Bradley Terreon Multi-Fount Series Installation Instructions Manual

Wall-hung washfountain with adaptive infrared control
Hide thumbs

Advertisement

Quick Links

Download this manual
IMPORTANT
Read through this installation manual to
ensure proper installation.
Make sure that water supply is completely
off before installation is begun.
When drilling into tile, masonry, or other
hard materials to install wall and floor
anchors, be sure to wear safety goggles
to prevent eye injuries.
Wall anchors used must have a minimum
pull-out rating of 1,000 lbs.
The Quadra-Fount™ requires a water
flowing pressure of at least 20 psi but no
greater than 100 psi.
File these instructions with the owner or
maintenance department.
215-1249 Rev. H; EN 03-045
© 2003 Bradley Corporation
Page 1 of 13
9-15-2003
Installation
Instructions
Bradley Multi-Fount™ Series
MF2949/IR
®
Terreon
Quadra-Fount
Wall-Hung Washfountain
with Adaptive Infrared
Control
(Standard* & Juvenile Height)
*ADA compliant when mounted at recommended
heights

Table of Contents

Pre-Installation Information . . . . . . . . . . . . . . . . . . . .2
Washfountain Component Parts . . . . . . . . . . . . . . . . .3
Installation Instructions . . . . . . . . . . . . . . . . . . . . .4-10
Cleaning Instructions . . . . . . . . . . . . . . . . . . . . . .11-12
Solenoid Valve Troubleshooting . . . . . . . . . . . . . . .13
P.O. Box 309, Menomonee Falls, WI 53052-0309
TEL. 1-800-BRADLEY
http://www.bradleycorp.com
™
FAX 262-251-5817

Advertisement

loading
Need help?

Need help?

Do you have a question about the Terreon Multi-Fount Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Bradley Terreon Multi-Fount Series

Summary of Contents for Bradley Terreon Multi-Fount Series

  • Page 1: Table Of Contents

    20 psi but no greater than 100 psi. File these instructions with the owner or maintenance department. P.O. Box 309, Menomonee Falls, WI 53052-0309 215-1249 Rev. H; EN 03-045 TEL. 1-800-BRADLEY FAX 262-251-5817 © 2003 Bradley Corporation http://www.bradleycorp.com Page 1 of 13 9-15-2003...

  • Page 2: Pre-Installation Information

    1. This warranty is limited to replacing or repairing, at our option, transportation charges prepaid by the purchaser, any Bradley unit or part thereof which our inspection shall show to have been defective within the limitations of this warranty.

  • Page 3: Washfountain Component Parts

    • Pipe sealant and plumber’s putty • 110 VAC power source for 110/24 VAC plug-in transformer supplied • OPTIONAL: Bradley recommends installing an electrical cut-off switch to the unit. This feature prevents accidental water delivery during regular maintenance and service.

  • Page 4: Installation Instructions

    (591) 25-1/2" Outline of 2-1/4" (648) 18-3/4" Wall Frame (57) (476) 4-1/4" (108) 8-1/2" (216) Finished Floor Finished Floor * Subtract 4" from this dimension for juvenile height model. Figure 1 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 5 Filter Washer Stop/Check Valve Flexible Hose Mounting Stud and 1/4" Nut Pipe Clamp Vernatherm Assembl Braided Hose Figure 2 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 6 Left Pedestal notches in the frame assembly. 3. Tighten the screws to secure the Right Pedestal pedestal panels to the frame assembly. Figure 4 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 7 Figure 6 Drain Assembly #10-24 x 1/2" Dome Screw for Strainer Strainer Drain Spud Washfountain Bowl Spud Discard this Washer washer; it is not used on Spud washfountains. Locknut Figure 5 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 8 4. Connect the flexible hose from the thermostatic mixing valve to the supply inlet on the left side of solenoid valve assembly. IMPORTANT: Verify that power to your Quadra-Fount™ is 24 VAC! 4-Solenoid Wire Harness Supply Inlet Transformer Plug Solenoid Tube Connector 4-Solenoid Wire Harness Plug Figure 7 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 9 3. Inside the pedestal assembly of the washfountain (use front access), slide the anchor plate onto the threaded rods and secure anchor plate against bowl using the wing nuts provided. Figure 8 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...
  • Page 10 3. Secure the access panel to the top of the pedestal frame using the self-retaining screw. 4. Tighten the screw to secure the bottom of the access panel in place. Figure 9 Pedestal Frame Self Retaining Screw Acess Panel #10-32 x 3/8" Bracket Slot Screw 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...

  • Page 11: Cleaning Instructions

    ® Solid Surface cleaner and polish to refresh and protect the Terreon Solid Surface material.Bradley recommends additional care and maintenance for the darker colored Terreon, for complete instructions on this additional maintenance see Bradley document #1505. IMPORTANT: DO NOT USE STRONG ACID OR ALKALINE CHEMICALS AND CLEANSERS TO CLEAN TERREON.
  • Page 12 It is emphasized that all products should be used in strict accordance with package instructions. 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...

  • Page 13: Solenoid Valve Troubleshooting

    • reconnect to the adjacent valve and turn on electrical and water supplies to the unit; • pass your hand in front of the sensor. If the station still fails to turn on, replace the sensor. 9-15-2003 Bradley Corporation • 215-1249 Rev. H; EN 03-045...

This manual is also suitable for:

Terreon quadra-fount mf2949/ir
