- Page 1 Assembly InstructIons mAXI uLtrA-H1 CLASSIC RANGE HAngIng rAIL Jumbo DrAWer PACK 1495H x 608W x 430D WHITE #2669937 LIgHT Oak #2683483 Dark COCO #2683521...
- Page 2 ASSEMBLY INSTRUCTION FOR MAXI ULTRA H1 TOP of UNIT When attaching unit to wall put safety bracket in middle of unit with 16mm pan head screw then 25mm pan head screw into wall. For plasterboard without a stud it is recommended to use a plug with screw (not provided).
- Page 3 TAKE YOUR GABLES AND LAY THEM OUT RAIL SUPPORT FLAT, YOU SHOULD HAVE QTY 2 GABLES CAM SHELF HOLE 8 KICK BRACKETS L&R . NEXT STEP REQUIRES YOU TO OPEN PART 2 AND RETREVE THE INFILL & SCREWS. NEXT STEP: USING 30mm 8 GAUGE SCREWS PROVIDED, ATTACH THE INFILL TO THE FRONT UNDER-SIDE OF THE CAM SHELF BEFORE PUTTING YOUR SHELF INTO PLACE.
- Page 4 1 x DRAWER ASSEMBLY INSTRUCTION MODEL DESCRIPTION NO MODEL DESCRIPTION CONFIRMAT SCREWS CAMS DOWELS CAM PINS BACKING NAILS 30mm 8 GAUGE SCREW 5/8 X 6 WOOD SCREWS 6 EURO SCREWS INFILL HANDLE RUNNERS PER SET STEP 1. LAYOUT YOUR DRAWER PIECES FLAT AS PER DESIGN WITH PRE- DRILLED HOLES FACING UP.
- Page 5 DRAWER USING THE WOOD SCREWS PROVIDED (No:4) SCREW TWO INTO EACH RUNNER . REPEAT FOR THE OTHER SIDE PICTURE OF YOUR FINISHED DRAWER Multistore Industries (Aust) Pty Ltd 9 Nevilles Street, Underwood, QLD 4119 Tel—(07) 3208 6799 Fax- (07) 3209 6332 www.multistore.com.au...
- Page 6 INSTRUCTIONS FOR RUNNER PLACEMENT DIAGRAM 1 Executive Series ● ● Models Hole Positions Fixed Shelf Position ● ● EXC – 4J 1 – 8 – 15 - 22 ● ● EXC – 5C 1 – 8 – 15 – 20 – 25 ●...
- Page 7 Storage units for any room multistore.com.au multistore Industries (Aust) Pty Ltd 9 nevilles Street, underwood QLD 4119 P:+61 (7) 3208 6799 sales@multistore.com.au For easy assembly instructions, please refer to video on our website: www.multistore.com.au...
