Watlow Anafaze PPC-2000 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PPC-2000
User's Guide
WATLOW
1241 Bundy Boulevard
Winona, Minnesota USA 55987
Phone: +1 (507) 454-5300,
Fax: +1 (507) 452-4507
Part No. 0600-3000-2000 Rev 2.3d
http://www.watlow.com

Advertisement

Table of Contents
loading

Related Manuals for Watlow Anafaze PPC-2000

Summary of Contents for Watlow Anafaze PPC-2000

  • Page 1 PPC-2000 User’s Guide WATLOW 1241 Bundy Boulevard Winona, Minnesota USA 55987 Phone: +1 (507) 454-5300, Fax: +1 (507) 452-4507 Part No. 0600-3000-2000 Rev 2.3d http://www.watlow.com...
  • Page 3 PPC-2010-xxB with adaptive control. Refer to the PPC-2000 User’s Guide regarding all other functionality which is the same as the standard version. Introduction The Watlow Anafaze PPC-2000 controller offers these standard options: • Forty-eight loops of conventional PID control with auto-tuning capability -or- •...
  • Page 4 To have the controller relearn the Plant Delay, set the loop's Control Mode to Manual or Off, set the Plant Delay to Automatic, and then set the Control Mode to Auto again. Adaptive Addendum PPC-2000 User's Guide 0600-0049-0001 rev C Watlow Anafaze...
  • Page 5 Input Signal Hi PV Lo ). See Setting up User Selectable Linear Inputs on PV Hi page 98 of the PPC-2000 User's Guide. 3. On the spreadsheet for each channel: Channels Adaptive Addendum PPC-2000 User's Guide 0600-0049-0001 rev C Watlow Anafaze...
  • Page 6 (typically degrees) above the process variable. d. Set the Control Mode Auto to begin adaptive closed-loop control. NOTE: Only channels 1 to 8 can be selected for adaptive control. Adaptive Addendum PPC-2000 User's Guide 0600-0049-0001 rev C Watlow Anafaze...
  • Page 7 V2: +24 Vdc @ 4 A Input Frequency 47 to 440 Hz Peak Current Output 9A @ 5Vdc 6A @ 24 Vdc 1241 Bundy Blvd. Winona, MN 55987 Phone: (507) 494-5656 Fax: (507) 452-4507 ©2004 Watlow Page 1 of 1...
  • Page 8 Upon request by Watlow Anafaze, Incorporated, the product or part claimed to be defective shall immediately be returned at the Customer's expense to Watlow Anafaze, Incorporated. Replaced or repaired products or parts will be shipped to the Customer at the expense of Watlow Anafaze, Incorporated.

  • Page 9: Table Of Contents

    List of Figures ix List of Tables xv Overview 1 Manual Contents 1 Getting Started 2 Safety symbols 2 Contacting Watlow Anafaze 2 Initial Inspection 2 Product Features 3 System Components 3 PPC-2000 Modules 6 PPC-2000 Terminal Boards 8 Additional Components 9...
  • Page 10 Connecting to the Relay Outputs on the PPC-206x 70 Wiring PPC-2062 Relay Outputs 71 Using Snubbers for Relay Outputs 73 Connecting Power 77 PPC-IPS-2 Power Supply 77 Processor Module 77 Connecting Communication Ports 78 Communication Ports 78 Connecting RS-485 Communications 81 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 11 Setting up Outputs for Use with a Logic Program 113 Using Logic to Set an Analog Input 113 Starting and Stopping Logic Programs 113 Controller Parameters 115 Channels 115 Digital I/O 132 Soft Integer 136 Soft Boolean 137 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 12 Accessing Soft Bool and Soft Int Registers with LogicPro 205 Soft Bool and Soft Int Registers 205 Global Parameters in the Database 206 Accessing Global Parameters with Modbus 206 Communications Parameters 207 Global Database Parameters 209 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 13 Message Framing 271 Address Field 272 Function Field 272 Data Field 273 Error Checking Field 273 Field Format 273 Parity Checking 274 CRC Checking 275 Read Examples 280 Appendix B: Declaration of Conformity 283 Glossary 285 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 14 Table of Contents PPC-2000 User’s Guide viii Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 15: List Of Figures

    Figure 2.31—Thermocouples Connected to Differential Inputs 1 and 2 Figure 2.32—Thermocouples Connected to Single-ended Inputs 1 and 2 Figure 2.33—Wiring 2-Wire RTDs: Input 1 and 2 Shown Figure 2.34—Wiring 3-Wire RTDs: Input 1 and 2 Shown Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 16 Figure 2.69—Connecting One PPC to a Computer Using RS-232 Figure 2.70—Connecting Multiple PPCs to a Computer Using RS-485 Figure 2.71—RS-485 Wiring Figure 2.72—Two Wire RS-485 Wiring Figure 2.73—Connecting Several PPCs with Short Cable Runs Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 17 Figure 3.26—Soft BOOL Spreadsheet Figure 3.27—PPC Globals Screen Troubleshooting 141 Figure 4.1—Assembled Modules Top View Figure 4.2—Assembled Modules Bottom View Figure 4.3—PPC-2010 Internal View Figure 4.4—PPC Assembled Modules Top View Figure 4.5—PPC Assembled Modules Bottom View Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 18 Figure 7.18—PPC-EITB Dimensions with HD-Type Cable Figure 7.19—PPC-TB50-SCSI Dimensions Figure 7.20—PPC-TB50-SCSI Dimensions with Straight SCSI Cable Figure 7.21—PPC-TB50-SCSI Dimensions with Right-Angle SCSI Cable Figure 7.22—PPC-IPS-2 Figure 7.23—SDAC Dimensions Appendix A: Modbus Protocol 269 Figure A.1—Query—Response Cycle Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 19 Table 2.26—Power Supply Connections Table 2.27—RS-232 Connector Pin Outs Table 2.28—RS-485 Connector Pin Out and Connections Table 2.29—RTS/CTS Pins in DB-9 and DB-25 Connectors Table 2.30—485 Terminal Block Pin Assignment Table 2.31—PPC-2010 Rotary Switch Configuration Doc.# 30002-00 Rev 2.3 Watlow Anafaze xiii...
  • Page 20 Table 5.27—Output Destinations for Soft Boolean and Soft Integers Table 5.28—Alarm Status Table 5.30—Alarm and Control Functionality Table 5.31—Alarm Acknowledge Table 5.32—Alarm Enable/Disable Table 5.33—Database Offsets and Sample Modbus Addresses for Digital I/O Table 5.37—Digital I/O Uses Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 21 Table 7.11—Digital Input Specifications Table 7.12—Digital Output Specifications Table 7.13—Serial Interface Table 7.14—Model Numbers Table 7.15—Environmental Specifications Table 7.16—Physical Specifications Table 7.17—Connections Table 7.18—Power Specifications Table 7.21—Sensor Reference Voltage Output Table 7.22—Model Number Table 7.23—Environmental Specifications Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 22 Table 7.66—Safety and Agency Approvals Table 7.67—Environmental Specifications Table 7.68—Physical Specifications Table 7.70—PPC-TB50-SCSI with Straight SCSI Table 7.72—Environmental Specifications Table 7.73—Physical Specifications Table 7.74—Dimensions with Din Rail Bracket Table 7.75—Power Specifications Table 7.76—Connections Table 7.77—Safety and Agency Approvals Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 23 Appendix A: Modbus Protocol 269 Table A.1—Example Message Frame Table A.2—Function Codes Table A.3—Sample Packet for Host Query Table A.4—Sample Packet for Slave Response Table A.5—Sample Packet for Host Query Table A.6—Sample Packet for Slave Response Doc.# 30002-00 Rev 2.3 Watlow Anafaze xvii...
  • Page 24 List of Tables PPC User’s Guide xviii Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 25: Overview

    PPC-2000 system and its peripherals. • Chapter 3: Software Setup. Describes how to use your PPC system with AnaWin3 , the Watlow Anafaze Human- Machine Interface (HMI) software. • Chapter 4: Troubleshooting. Includes troubleshooting, upgrading and reconfiguring procedures for technical personnel.

  • Page 26: Getting Started

    NOTE! Indicates pertinent information or an item that may be useful to document or label for later reference. Contacting Watlow Anafaze To contact Watlow Anafaze, send correspondence to: Watlow Anafaze, Inc. 314 Westridge Drive Watsonville, CA 95076 Our technical support and customer service departments may be reached Monday-Friday, 8 a.m.

