ASSEMBLY INSTRUCTION FOR MAXI ULTRA H2
When attaching unit to wall put safety bracket in
middle of unit with 16mm pan head screw then
25mm pan head screw into wall. For plasterboard
without a stud it is recommended to use a plug with
screw (not provided).
1x CAM SHELF
2x FIXED SHELF
1x 30mm HANGING RAIL
NO MODEL
DESCRIPTION
1
CONFIRMAT SCREWS 50mm x 5mm
2
WHITE CAPS
3
DOWELS
4
BACKING NAILS
5
16mm WOOD SCREW
TOP of UNIT
PARTS IDENTIFICATION LIST
. . . . . .
. . . . . .
1 BOTTOM KICK
1x .......BACKING
1x .......BACKING
QTY
NO
MODEL
15
6
15
7
4
8
60
9
2
10
. . . . . .
. . . . . .
DESCRIPTION
CAMS
CAM PINS
16mm PAN HEAD SCREWS
25mm PAN HEAD SCREWS
"L" SAFETY BRACKET
QTY
4
4
1
4
1
1
Advertisement
Related Manuals for Multistore MAXI ULTRA H2
Summary of Contents for Multistore MAXI ULTRA H2
- Page 1 ASSEMBLY INSTRUCTION FOR MAXI ULTRA H2 TOP of UNIT When attaching unit to wall put safety bracket in middle of unit with 16mm pan head screw then 25mm pan head screw into wall. For plasterboard without a stud it is recommended to use a plug with screw (not provided).
- Page 2 Take your gables and lay them out flat you should have 2 Top & 2 Bottom gables. Using a little of wood glue (NOT SUPPLIED) in your pre-drilled PLACE YOUR RUNNERS INTO THE holes, insert your Wood Dowels into 2 of the holes and push DESIGNATED HOLES MAKING SURE YOU your top into your bottom gables.
- Page 3 HOW TO ASSEMBLE YOUR DRAWER STEP 1. LAYOUT YOUR DRAWER PIECES FLAT AS PER DESIGN WITH PRE-DRILLED HOLES FACING UP. START WITH THE BACK OF THE FRONT DRAWER AND PLACE YOUR DOWELS & CAM PIN IN THE PRE-DRILLED HOLES ON EITHER SIDE AS INSTRUCTED BELOW. STEP 2.
- Page 4 10 Year Warranty • If the purchaser has a fault or defect with this product, the purchaser needs to contact Multistore Industries (Aust) directly on (07) 3208 6799 and state date of purchase, place of purchase and proof of purchase.
