Water supply requires a flowing pressure of at least 20 psi, but no greater than 80 psi.
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
Hardware supplied by installer must be appropriate for wall construction. Wall anchors used must have a
minimum pull-out rating of 1,000 lbs.
Read this entire installation manual to ensure proper installation. When finished with the installation, file this
manual with the owner or maintenance department.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
Product warranties may be found under "Products" on our website at www.bradleycorp.com.
215-1539 Rev. K; ECO 19-00-022
© 2019 Bradley
Page 1 of 12
7/10/2019
Installation
MF2944 TouchTime
Terreon
with TouchTime
(Standard*, Juvenile and OBC Height)
* Standard Height is ADA/TAS Compliant

Table of Contents

Supplies Required by Installer . . . . . . . . . . . . . . . . . . . . . 2
Pre-Installation Information . . . . . . . . . . . . . . . . . . . . . . . 2
Rough-Ins . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Assemble Pedestal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Install Pedestal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Install Solenoid Assembly . . . . . . . . . . . . . . . . . . . . . . . . 6
Assemble and Install Bowl . . . . . . . . . . . . . . . . . . . . . . . 7
Electrical and Supply Connections . . . . . . . . . . . . . . . . . 8
Adjusting the TouchTime Module . . . . . . . . . . . . . . . . . . 8
Check Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Install Top Cover and Front Panel . . . . . . . . . . . . . . . . . 9
Brand Names . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Troubleshooting - Valve . . . . . . . . . . . . . . . . . . . . . . . . 11
WARNING
IMPORTANT
Quadra-Fount
®
®
®
P.O. Box 309
Menomonee Falls, WI 53052 USA
800 BRADLEY (800 272 3539)
+1 262 251 6000
bradleycorp.com
®
Washfountain
. . . . . . . . . . . . . . 3
®
. . . . . . . . . . . . 10
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Terreon Quadra-Fount TouchTime MF2944 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bradley Terreon Quadra-Fount TouchTime MF2944

Summary of Contents for Bradley Terreon Quadra-Fount TouchTime MF2944

  • Page 1: Table Of Contents

    Product warranties may be found under "Products" on our website at www.bradleycorp.com. P.O. Box 309 215-1539 Rev. K; ECO 19-00-022 Menomonee Falls, WI 53052 USA 800 BRADLEY (800 272 3539) © 2019 Bradley +1 262 251 6000 Page 1 of 12 7/10/2019 bradleycorp.com...

  • Page 2: Supplies Required By Installer

    • Pipe sealant and plumber’s putty • 110 VAC power source for 120VAC/12V DC plug in adapter supplied • OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit . This feature prevents accidental water delivery during regular maintenance and service .

  • Page 3: Parts Included With The Quadra-Fount

    Parts included with the Quadra-Fount ® Separate all parts from packaging materials and ensure you have all the parts required for assembly . If any parts are missing, do not attempt to assemble the Bradley Terreon Quadra-Fount Washfountain until you obtain all parts .

  • Page 4: Rough-Ins

    Install the upper and lower brackets to the pedestal panels with two pan RIGHT PEDESTAL head 1/4"- 20 x 1/2" screws and PANEL 5/16" I .D washers supplied . LOWER CENTERLINE OF BRACKET FIXTURE Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 5: Install Pedestal

    ASSEMBLY (supplied by installer) for 3/8" bolts . After floor anchors are installed, secure the pedestal assembly to the floor anchors using two 3/8" bolts and washers (supplied by installer) . Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 6: Install Solenoid Assembly

    For optional single tempered supply: attach the stop to the 1/2" tempered supply line . Connect Cold Supply the stop to the solenoid valve assembly with the Inlet flexible supply hose . Stop Cables not shown for clarity. Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 7: Assemble And Install Bowl

    Install strainer in the bowl drain using the two #10-24 x 1/2" flat socket head screws supplied . Connect the drain trap (supplied by installer) to the drain spud and drain line . Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 8: Electrical And Supply Connections

    (4 through 9 for either one or both) Selector Switch no flush, A though F for 24 hours flush) as indicated on the module label . Power Connection Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 9: Check Operation

    To install front panel, slip slot in bottom of front pedestal panel over the lip on the lower bracket . SCREW Secure panel to upper bracket with attached screw . FRONT PANEL LOWER BRACKET Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 10: Cleaning And Maintenance For Terreon

    . For complete instructions on this additional maintenance, visit bradleycorp .com . Repair Kits: Terreon repair kits are available . Contact your Bradley representative or distributor for part numbers and pricing . Repair kits are made to order and have a shelf life of 30 days .

  • Page 11: Troubleshooting - Valve

    • reconnect to the adjacent valve and turn on the water supplies to the unit; • activate the pushbutton/piezo switch . If the station still fails to turn on, replace the pushbutton/piezo switch assembly . Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...

  • Page 12: Thermostatic Mixing Valve Troubleshooting

    198-014 Check Valve* 132-051 Retaining Ring* 118-319 Valve Body 146-079 U-Clip * Included with Prepack S65-326 Tempered Line Adapter Option Part no. S39-804 (replaces S59-4000 if tempered line is used) Strainer (173-028) Bradley • 215-1539 Rev. K; ECO 19-00-022 7/10/2019...