  • Page 27: Product Features

    The number and types of I/O are determined by which modules are selected for the application. Field wiring connects to DIN rail or panel mounted terminal block boards. Terminal block boards connect to I/O modules via 50-pin SCSI cables. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 28 (option) PC for AnaWin3 HMI Power PPC-2000 Encoder Input Supply Assembly Terminal Block Software and/or LogicPro (EITB) Analog Input Terminal Board (AITB) TB50 for Digital I/O Operator Interface Terminal Figure 1.1 System Diagram Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 29: Table 1.1-Ppc-2000 System Modules

    Linear voltages (differential or single-ended) PPC-KEY-30 Adapts AITB for 0-20mA linear current (blue) (differential) PPC-KEY-40 Adapts AITB for 0-20mA linear current (single-ended) (black) PPC-KEY-50 Adapts AITB for 2-wire RTDs (differential) or 3-wire RTDs (differential) (red) Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 30: Ppc-2000 Modules

    Precision analog outputs can be provided using Serial Digital to Analog Converters (SDAC). Each SDAC unit converts a control output from the processor module to an analog voltage or current signal. For more specific information, see SDAC Serial Analog-to-Digital Converter on page 9. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 31 • High voltage isolation capability • Supports TCs, RTDs and linear voltage & current signals • LED status indicator • DIN rail/panel mount • Connects to analog input terminal board via 50-pin SCSI cable Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 32: Ppc-2000 Terminal Boards

    PPC-KEY-01 through 04 in Table 1.1 on page 5. The keys allow easy configuration of the terminal block for different types of inputs on different channels. The AITB is DIN rail or panel mount compatible. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 33: Additional Components

    24Vdc and has 5Vdc available for powering loads. Safety Watlow Anafaze has made every effort to ensure the reliability and safety of this product. In addition, we have provided recommendations that will allow you to safely install and maintain this controller.

  • Page 34: External Safety Devices

    Failure to install external protection devices where hazards exist can result in damage to equipment and property as well as loss of human life. Contact Watlow Anafaze immediately if you have any questions about system safety or system operation. Watlow Anafaze...

  • Page 35: External Switch Disconnect

    European Union Directives. This symbol indicates that the product is listed by Underwriters Laboratory and Canadian Underwriters LISTED Laboratory. Î The terminals adjacent to this symbol should be connected to DC voltage only. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 36 Chapter 1: Overview PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 37: Hardware Installation

    Read this chapter before installing your PPC-2000 system. Power Supply Requirements Watlow Anafaze provides the PPC-IPS2 power supply for the PPC-2000 system. This unit supplies sufficient current for a processor and various combinations of I/O modules. For specification information on the power supply, refer to Chapter 7, Specifications.
  • Page 38 PPC-202x (max. 4) 195mA PPC-2030 (max. 4) 450mA PPC-2040 (max. 6) 150mA PPC-2050 400mA PPC-2051 250mA (max. 4) PPC-206x (max. 6) 125mA PPC-207x (max. 4) 50mA total Total Number of current Modules (max. 10) required Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 39: Mounting The Power Supply

    PPC-IPS-2 can be DIN rail or screw mounted. Refer to Figure 2.1 for power supply mounting clearances. All dimensions are measured in inches. 2.5 in. min. Air Flow Space 1.2 in. 3.1 in. 1.97 in. Figure 2.1 PPC-IPS-2 DIN Mounting Dimensions Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 40: Figure 2.2-Ppc-Ips-2 Panel Mounting Dimensions

    Drill and tap the mounting holes. Place the power supply such that the holes are aligned, insert the screws and tighten them Table 2.3 Power Supply Screw Mounting PPC-IPS-2 Number of Screws Drill and tap size Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 41: Hardware Configuration

    PPC system. Refer to Chapter 4, Resetting Closed-Loop Control Parameters on page 156. NOTE! It may be useful to label each module with the address you select. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 42: Ppc-2010 Jumper Settings

    Locate jumpers 1 and 2. Table 2.5 describes the PPC-2010 jumper configuration. Install the jumper in the orientation shown in Figure 2.4 on page 19. Table 2.5 PPC-2010 Processor Module Jumpers Terminated Unterminated Port Jumper # Position Position Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 43: Ppc-2030 Dip Switch Settings

    (on) or quadrature (off) position. The switch is on when in the direction indicated by the arrow. ç CAUTION! Be sure to take antistatic precautions. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 44: Ppc-2030 Jumper Settings

    Locate Jumpers 1 through 4. Table 2.6 on page 21 describes the analog output jumper configuration. Install the jumper in the orientation shown in Figure 2.5. ç CAUTION! Incorrectly installing the jumper may damage the PPC-2030 module. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 45: Ppc-2040 Jumper Settings

    Table 2.7 and Figure 2.6 to determine which jumper to set and appropriate position. Table 2.7 PPC-2040 Counter Input Jumpers Counter Jumper Single Phase Quadrature Input PPC-2040 Position Position Figure 2.6 PPC-2040 Jumper Settings Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 46: Ppc-205X Jumper Settings

    Position* Position* 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc 0-20mA 0-10Vdc * Listed values are maximum ranges. Other ranges within these limits may be selected in software. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 47: Figure 2.7-Ppc-205X Jumpers

    JU7 (2050: Output 7, 2051: Output 4) JU6 (2050: Output 6) JU5 (2050: Output 5, 2051: Output 3) JU4 (2050: Output 4) JU3 (2050: Output 3, 2051: Output 2) JU2 (2050 Output 2) JU1 (Output 1) Figure 2.7 PPC-205x Jumpers Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 48 (pushed toward the back of the module. Refer to Figure 2.8. Back Module latch (unlocked) Module latch (locked) Front Figure 2.8 Assembled Modules Top View Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 49: Figure 2.9-Assembled Modules Bottom View

    The modules are properly locked when there is a firm connection with no rocking or shifting. Repeat these steps for any additional modules. When there are no additional modules, install the right end cap in a similar manner. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 50: Module Disassembly

    140°F (60°C). NOTE! During wiring and cabinet assembly, prevent debris from falling inside the PPC by removing the unit from the area, or cover the ventilation holes on the PPC system. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 51: Din Rail Mounting

    DIN Rail DIN Rail Latch (open) Push to lock Figure 2.12 Mounting Assembled PPC Modules on a DIN rail (side) Push the DIN rail latches up and under the lower lip of the DIN rail. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 52: Mounting Terminal Boards

    Refer to Figure 2.13 on page 29 for AITB dimensions. Refer to Figure 2.14 on page 30 for EITB dimensions. Refer to Figure 2.15 on page 31 for TB50 dimensions. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 53: Figure 2.13-Aitb Dimensions / Clearances

    For more detailed specification information, refer to Chapter 7, Specifications. 3.6" (91 mm) 2.0" (51 mm) 5.756" 4.70" 5.10" L 5.1" (128 mm) (146 mm) (119 mm) (130 mm) 2.6" (66 mm) 4.0" W (102 mm) Figure 2.13 AITB Dimensions / Clearances Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 54: Figure 2.14-Eitb Dimensions / Clearances

    Chapter 2: Hardware Installation PPC-2000 User’s Guide 2.2 in. (56 mm) 3.8 in. L 3.4 in. (86 mm) (97 mm) 1.6 in. (41 mm) 2.0 in. W (51 mm) Figure 2.14 EITB Dimensions / Clearances Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 55: Din Rail Mounting

    To install a terminal board on a DIN rail, place the hook side of the mounting mechanism over one of the DIN rail lips and snap the board over the other lip. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 56: Din Rail Removal

    Pry the snap latch away from the DIN rail lip and repeat for the other side. See Figure 2.17. Removal catch for screwdriver DIN Rail snap latch Hook side Figure 2.17 TB50 Mounted on DIN Rail (Side) Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 57: Panel Mounting

    When a location has been determined for board, mark the four mounting holes. Drill and tap the four #6-32 mounting holes. Place the terminal board so the standoffs are aligned with the holes. insert the screws in to the standoffs and tighten them. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 58: System Wiring

    ç CAUTION! Never route low power circuits next to high power AC wiring. Instead, physically separate high power circuits from the controller. If possible, install high voltage AC power circuits in a separate panel. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 59: Wiring Recommendations

    6000 ft. Noise Suppression The PPC-2000’s outputs are designed to drive resistive loads. Open collector outputs can drive solid state relays. These relays may in turn operate more inductive types of loads such as Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 60 The watchdog time out LED on the Processor Module lights. EMI may also damage the digital output circuit—so digital outputs will not turn on. If the digital output circuit is damaged, return the controller to Watlow Anafaze for repair. Avoiding Noise Problems To avoid RFI/EMI noise problems: •...

  • Page 61: Avoiding Ground Loops

    Analog common terminals on AITBs • Signal common terminals on the EITB or other devices connected to the encoder inputs on a PPC-2030 Watlow Anafaze strongly recommends that you: • Isolate outputs through solid state relays, where possible. • Isolate RTDs or “bridge” type inputs from ground.

