ASSEMBLY INSTRUCTION FOR EXC-750
TOP of UNIT
When attaching unit to wall put safety bracket in
middle of unit with 16mm pan head screw then
25mm pan head screw into wall.
For plasterboard without a stud it is recommended
to use a plug with screw (not provided).
2 x TOP GABLES
2 x BOTTOM
GABLES
2 x BACKING
BOARDS
NO MODEL
DESCRIPTION
CONFIRMAT SCREWS
1
50mm x 5mm
2
WHITE CAPS
3
DOWELS
4
BACKING NAILS
PARTS IDENTIFICATION LIST
FOLD LINE
QTY
20
20
4
75
3 x FIXED SHELF
1 x BOTTOM KICK
4 x 30mm FLANGES
2 x 30mm HANGING RAIL
1 x SAFETY BRACKET
NO MODEL
DESCRIPTION
5
16mm PAN HEAD SCREWS
6
25mm PAN HEAD SCREWS
7
"L" SAFETY BRACKET
16mm COUNTER SUNK SCREWS
8
EXC-750
QTY
1
1
1
4
Advertisement
Related Manuals for Multistore EXC-750
Summary of Contents for Multistore EXC-750
- Page 1 ASSEMBLY INSTRUCTION FOR EXC-750 EXC-750 TOP of UNIT When attaching unit to wall put safety bracket in middle of unit with 16mm pan head screw then 25mm pan head screw into wall. For plasterboard without a stud it is recommended to use a plug with screw (not provided).
- Page 2 INTO THE HOLES PROVIDED IF YOU WISH YOU CAN SCREW IN 1 SCREW INTO THE MIDDLE OF THE FLANGE AND SLIDE IN YOUR HANGING RAIL. Multistore Industries (Aust) Pty Ltd 9 Nevilles Street, Underwood, QLD 4119 Tel—(07) 3208 6799 Fax- (07) 3209 6332 www.multistore.com.au...
- Page 3 10 Year Warranty • If the purchaser has a fault or defect with this product, the purchaser needs to contact Multistore Industries (Aust) directly on (07) 3208 6799 and state date of purchase, place of purchase and proof of purchase.
