepper board there is no need to use an additional power supply to power
the board. It will draw power from the Smooth Stepper board.
• Built-in Passive Low Pass Filters for the all inputs.
This board includes low pass filters to reduce the effect of the noise from the drivers
or other devices over the inputs signals.
• All TTL 5VDC signals.
Interface directly with parallel port interface products and other CNC4PC cards.
5VDC (TTL) cards are very common among automation devices.
• Input and output pins with close by ground connections.
Forget about grounding problems. Easily connect your pin by using your close by
ground connection. No need to be an electronics expert to ground all your stuff.
• Push-lock connections for all terminals.
You only have to push-lock the wires to make all your connections.
2.0

SPECIFICATIONS

On-state voltage range
Maximum off-state voltage
Number of outputs
Maximum output voltage
Maximum off-state voltage
User's Manual
DIGITAL INPUT SPECIFICATIONS
Numbers of inputs
Type
DIGITAL OUTPUT SPECIFICATIONS
5 on Port1, 13 on Port2
3.5 to 5V DC
Aprox. 1.5V
Active High
12 on Port1, 4 on port2
(5V power supply voltage) +0.5V
0.33 V
Page 1