  • Page 62: Tb50 Connections

    TB50. Table 2.10 on page 39 shows the TB50 pinout for use with the PPC-2010. Use 14 to 22 AWG wire. When making connections, tighten to 0.5 to 0.6 Nm, or 4.5 to 5.4 inch-pound. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 63 Digital Out 29 PPC1: Proc 0.0.29 Digital Out 30 PPC1: Proc 0.0.30 Digital Out 31 PPC1: Proc 0.0.31 Digital Out 32 PPC1: Proc 0.0.32 Digital Out 33 PPC1: Proc 0.0.33 Digital Out 34 PPC1: Proc 0.0.34 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 64: Connecting Digital Inputs

    TB50. Refer to Table 2.10 on page 39 for screw terminal numbering. Use the Digital I/O parameters to configure digital inputs. Refer to Digital I/O on page 132. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 65: Connecting Counter Or Frequency Inputs

    Figure 2.23 through Figure 2.25, use a solid state relay to drive your load. The outputs conduct current when they are LOW or ON. The maximum current sink capability is 100mA at 24Vdc. They cannot ‘source’ current to a load. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 66: Figure 2.23-Powering Output With 5Vdc From Ppc Supply

    Figure 2.23 Powering Output with 5Vdc from PPC Supply TB50 2010 Digital Figure 2.24 Powering Output with 12-24Vdc from PPC supply TB50 2010 Digital controller Output Figure 2.25 Powering Output with Separate Power Supplies Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 67: Sdac Connections

    TB50 (digital output • Connect SDAC pin 4 to the desired control output on the 41-45 TB50 (digital output • Connect SDAC pins 5 and 6 to the input of the controlled device. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 68: Figure 2.27-Wiring Single/Multiple Sdacs

    DC COM COM In PPC-2010 CLK In Processor Data In Electrical DC COM + Out Isolation SCSI - Out TB50 Connection SDAC Clock 41 to 45 Control Load Output Figure 2.27 Wiring Single/Multiple SDACs Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 69: Connecting Analog Inputs To The Ppc-2021 - 2025

    If more than one AITB has been installed, it may be useful to label both ends of the SCSI cable and the AITB with the address selected on the corresponding analog input or high isolation analog input module. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 70: Sensor Keys

    Figure 2.29 Inserting Sensor Keys in AITB Table 2.11 Sensor Keys Used Color Sensors with None TC and Voltage 2021 2-Wire or 3-Wire 2024 Platinum 100Ω RTD 2025 2021 Differential Blue 0-20mA 2024 Current 2025 Single-Ended Black 0-20mA 2022 Current Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 71: Aitb Connections

    When connecting sensor wires, tighten to 0.5 – 0.6 Nm, or 4.5 – 5.4 inch-pound. Table 2.12 Numbers and Types of Inputs by Module Type Number Differential or Module Note Single-ended Inputs PPC-2021 Differential PPC-2022 Single-ended PPC-2024 Differential High Isolation PPC-2025 Differential High Isolation Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 72 2000 in the system. See Inputs on page 127 for a full explanation of analog input naming. For the single-ended module the negative sensor lead is connected to any one of the Com (Analog Common) terminals. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 73: Connecting Thermocouples

    Ref (4 PL.) Analog Common Com (8 PL.) NOTE! The Ref voltage is provided for special sensor types. Do not use this voltage without consulting Watlow Anafaze. Connecting Thermocouples NOTE! Connect thermocouple shields directly to a good frame or chassis ground. Connect thermocouple shields at one end only, either near the terminal board or the sensor end.

  • Page 74: Connecting Rtds

    They may only be used with a differential analog input module. A jumper wire must be added on the terminal board from the terminal to the terminal. See Figure 2.33 on page 51. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 75 . See Figure 2.34. AITB 1A (input 1+) 1B (input 1-) 2A (input 2+) 2B (input 2-) Figure 2.34 Wiring 3-Wire RTDs: Input 1 and 2 Shown Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 76: Connecting Sensors With Linear Voltage Signals

    Differential Inputs 1 and 2 Single-ended voltage sources should have the positive lead on the positive terminal of the desired input. The negative lead should be connected to the terminal. See Figure 2.36 on page 53. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 77: Connecting Sensors With Linear Current Signals

    Input 1, 2, and 3 Shown Single-ended current sources should be have the positive lead on the positive terminal of the desired input. The negative lead should be connected to the terminal. See Figure 2.38 on page 54. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 78: Figure 2.38-Connecting Current Inputs To A Single-Ended Analog Input Module: Input 1 And 2 Shown

    Typical Typical 3-wire Power 2-wire current current Supply source transmitter transmitter – – – 1A(Input 1+) 2A(Input 2+) Figure 2.38 Connecting Current Inputs to a Single-ended Analog Input Module: Input 1 and 2 Shown Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 79: Connecting The Encoder Input Cable To The Ppc-2030

    60 discusses analog outputs from the PPC-2030. NOTE! If more than one EITB has been installed, it may be useful to label both ends of the HD-15 connector and each EITB with the corresponding module address and jack number. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 80: Figure 2.40-Ppc-Eitb-1

    The AnaWin3 name is shown for the Encoder In Analog Out module with address 11 on the first PPC-2000 in the system. See Inputs on page 127 for a full explanation of Analog input naming. Both count and frequency are measured for each input. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 81: Encoder Wiring

    Both phases are used only in quadrature mode nominally. EITB 2 (input 1 phase 1+) 8 (input 2 phase 1+) 12 (COM) Figure 2.41 EITB Single-ended Single Phase Connections: Input 1 and 2 Shown Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 82 2 (input 1 phase 1+) 3 (input 1 phase 1-) 12 (COM) 8 (input 2 phase 1+) 9 (input 2 phase 1-) 12 (COM) Figure 2.43 EITB Differential Single Phase Connections: Input 1 and 2 Shown Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 83: Encoder Connections Without The Eitb

    The AnaWin3 name is shown for the Encoder In Analog Out module with address 11 on the first PPC-2000 in the system. Refer to Inputs on page 127 for a full explanation of analog input naming. Both count and frequency are measured for each input. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 84: Analog Output Connections

    The AnaWin3 name is shown for the Encoder In Analog Out module with address 11 on the first PPC-2000 in the system. Refer to Outputs on page 135 for a full explanation of Analog output naming. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 85: Connecting I/O To The Ppc-2040

    I/O (sensors, actuators, relays, SSRs, etc.). Connecting the TB50 to the PPC-2040 Module Refer to Figure 2.47 on page 62. Connect the SCSI connector from the PPC-2040 module to the TB50. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 86: Tb50 Connections

    Table 2.21 on page 63 shows the TB50 pinout when used with the PPC-2040. Use 14 to 22 AWG wire. When making connections, tighten to 0.5 to 0.6 Nm, or 4.5 to 5.4 inch-pound. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 87 See Digital I/O on page 132 for a complete explanation of digital I/O names. Both count and frequency are measured for the pulse input. See Inputs on page 127 for an explanation of analog input names. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 88: Connecting Digital Inputs

    The PPC-2040 module can accommodate encoder signals up to 24Vdc. The following figures illustrate connecting encoders: TB50 1 (input 1 phase 1+) 3 (input 2 phase 1+) 37 (COM) Figure 2.49 Single Phase Connections: Input 1 and 2 Shown Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 89: Connecting Digital Outputs

    The outputs conduct current when they are LOW or ON. The maximum current sink capability is 150mA at 24Vdc. They cannot ‘source’ current to a load. + 12-24 TB50 Digital Figure 2.51 Powering Output with 5Vdc from PPC Supply Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 90: Figure 2.52-Powering Output With 12-24Vdc From Ppc Supply

    Chapter 2: Hardware Installation PPC-2000 User’s Guide TB50 Digital Figure 2.52 Powering Output with 12-24Vdc from PPC supply TB50 Digital controller +5 to 24Vdc Output Figure 2.53 Powering Output with Separate Power Supplies Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 91: Figure 2.54-Ppc-205X Connections (Bottom View)

    1. The AnaWin3 name is shown for the Encoder In Analog Out module with address 11 on the first PPC-2000 in the system. Refer to Outputs on page 135 for a full explanation of Analog output naming. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 92: Figure 2.55-Analog Output Connections On A Ppc-2050 Configured For Current: Outputs 1 And 2 Shown

    PPC-2050 Sink Load Source Sink Load Source Figure 2.55 Analog Output Connections on a PPC-2050 Configured for Current: Outputs 1 and 2 Shown Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 93: Figure 2.56-Analog Output Connections On A Ppc-2050 Configured For Voltage: Outputs 1 And 2 Shown

    Voltage: Outputs 1 and 2 shown NOTE! The B terminal sources current and the A terminal sinks it on outputs configured for current. On outputs configured for voltage the A terminal is at the greater potential. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 94: Connecting To The Relay Outputs On The Ppc-206X

    Relay output field wiring is terminated at a sixteen position removable terminal block. 16-pin terminal block for relay outputs Common Terminals PPC-2062 PPC-2061 Figure 2.58 PPC-206x Connections (bottom view) Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 95: Wiring Ppc-2062 Relay Outputs

    The PPC-2062 has eight normally open, single-contact relay outputs. The load may be connected to either contact. DC or AC power may be switched. See Figure 2.60 on page 72 for an example of how to connect to the relay outputs. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 96 The AnaWin3 name is shown for the Digital Out module with address 41 on the first PPC-2000 in the system. See Digital I/O on page 132 for a full explanation of Digital I/O naming. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 97: Using Snubbers For Relay Outputs

    Resistor: 120 Ω • Capacitor: 0.47 µF • Install the snubber across the contacts or the load. Generally, it performs more reliably across the contacts. 120/240Vac Preferred Method Load Contacts Alternative Method Figure 2.61 Snubber Connections Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 98: Figure 2.62-Ppc-207X Connections (Bottom View)

    PPC-2071 PPC-2072 PPC-2073 Figure 2.62 PPC-207x Connections (bottom view) PPC-2070/ Input Device PPC-2071 (2072 only) Input Device Å Source Source Figure 2.63 Input Connections to a PPC-2070 or PPC-2072: Inputs 1 and 2 shown Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 99: Figure 2.64-Input Connections To A Ppc-2071 Or Ppc-2073: Inputs 1,2, 9 And 10 Shown

    PPC-2073: Inputs 1,2, 9 and 10 Shown PPC-2072/ PPC-2073 C/C1 Sensor’s Output Sensor Circuit Source Current Sinking Field Device Figure 2.65 Connecting a Current Sinking Field Device to a PPC-2072 or PPC-2073: Input 1 Shown Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 100 The AnaWin3 name is shown for the Digital In module with address 51 on the first PPC-2000 in the system. See Digital I/O on page 132 for a full explanation of digital I/O output naming. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 101: Connecting Power

    C to the DC common. See Table 2.26 for connections for the two power supplies. Table 2.26 Power Supply Connections PPC-2010 IPS-2 Figure 2.67 on page 78 illustrates the connections when using the PPC-IPS-2. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 102: Connecting Communication Ports

    Both communication ports support RS-232 and RS-485 signals. A 4-position, 4-conductor telephone handset connector is provided for RS-232 communications and an RJ12 connector is provided for RS-485 communications. Only one of these connectors may be used. Both ports are optically isolated. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 103: Figure 2.68-Rs-232 And Rs-485 Rj-Type Connectors

    1 in the connectors. Refer to Table 2.27 on page 79 for RS-232 cable pin outs. Refer to Table 2.28 on page 80 for the RS-485 pin out and connections. The colors in the table are for Watlow Anafaze cables.
  • Page 104 Table 2.29 RTS/CTS Pins in DB-9 and DB-25 Connectors DB-9 DB-25 Cables manufactured by Watlow Anafaze for RS-232 communications include these jumpers. AnaWin3 and LogicPro do not require these jumpers and are not affected by their presence. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 105: Connecting Rs-485 Communications

    232 to 485 converter no more than 10 ft. flat cable with RJs PPC N PPC 1 PPC 2 Figure 2.70 Connecting Multiple PPCs to a Computer Using RS-485 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 106: Figure 2.71-Rs-485 Wiring

    485 network. Pins on the terminal block are designated 1 to 6. The function and number of each pin corresponds to the function and pin numbers of the 485 ports on the PPC-2010 module. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 107: Table 2.30-485 Terminal Block Pin Assignment

    Not used Not used Cable Recommendations Watlow Anafaze recommends Belden #9843 or its equivalent. This cable includes three, 24 AWG, shielded, twisted pairs. It should carry signals of up to 19.2 kbaud with no more than acceptable losses for up to 4000 feet.

  • Page 108: Figure 2.72-Two Wire Rs-485 Wiring

    485 Communications 232 Communications serial port shielded twisted pair cable optically isolating 232 to 485 converter 6-wire RJ12 splitter PPC 1 PPC 2 PPC N Figure 2.73 Connecting Several PPCs with Short Cable Runs Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 109 PPC. See Figure 2.70 on page 81. The value of the termination resistor should be equal to the impedance of the communications cable used. Values are typically 120 to 200 ohm. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 110: Table 2.31-Ppc-2010 Rotary Switch Configuration

    8 data bits (fixed) • 1 stop bit (fixed) Switch position selects the following fixed settings: • 19.2 kbaud • Even parity • 8 data bits • 1 stop bit Switch settings are reserved. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 111 12. Turn off power to the PPC system. 13. Turn on power to the PPC system. Once configured with unique addresses, as many as 32 PPC controllers may be connected to the PC on a 485 communications network. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 112 Chapter 2: Hardware Installation PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 113: Operating With Anawin3

    Operating with AnaWin3 This section describes how to use your PPC system with AnaWin3, the Watlow Anafaze HMI software. For hardware installation and configuration information, refer to Chapter 2, Hardware Installation. For AnaWin3 installation and user information, refer to the AnaWin3 User’s Guide.

  • Page 114: Feedback

    See Channels on page 115 for more information. When PID control is used for one or both channel outputs, both the spread and the PID parameters determine when control switches between heating and cooling. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 115: Table 3.1-Control Types Pid1 And Pid2

    This algorithm was devel- oped for plastic extruders, but may be of benefit whenever a load is typically heated but occa- sionally needs cooling. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 116 See Autotuning on page 93 or more infor- mation on autotuning. If both heat and cool outputs are used, set the Spread. Set the Set Point to the desired value and the Control Mode to Auto to begin closed-loop control. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 117: Prerequisites

    (i.e., manual mode) and leaves the PID parameters unchanged. The Watlow Anafaze autotune is started at ambient temperature or at a temperature above ambient. However, the temperature must be stable and there must be sufficient time for the controller to determine the new PID parameters.

  • Page 118: Using Anawin3 To Tune

    Adjust the Set Point to the desired temperature. Restore the setting of the input filter to its original value. ç CAUTION! Never set the set point above the safe operating limits of your system. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 119: Alarms

    Digital output, or Soft Bool, if set, activates on alarm, deactivates when channel is not in alarm. Control Global alarm output does not activate. No alarm acknowledgment required to clear. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 120: Alarm Delay

    The controller may be configured to delay alarm reporting. Alarm Delay delays failed sensor alarms and process alarms for the channel. Only alarms that are continuously present for longer than the alarm delay time are reported. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 121: Setting Up Process And Deviation Alarms

    On the Dig I/O spreadsheet, set the Logic of each output used for alarms as desired. Return to the Alarms spreadsheet. Enable the alarm by setting the corresponding field (LP Enable, LD Enable, HD Enable, HP Enable) to Enabled. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 122: Figure 3.3-Linear Input Example

    To define the conversion function, the user specifies two points on the line. See Figure 3.3. 20 PSI PV Hi Process Variable PV Lo 0 PSI Input Signal Hi 10V Input Signal Lo Sensor Input Figure 3.3 Linear Input Example Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 123: Setting Input Signal Lo And Input Signal Hi

    PV Lo and PV Hi. The PV Lo is the process variable measured when the sensor signal is at the level set in the Input Signal Lo field. The PV Hi is the process variable measured when Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 124: Setting Decimal Places

    PV Lo or PV Hi is changed. Table 3.4 PV Range permitted for various Decimal Places Settings Decimal PV Lo PV Hi Places minimum maximum -32768 32767 -3276.8 3276.7 -327.68 327.67 -32.768 32.767 -3.2768 3.2767 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 125: Linear 4-20Ma Input Example

    Scaling Parameters for 4-20mA Linear Input Example Parameter Setting Units Input Type Linear -2 to 20 (mA) Units Input Signal Lo 4.000 Input Signal Hi 20.000 PV Lo 0.00 PV Hi 100.00 Decimal Places Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 126: Process Variable Retransmit

    Heat/Cool Scale Lo Sensor Range Min Set Point Max Set Point Sensor Range High Analog Input Range (Engineering Units) Figure 3.4 Linear Scaling of the Analog Input for Retransmit on the Heat or Cool Output Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 127: Setting Up Process Variable Retransmit

    Set the Cool Scale Lo to a percent of the range of the se- lected cool output type. This is the signal level that will be transmitted when the analog input selected as Set Point Source is at a value you entered for Min Set Point. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 128: Process Variable Retransmit Example

    0°F to 0°F, channel 2’s output will be 4mA. When the analog input value is equal to or greater Max Set Point 1000°F than 1000°F, channel 2’s output will be 20mA. Auto Control Mode Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 129: Cascade Control

    Max Set Point Min Set Point -100% 100% Primary Channel’s Output (% of Full Scale) Figure 3.6 How the Secondary Channel’s Set Point is Determined When the Primary Channel Has Heat and Cool Outputs Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 130: Setting Up Cascade Control

    The inner TC is connected to the first input on the Analog Input outer module. Output 22 on the Processor module is used to drive a solid state relay power control. Figure 3.8 on page 107 illustrates this application. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 131 As the input drops 10°F, the output increases to 100%. Heat Integral Only proportional control is used. Heat Derivative Only proportional control is used. The primary output must be enabled, but is not used to drive Heat Output Dest PPC1:Soft Bool a load. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 132 1’s output is 100% and channel 2’s set point is 190°F. At this point further decreases to channel 1’s process variable have no additional affect on channel 2. Figure 3.9 on page 109 illustrates this relationship. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 133: Ratio Control

    Figure 3.10 on page 110 illustrates this relationship. The set point of the ratio loop is limited by the settings of Max Set Point and Min Set Point. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 134: Setting Up Ratio Control

    Set the Min Set Point to the lowest set point value the ratio channel should ever have. Set the Max Set Point to the highest set point value the ratio channel should ever have. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 135: Figure 3.11-Sample Application Using Ratio Control

    0 gps. When the water flow is 0 gps the KOH flow Min Set Point 0 gps should be 0 gps. Max Set Point 15 gps The KOH set point will not exceed 15 gps. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 136: Differential Control

    If an output variable in a logic program sets a value using an IO Driver and IO Physical Address, the associated register in the PPC-2000 cannot be written to by the closed-loop control program, an HMI or any other device. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 137: Setting Up Outputs For Use With A Logic Program

    To start the logic program: Select the View menu. Select PPC Globals. Double-click on the Start Logic Program button. Click on the Send button to command the PPC to start the logic program -or- click Cancel. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 138 Closed-loop control is disabled during logic downloads. Control modes are set to Off. Ensure that all loops can be safely disabled before downloading programs. After the program has been successfully downloaded, loops remain in the Off mode. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 139: Controller Parameters

    For example, Heat Prop Band is the proportional band for the heat output and Cool Prop Band is the proportional band for the cool output. A description for each parameter in Channels follows. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 140 Enter a cool output value in percent when the channel is in manual control mode, or monitor the output in automatic control. For PID output types, the output is calculated based on the cool PID parameters. Range: 0.0% to 100.0% Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 141 Point Ratio to calculate the set point. (Ratio Control on page 109, Differential Control on page 112, and Remote Set Point on page 112.) Range: -32768 to 32767 (Decimal placement depends on the Input Type selected.) See Table 3.15 on page 130. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 142: Table 3.12-Anawin3 Control Types

    Enter the derivative term value which controls the amount of influence the rate of change of the error has on the output. A greater value yields a greater derivative action. The derivative constant is in units of seconds. Range: 0 to 255 seconds Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 143 This field specifies the type of output signal and determines whether the PID or on/off control algorithm is used for the channel. Refer to AnaWin3 Output Types on page 120 for a description of the output type options. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 144 Lag Curve A — Output is reduced somewhat from calculated value. • Lag Curve B — Output is further reduced from calculated value. Straight linear is used for most applications. Lag curves are usually used in plastic extruder applications. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 145: Figure 3.13-Output Scaling (Heat/Cool) Curves

    Manual to Automatic control. The heat/cool limit only affects channels under automatic control. It does not affect channels under manual control. Range: 0.0% to 100.0% Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 146 Output Type set to On/Off. The spread is in the channel’s engineering units. Range: same as the range of the input type selected. See Table 3.14 on page 130. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 147 Heat/Cool Scale Lo Set this parameter in conjunction with Heat/Cool Scale Hi to scale the output or to change the control action. (See table 3.x.) Enter the value, as a percent of range, that the output should approach as the process variable approaches the set point from below for a heat output or from above for a cool output.
  • Page 148 Figure 3.x Heat and Cool Scaling Parameters Set Point + Cool Prop Band Cool Scale Hi Cool Cool Scale Lo Set Point Heat Scale Lo Heat Set Point - Heat Prop Band Heat Scale Hi Time As the process As the process As the process As the process variable increases...

  • Page 149: Figure 3.14-Alarms Spreadsheet

    (PV) rises above the HP Limit. The PV must drop below the HP Limit minus the alarm deadband to be reset (cleared). When this parameter is set to Disabled, the high process alarm does not occur. Range: Enable or Disable Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 150 The same output may not be used for multiple alarm output destinations. Range: Not Assigned, or any of the digital outputs on the DigI/O spreadsheet, or any of the Soft Bool registers. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 151 Range: same as the range of the input type selected. See Table 3.15 on page 130. LP Type Select the function of the low process alarm. See Process Alarms on page 95 for a description of the settings. Range: Alarm or Control Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 152 The alarm delay applies to failed sensor alarms and process and deviation alarms. Only alarms that are present for longer than alarm delay time are reported. Range: 0 to 100 seconds Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 153: Figure 3.15-Inputs Spreadsheet

    1, and input #3. For a description of module addresses, see Module Addresses on page 17 for a table that correlates the module I/O numbers with screw terminals on the AITB, see Table 2.13 on page 48. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 154: Figure 3.17-Pulse Input Names

    Channel outputs are treated as raw inputs and are scaled and filtered according to the input parameter settings. Figure 3.19 on page 129 illustrates how channel output names appear in the spreadsheet settings. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 155: Figure 3.19-Channel Output Names

    Input Type Choose the input type appropriate for the sensor connected to the corresponding input. Table 3.14 lists the choices available. Select No Input if no sensor is attached to the input. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 156 S T/C -58°F 3215°F T T/C -454°F 752°F F T/C (Platinel2) 32°F 2250°F G T/C 32°F 4200°F RTD 100 Ohm Plat -418°F 521°F RTD 100 Ohm Plat High -418°F 1562°F 100K Ohm Thermistor -25°F 327°F Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 157: Table 3.16-Units

    For counter inputs, the value set here is loaded as the Input Value when it is entered. Enter 0 to reset a counter. Range: -32768 to 32767 (Decimal placement depends on Input Type selected). Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 158: Digital I/O

    Digital I/O Parameters on the Dig I/O spreadsheet determine the state and behavior of digital or discrete inputs and outputs found on the PPC’s processor and digital I/O modules. Figure 3.20 Dig I/O Spreadsheet Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 159: Figure 3.21-Ppc-2010 And Ppc-204X Digital I/O Names

    Figure 3.21 PPC-2010 and PPC-204X Digital I/O Names PPC1: DO 41.2 module I/O number module address module type controller number Figure 3.22 PPC-206X and PPC-207X Digital I/O Names Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 160: Table 3.18-Function Values

    Output not used for control or alarm Heat/Cool Output Dest Output selected in Control Output Channels field on the spreadsheet. LP, LD, HD HP Output Dest Selected in Alarm Output Alarms field on the spreadsheet. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 161: Figure 3.23-Outputs Spreadsheet

    Figure 3.24 Analog Output Names Table 3.19 Module Abbreviations Seen on the Outputs Spreadsheet Module Type Abbreviation PPC-2030 Encoder Input Analog Output EIAO PPC-205x Analog Output There is only one parameter on the Outputs spreadsheet: Value. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 162: Soft Integer

    The registers are all read/ write, but if a register is set as an output in the logic program, the logic program updates its value and user entered values are disregarded. Range: -32768 to 32767 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 163: Soft Boolean

    The registers are all read/write, but if a register is set as an output in the logic program, the logic program updates its value and user entered values are disregarded. Range: False (0) or True (1) Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 164: Figure 3.27-Ppc Globals Screen

    Note that the channel numbers associated with a given cold junction reference depend on whether the card is single-ended or differential. Table 2.13 on page 48 correlates the terminals with the input number. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 165: Table 3.20-System Status

    Logic Start State present, runs when the PPC is powered up or reset Determines the input scan duration and DZC AC Frequency output time base. Set this parameter equal to the AC line frequency. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 166 Program Version The Program Version is an embedded program version label for the firmware program. This selection is read-only. View the program version by selecting About from the Help menu. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 167: Troubleshooting

    This is an open collector type output (up to 100mA) and will sink current to common when the processor is operating properly. An open circuit indicates a processor failure and remains open until proper operation is established. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 168 Remove the PPC-2000 system from the DIN rail or panel. Make sure the red top and bottom module latches on the processor module are in the unlocked position (pushed toward the back of the module.) Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 169 Use a PLCC extractor tool or insert a small flat blade screwdriver into one of the notches at the corner of the socket and gently pry the flash memory chip out of the socket. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 170: Figure 4.3-Ppc-2010 Internal View

    13. Reconnect cables. 14. Power the unit. 15. Download the Snapshot from AnaWin3 and reload the logic program from LogicPro, if necessary. Battery Flash Memory Chip (firmware) Notch Notch Figure 4.3 PPC-2010 Internal View Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 171: Figure 4.4-Ppc Assembled Modules Top View

    Make sure the red top and bottom module latches on the processor module are in the unlocked position (pushed toward the back of the module.) Back Module latch (unlocked) Module latch (locked) Front Figure 4.4 PPC Assembled Modules Top View Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 172: Figure 4.5-Ppc Assembled Modules Bottom View

    + and – terminals. Replace battery with Duracell DL2032 (3 volt) only; contact Watlow Anafaze. Use of another battery may present a risk of fire or explosion. See Battery Safety on page 11 for safety instructions.

  • Page 173: Processor Module Leds

    Error 1 Orange LED on: Indicates low battery or low voltage from the power supply. Corrective Actions: Check to make sure the voltage on the power supply is 12 to 28Vdc. Replace the battery. See Battery Installation Procedures on page 145. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 174 If the 10V reference on the AITBs are used to power an ex- ternal circuit (i.e., bridges, etc.) make sure the total current required does not exceed the specified limit. Refer to Chapter 7, Specifications for current information. These conditions will not harm the voltage source. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 175 Check all interconnects (terminal blocks and SCSI con- nector). Check the input configuration in the AnaWin3 software. Refer to Chapter 3, Software Setup for configuration infor- mation. Incorrect sensor type or wrong channel setup could be seen as incorrect data retention. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 176 Ensure connections to terminal blocks are correct. Refer to Analog Output Connections on page 60 for analog output wiring. Be sure the software configuration matches the hardware setup. Check that the jumpers are set correctly. See PPC-2030 Jumper Settings on page 20. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 177: Ppc-2040 Digital I/O

    Check the load on the outputs to make sure that none of them exceeds 150mA. Check to make sure the I/O wiring is correct. See Con- necting I/O to the PPC-2040 on page 61. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 178 Check to make sure the I/O wiring is correct. See Con- necting Analog Outputs to the PPC-205x on page 67. Check that the jumpers are set correctly. See PPC-205x Jumper Settings on page 22. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 179: Ppc-207X Digital In

    • Green Status LED is blinking but inputs are not working correctly: Corrective Actions: Check to make sure the I/O wiring is correct. See Con- necting Digital Inputs to the PPC-207x on page 74. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 180: Troubleshooting And Corrective Actions

    PPC-2010 on page 37, Connecting Analog Inputs to the PPC-2021 — 2025 on page 45, Connecting Encoders and Analog Outputs to the PPC-2030 on page 55, or Connecting to the Relay Outputs on the PPC-206x on page 70. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 181: Communications

    Is the RS-232/485 converter working properly? If one of the programmable communications parameters may have changed, establishing communications by following these steps will demonstrate that all the components are functioning and connections are correct: Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 182: Resetting Closed-Loop Control Parameters

    Make a record of all settings you may wish to restore before performing this procedure. After performing the following procedure, refer to Setting Programmable Modbus Addresses on page 87, if necessary, to reprogram the Modbus address or baud rate. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 183: Disabling Control

    Power up the PPC-2000 system. Set channels to the desired control modes to begin closed- loop control. Click the Start Logic button on the PPC Globals screen to start the logic program, if desired. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 184 Chapter 4: Troubleshooting PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 185: Logicpro And Modbus Reference

    2.0 (released 9/1/99) and later. This chapter provides information needed to address parameters when writing programs using LogicPro. For instructions on operating the Watlow Anafaze software, AnaWin3, with your PPC system, refer to Chapter 3, Software Setup. Text Conventions in the Database Sections Table 5.1 shows the parameter names and abbreviations as...

  • Page 186: The Ppc-2000 Database

    Input Filter. Each row holds the settings of each of these parameters for a particular analog input. Table 5.2 Example Database Table Input Value Input Type Input Filter Input 1 2089 Input 2 2089 2089 Input 3 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 187: Data Table Organization

    -32,768 to 32,767. Software interfaces may read but not write the values stored in these registers. The PPC-2000 uses these registers to store analog and encoder input values. The Modbus addresses for the input registers range from 30001 to 39999. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 188: How Logicpro Accesses The Database

    LogicPro address. Instead, the parameter number and database offset range for each parameter are supplied. Individual registers are addressed by coupling the parameter number and the database offset corresponding to the particular input, output, or channel. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 189: Analog And Counter Input Parameters In The Database

    56, Table 2.16 on page 56, and Table 2.19 on page 60. When a logic program variable accesses an analog input parameter, the parameter number (#) and the Database Offset are used in conjunction with LogicPro’s Database IO Driver. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 190: Analog Input Numbers And Address Offsets

    Use this address with the Database IO Driver when addressing input parameters other than Input Value. Replace the # with the parameter number (#) from Table 5.8 on page 168 for the parameter you want to address. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 191: Table 5.4-Addresses For Encoder Inputs On The Ppc-2030 Encoder In Analog Out Module

    Use this address with the Database IO Driver when addressing input parameters other than Input Value. Replace the # with the parameter number (#) from Table 5.8 on page 168 for the parameter you want to address. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 192 Use this address with the Database IO Driver when addressing other input parameters. Re- place the # with the parameter number (#) from Table 5.8 on page 168 for the parameter you want to address. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 193: Table 5.7-Addresses For Encoder Inputs On The Ppc-2040 Digital I/O Modules

    Use this address with the Database IO Driver when addressing input parameters other than Input Value. Replace the # with the parameter number (#) from Table 5.8 on page 168 for the parameter you want to address. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 194: Analog And Encoder Input Parameters

    Input Signal High 44151-44550 1036-11C5 See Table 5.11 +32767 Process -32768 to 43751-44150 EA6-1035 Variable Low +32767 Process -32768 to 43351-43750 D16-EA5 Variable High +32767 PV Offset/ -32768 to 44951-45350 1356-14E5 Counter Reset +32767 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 195: Table 5.9-Input Status

    6 and the Input Value register contains a value of 2506, the actual measure value is 25.06mV because the values in the register are in units of hundredths of a millivolt. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 196 J T/C without open detection -3460 to 15980 0.1°F K T/C without open detection -4540 to 22490 0.1°F RTD, 100 Ohm Plat -4180 to 5210 0.1°F RTD, 100 Ohm Plat High -4180 to 15620 0.1°F Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 197: Table 5.11-Temperature Scale Conversion

    The units and range for this parameter correlate to the selected Input Type. See Table 5.9. See Setting Input Signal Lo and Input Signal Hi on page 99 for detailed information. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 198: Channel Parameters In The Database

    Heat Proportional Band is stored at address 43102, and so on. Table 5.12 on page 174 lists first and last Modbus addresses for each channel parameter. Use these addresses when accessing channel parameters with third-party software or operator interface terminals. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 199: Accessing Channel Parameters With Logicpro

    While all the channel parameter values are 16-bit integers, many, such as Control Mode, are numerical representations of settings that have special meanings to the controller. See the tables under the corresponding parameter descriptions for explanations of the possible settings. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 200 See Table 5.21 on page 184 See Table 5.21 on page 184 Cool Curve 41451-41500 5AA-5DB Auto Heat Limit 0-1000 40801-40850 320-351 Auto Cool Limit 0-1000 41351-41400 546-577 Heat Limit Time 0-32767 40851-40900 352-383 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 201 A value of 0 indicates a channel with no input. See Table 5.13 on page 176 through Table 5.17 on page 179 for a list and explanation of input numbering. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 202: Table 5.13-Process Variable And Setpoint Source Settings For Analog Inputs On The Ppc-202X Modules

    Settings for Analog Inputs on the PPC-202x Modules Input Name Value (AnaWin3 Input Spreadsheet) PPC1:AI 1.1 PPC1:AI 1.2 PPC1:AI 1.32 PPC1:AI 2.1 PPC1:AI 2.2 PPC1:AI 2.32 PPC1:AI 3.1 PPC1:AI 3.2 PPC1:AI 3.32 PPC1:AI 4.1 PPC1:AI 4.2 PPC1:AI 4.32 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 203 PPC1:EIAO 13.1.3 C PPC1:EIAO 13.2.3 F PPC1:EIAO 13.1.4 C PPC1:EIAO 13.2.4 F PPC1:EIAO 14.1.1 C PPC1:EIAO 14.2.1 F PPC1:EIAO 14.1.2 C PPC1:EIAO 14.2.2 F PPC1:EIAO 14.1.3 C PPC1:EIAO 14.2.3 F PPC1:EIAO 14.1.4 C PPC1:EIAO 14.2.4 F Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 204: Table 5.16-Process Variable And Setpoint Source Settings For Soft Input And Channel Out Registers

    Settings for Soft Input and Channel Out Registers Input Name Value (AnaWin3 Input Spreadsheet) PPC1:Soft Input 1 PPC1:Soft Input 2 PPC1:Soft Input 48 Reserved Reserved PPC1:Channel 1 Out PPC1:Channel 2 Out PPC1:Channel 48 Out Reserved Reserved Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 205 This register contains the actual value measured by the sensor attached to the input set as the Process Variable Source for the channel (see above). The process variable is used in the channel’s feedback calculation. This register is read-only. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 206: Table 5.18-Control Mode

    The integral term controls the amount of influence the history of error has on the output. Increasing the integral value decreases the integral contribution to the output. Zero is a special case that disables integral action. This value is in seconds per repeat. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 207: Table 5.19-Control Types

    Control Types Value AnaWin3 Name Description Heat and Cool outputs, only one PID1 on at a time. Heat and Cool outputs, both may PID2 be on. Reserved Retransmit one or two analog Retransmit inputs Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 208 This parameter specifies the type of output signal and determines whether the PID or on/off control algorithm is used for the channel. See Table 5.20 on page 183. For specific information on control terminology and definitions, refer to Chapter 6, Control Terminology. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 209 SDAC 0-5Vdc log converter, 0- PPC-2010 module 5Vdc connected to a peripheral SDAC module. Serial digital-to-ana- SDAC 1-5Vdc log converter, 1- 5Vdc Serial digital-to-ana- SDAC 0-10Vdc log converter, 0- 10Vdc Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 210 Output is unaffected and is set as Straight lin- calculated by the closed-loop PID calculation. Output is reduced somewhat from Lag curve A calculated value. Output is further reduced from Lag curve B calculated value. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 211 Heat/Cool Scale Lo Set this parameter in conjunction with Heat/Cool Scale Hi to scale the output or to change the control action. (See table 3.x.) Enter the value, as a percent of range, that the output should approach as the process variable approaches the set point from below for a heat output or from above for a cool output.
  • Page 212 Figure 3.x Heat and Cool Scaling Parameters Set Point + Cool Prop Band Cool Scale Hi Cool Cool Scale Lo Set Point Heat Scale Lo Heat Set Point - Heat Prop Band Heat Scale Hi Time As the process As the process As the process As the process variable increases...

  • Page 213: Figure 5.2-Output Scaling Curves

    Manual control at this percent power output. The valid range is 0 to 1000 and corresponds to 0.0% to 100.0%: for example, a setting of 500 corresponds to 50.0%. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 214: Table 5.22-Output Destinations For Digital Outputs On The Ppc-2010 Module

    Table 5.22 for a list of values and the corresponding physical or software output destinations. Table 5.22 Output Destinations for Digital Outputs on the PPC-2010 Module Digital I/O Name Value (AnaWin3 Dig I/O Spreadsheet) PPC1:Proc 0.0.1 PPC1:Proc 0.0.2 PPC1:Proc 0.0.48 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 215 PPC1:DIO 21.0.2 PPC1:DIO 21.0.32 PPC1:DIO 22.0.1 PPC1:DIO 22.0.2 PPC1:DIO 22.0.32 PPC1:DIO 23.0.1 PPC1:DIO 23.0.2 PPC1:DIO 23.0.32 PPC1:DIO 24.0.1 PPC1:DIO 24.0.2 PPC1:DIO 24.0.32 PPC1:DIO 25.0.1 PPC1:DIO 25.0.2 PPC1:DIO 25.0.32 PPC1:DIO 26.0.1 PPC1:DIO 26.0.2 PPC1:DIO 26.0.32 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 216 PPC1:DO 41.2 PPC1:DO 41.16 PPC1:DO 42.1 PPC1:DO 42.2 PPC1:DO 42.16 PPC1:DO 43.1 PPC1:DO 43.2 PPC1:DO 43.16 PPC1:DO 44.1 PPC1:DO 44.2 PPC1:DO 44.16 PPC1:DO 45.1 PPC1:DO 45.2 PPC1:DO 45.16 PPC1:DO 46.1 PPC1:DO 46.2 PPC1:DO 46.16 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 217: Table 5.26-Output Destinations For Analog Outputs On The Ppc-205X Modules

    PPC1:AO 31.1 1018 PPC1:AO 31.2 1024 PPC1:AO 31.8 1025 PPC1:AO 32.1 1026 PPC1:AO 32.2 1032 PPC1:AO 32.8 1033 PPC1:AO 33.1 1034 PPC1:AO 33.2 1040 PPC1:AO 33.8 1041 PPC1:AO 34.1 1042 PPC1:AO 34.2 1048 PPC1:AO 34.8 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 218: Table 5.28-Alarm Status

    When the alarm condition clears, the controller sets the bit back to 0. Table 5.28 summarizes these definitions. See Table 5.29 on page 191 for alarm bit definitions. Table 5.28 Alarm Status Value Condition No alarm condition exists Alarm condition exists Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 219 Control bit to 1 makes the corresponding alarm behave as a control. Setting a bit to 0 makes it behave as a standard alarm. Table 5.30 on page 192 describes the difference between standard alarms and controls. See Table 5.29 for alarm bit definitions. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 220 Table 5.32 Alarm Enable/Disable Value Description Disable Enable NOTE! The range and precision of the process limits and deviation offsets are the same as that of the corresponding input. See Table 5.10 on page 170. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 221 The deadband is set in the engineering units of the channel. The default alarm deadband is 2. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 222 Choose the digital output that is toggled when the low deviation alarm occurs. This may be any available hardware output or a Boolean register accessible to the logic program. The default alarm output is 0. When 0 is selected there is no output. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 223: State And Logic

    03002, and so on. Table 5.38 on page 200 lists first and last Modbus addresses for each digital I/O parameter. Use these addresses when accessing digital I/O parameters with third-party software or operator interface terminals. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 224: Digital I/O Numbers And Address Offsets

    Use this address with the Database IO Driver when addressing input parameters other than State. Replace the # with the parameter number (#) from Table 5.38 on page 200 for the pa- rameter you want to address. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 225 Use this address with the Database IO Driver when addressing digital I/O parameters other than State. Replace the # with the parameter number (#) from Table 5.38 on page 200 for the parameter you want to address. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 226 Use this address with the Database IO Driver when addressing digital I/O parameters other than State. Replace the # with the parameter number (#) from Table 5.38 on page 200 for the parameter you want to address. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 227 I/O points are reserved for the global alarm and CPU fail/ system OK signals. Some I/O points can be used for frequency or counter inputs or serial digital-to-analog (SDAC) outputs. Refer to Table 5.37 on page 200 for specific information. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 228: Digital I/O Parameters

    I/O point configured as an input. Table 5.39 on page 201 lists and describes possible combinations of State and Logic values. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 229: Table 5.40-Direction

    5.37 on page 200 for restrictions on particular I/O points. Table 5.40 Direction Value State Input Output Logic Specify the active, true level (On state) for each system digital output. Table 5.41 Logic Value State 1=On 0=On Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 230: Accessing Analog Outputs With Modbus

    Analog Outputs and Modbus Addresses Table 5.42 and Table 5.43 list the LogicPro I/O physical address and Modbus address for each Analog Output Value corresponding to the modules, module addresses and module output numbers of each analog output. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 231 135 for a full explanation of analog output naming. Use this address with the Encoder_Analog_2030 IO Driver when addressing Analog Output Val- ue. There are no other analog output parameters so you will not use the Database IO Driver . Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 232 The resolution of the analog outputs is 12 bit. The output Value is displayed as a 15-bit integer. The output Value must change by more than seven to effect a measurable change in an analog output. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 233: Soft Bool And Soft Int Registers In The Database

    Modbus addresses for the Boolean and integer registers. These values are used when accessing Boolean and Integer registers with third-party software, operator interface terminals or LogicPro programs. Table 5.45 Soft Bool Values Value AnaWin3 Value False True Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 234: Global Parameters In The Database

    209 list first and last Modbus address for the global parameters. Use Modbus addresses when accessing global parameters with third-party software or operator interface terminals. See the parameter descriptions for addressing details. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 235: Communications Parameters

    Parameter settings can be lost. See Chapter 4, Troubleshooting, for more on these switch settings. Table 5.47 Rotary Switch Configuration Position Network Address Fixed: 1 Fixed: 2 Fixed: 3 Programmable, Default: 4 Fixed: 1 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 236: Table 5.48-Communications Parameters

    Port 1 Port 2 Table 5.50 Baud Rate Value Baud Rate 9600 9600 19200 19200 Address This is the Modbus communications network address to which the PPC will answer on ports 1 and 2. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 237: Global Database Parameters

    Full Scale The values stored in the Full Scale registers are the readings from the high voltage references. These readings are used in conjunction with the zero reference readings to scale the analog input readings. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 238 -1 to 10V -0.5 to 5V -0.1 to 1V -50 to 500mV -10 to 100mV -5 to 50mV -1 to 10V -0.5 to 5V -0.1 to 1V -50 to 500mV -10 to 100mV -5 to 50mV Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 239 Type of Module Module number (rotary switch address) 0-14 Number of digital inputs 0-48 Number of digital outputs 0-48 Number of analog inputs 0-32 Number of analog outputs Number of frequency / counter inputs Reserved Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 240: Table 5.57-Module Types

    Some command bits are executed and reset to 0 by the controller immediately after a host writes a 1. Other command bits are latched in whatever state was last written. Table 5.58 lists each type. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 241 1=Start control loops from last mode stored in memory. 0=60Hz 04060 Latched Frequency 1=50Hz 0=Start logic program when commanded. Logic Star- 04061 Latched 1=Start logic program on star- tup. 04062 Reset PPC Reset Reset controller Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 242 The values of the bits in the System Status Registers are interpreted according to the following table: Table 5.60 System Status Bits Value Status no error / false error / true Program Version Embedded program version label for the firmware program. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 243 Register 33052 contains the oldest change logged, 33053 contains the second oldest and so on. After the host reads the register(s), the data is cleared and shifted in the FIFO stack. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 244 The first register contains a total count of system errors. The last register contains a number of unidentified or illegal error codes logged. Refer to Table 5.62 on page 217. The counts stop incrementing at 255. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 245 Bad Modbus packet length 33308 Bad Address Bad Modbus register address 33311 Missed I/O Update Internal error: missed I/O update deadline 33329 Bad Error Msg Internal error: attempted to post error of 128 or greater Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 246 The values for day of the week are not predefined. They are in- cremented with the date. The user chooses what day equals a val- ue of one, and the rest of the day values follow. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 247: Tuning And Control

    This chapter explains PID control and supplies some starting PID values and tuning instructions to help appropriately set control parameters in the PPC system. For more information on PID control, consult the Watlow Anafaze Practical Guide to PID. The control algorithm dictates how the controller responds to an input signal.

  • Page 248: Control Algorithms

    On/Off control turns an output on or off when the process variable reaches limits around the desired setpoint. This limit is adjustable; Watlow Anafaze controllers use an adjustable spread. For example, if the set point is 1000°F, and the spread is 20°F, the heat output switches On when the process variable drops below 980°F and Off when the process rises above 1000°F.

  • Page 249: Figure 6.2-Proportional Control

    However, a process which uses only proportional control settles at a point above or below the setpoint; it never reaches the setpoint by itself. This behavior is known as offset or droop. offset Figure 6.2 Proportional Control Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 250: Figure 6.3-Proportional And Integral Control

    Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 251: Figure 6.4-Proportional, Integral And Derivative Control

    Use derivative control to reduce the overshoot and oscillation of the process variable common to PI control. Figure 6.4 shows a process under full PID control. Figure 6.4 Proportional, Integral and Derivative Control Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 252: Output Control Forms

    10 seconds, then the output will be on for 3 seconds and off for 7 seconds. Figure 6.5 shows example TP and Distributed Zero Crossing (DZC) waveforms. Figure 6.5 Example Time Proportioning and Dis- tributed Zero Crossing Waveforms Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 253: Output Filter

    PB to be used, achieving better control. Also, use the digital filter to reduce the process output swings and output noise when a large derivative is necessary, or to make badly tuned PID loops and poorly designed processes behave properly. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 254: Proportional Band (Pb) Settings

    The controller’s Integral parameter is set in seconds per repeat. Some other products use an integral term called Reset, in units of repeats per minute. Table 6.2 on page 227 shows Integral settings versus Reset settings. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 255: Derivative Settings

    While the basic PID algorithm is well defined and widely recognized, various controllers implement it such that parameters may not be taken from one controller and applied to another with optimum results even if the above unit conversions are performed. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 256: General Pid Constants By Application

    Electrical heat with SSR 50°F Electrical heat with EM relays 50°F Cool w/ solenoid valve 70°F Cool w/ fans 10°F Electric heat with open heat coils 30°F 60°F Gas heat w/ motorized valves Analog SP>1200 100°F Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 257: Specifications

    Table 7.1 Safety and Agency Approvals 3121-1 Listed, Category II Installation, File # E212113 C-UL CE Safety EN 61010-1 CE EMC EN 61326, EN 55011 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 258: Physical Specifications

    8.895 in. 9.390 in. 9.850 in. 10.345 in. 10.805 in. 11.300 in. 11.760 in. Power Specifications See Chapter 2, Power Supply Requirements on page 13 to determine the power requirements for a PPC-2000 system. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 259: Ppc-2010 Processor Specifications

    Power / Error LEDs Serial Port 1 Rotary Address Switch RS-485 Connector RS-232 Connector Serial Port 2 RS-485 Connector RS-232 Connector Figure 7.2 PPC-2010 Front View Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 260 0 to 60°C (32º to 140°F) Humidity 10 to 95% non-condensing Table 7.5 Physical Specifications Weight 0.82 lbs 0.37 kg Height 8.0 in. 203 mm Width, including endcaps 3.2 in. 81 mm Depth 5.25 in. 133 mm Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 261: Table 7.7-Power Specifications

    IEC1131-3 compliant Ladder Programming Language Diagram, SFC, and FBD 7 logic instructions, 42 applied Number of Instructions instructions Logic Program Storage Flash memory Logic Programming Software LogicPro Operating System for Programming Windows95/98, Software WindowsNT Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 262 Voltage Limiting and Protection 40Vdc Voltage Levels <0.6 = Low; 3.8V = High 0.5mA from processor with Max. Input Current input at 0V Max. Switch Resistance to Pull Input 1 kOhm Min. Switch Off Resistance 27 kOhm Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 263: Table 7.12-Digital Output Specifications

    RS-485: RJ12 6 position, 6 conductor Isolation 40Vdc working, ± 200Vdc peak Baud Rate 19200 default, configurable 9600 or 19200 Error Check # of Controllers 1 with RS-232; 32 with RS-485 Protocol Modbus RTU Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 264 PPC-2000 User’s Guide PPC-2021 - 2025 Analog In/Analog In High Isolation Specifications Status / Error LEDs Rotary Address Switch Figure 7.4 PPC-2021 Front View 50-pin SCSI Connector Figure 7.5 PPC-2021 - 2025 Bottom View Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 265: Table 7.14-Model Numbers

    Table 7.17 Connections Connector on Module SCSI-2 female Table 7.18 Power Specifications Power Requirement 4.7 W typical Current (@ 12Vdc) 390mA typical @ 25°C Current (@ 24Vdc) 195mA typical @ 25°C Modules per Processor Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 266 Sample Rate @ 60 Hz, PPC-2022 666 msec to sample all 32 channels (1.5 Hz) Sample Rate @ 60 Hz, PPC-2024 220 msec to sample all 8 channels (4.5 Hz) *Not applicable to PPC-2022 Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 267 -454 to 752°F (-270 to 400°C) ±0.07°F (±0.04°C) ±2.1°F (±1.2°C) -24.78°F to 327°F ±0.01°F Thermistor 100K Ohm ±0.08°F (±0.04°C) (-31.54 to 163.89°C) (±0.006°C) Table 7.21 Sensor Reference Voltage Output Voltage 10Vdc ± 0.3Vdc @ 25°C Maximum Current 20mAdc Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 268: Figure 7.6-Ppc-2030 Front View

    15-pin HD connectors and two analog output connections with two, 4-position plug type connectors. Each signal has a dedicated return. Status PPC-2030 4 ENCODER IN 4 ANALOG OUT STATUS Rotary Address MODULE Switch PXX-XXXXX Figure 7.6 PPC-2030 Front View Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 269: Figure 7.7-Ppc-2030 Bottom View

    Operating Temperature 0 to 60ºC Humidity 10 to 95% non-condensing Table 7.24 Physical Specifications Weight 0.62 lbs 0.28 kg Height 8.0 in. 203 mm Width 1.5 in. 38 mm Depth 5.25 in. 133 mm Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 270 2.0 V Pulse Input Voltage Range: ±14.0 max., 0.0 to 5.0V Differential nominal Input Current: Single-ended ± 1.0mA Input Current: Differential ± 3.0mA Count Range 16 bits Power for Encoders 5V @ 240mA max. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 271: Table 7.29-Safety And Agency Approvals

    (400 Ohm load) 1.5% of reading Accuracy (Current Mode) ± 0.2% of range at 25°C Output Update Time 0.1 sec. Table 7.29 Safety and Agency Approvals 3121-1 Listed, Category II Installation, File # E212113 C-UL Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 272: Figure 7.8-Ppc-2040 Front View

    50-pin SCSI Connector Figure 7.8 PPC-2040 Front View Table 7.30 Model Number PPC-2040 Digital I/O Table 7.31 Environmental Specifications Storage Temperature -20 to 70ºC Operating Temperature 0 to 60ºC Humidity 10 to 95% non-condensing Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 273: Table 7.32-Physical Specifications

    Sample Rate 250 ms (4 Hz) Pulse Input Voltage Range: <0.6 = Low; 3.8V = High Single-ended Maximum Current 0.5mA from module with input at 0V Input Resistance 6 kOhms Min. Count Range 16 bits Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 274 Maximum Voltage 24Vdc Maximum Current 150mA sink to common Off State Leakage Current <0.010mA up to 30Vdc *The PPC-2040 has 32 digital I/O points. Each can be configured as either an input or an output. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 275: Ppc-205X Analog Out Specifications

    PPC-205x Analog Out Specifications The PPC-2050 and PPC-2051 provide eight and four analog outputs, respectively. Each output is configurable as a voltage or current output. Status Rotary Address Switch Figure 7.9 PPC-2050 Front View Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 276: Figure 7.10-Ppc-2050 Bottom View

    Operating Temperature 0 to 60°C °C Humidity 10 to 95% non-condensing Table 7.40 Physical Specifications Weight 0.6 lb. 0.27 kg Height 8.0 in. 203 mm Width 1.5 in. 38 mm Depth 5.25 in. 133 mm Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 277: Table 7.41-Connections

    0 to 10Vdc @ 10mA maximum 0 to 20mA with 8V minimum compliance Current Range (400 Ohm load) Voltage Accuracy ± 0.5% of range at 25ºC Current Accuracy ± 0.8% of range at 25°C Output Update 0.1 second Time Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 278: Ppc-206X Digital Output Specifications

    Chapter 7: Specifications PPC-2000 User’s Guide PPC-206x Digital Output Specifications Status Rotary Address Switch 8/16 Relay Output LEDs Figure 7.11 PPC-206x Front View Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 279: Figure 7.12-Ppc-206X Bottom View

    0 to 60°C Humidity 10 to 95% non-condensing Table 7.47 Connections Screw Terminal Wire Gauge 24 to 12 AWG Screw Terminal Torque 0.5 to 0.6 Nm (4.4 to 5.3 in-lb.) Mounting DIN rail or panel mount Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 280 240Vac to power common or ground Contact Arrangement open in power off, fault or inactive condition 2A (PPC-2062) Maximum Load Cur- rent 1A up to 5A per common (PPC-2061) Contact Voltage Rating 240Vac, 30Vdc Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 281: Ppc-207X Digital In Specifications

    The PPC-207x modules provide 8 or 16 digital inputs. The 2070 and 2071 accept 120Vac signals. The 2072 and 2073 accept 24Vac or 24Vdc signals. Status Rotary Address Switch Input LEDs Figure 7.13 PPC-2070, PPC-2071 Front Views Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 282: Figure 7.14-Ppc-207X Bottom Views

    Operating Temperature 0 to 60°C Humidity 10 to 95% non-condensing Table 7.53 Physical Specifications Weight 0.52 lbs 0.24 kg Height 8.0 in. 203 mm Width 1.5 in. 38 mm Depth 5.25 in. 133 mm Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 283: Table 7.54-Connections

    64 ms (12-20Vac PPC-2072,2073) 77 kOhms (PPC-2070, 2071) Input Impedance 16.9 kOhms (PPC-2072, 2073) Input Current 1.5mA (typical) @ 120Vac or 24Vac/dc Switch Resistance to Pull 1 kOhms Maximum Switch Resistance for High 27 kOhms Minimum Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 284: Figure 7.15-Ppc-Aitb-1

    Operating Temperature 0 to 60°C Humidity 10 to 95% non-condensing Table 7.58 Physical Specifications Weight 0.5 lbs 0.22 kg Height 5.1 in. 130 mm Width 4.2 in. 107 mm Depth 2.3 in. 58 mm Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 285: Figure 7.16-Ppc-Aitb Dimensions With Straight Scsi Cable

    2.0 in. (51 mm) 5.10 in. H (130 mm) 4.70 in. (119 mm) 2.3 in. D (58 mm) 2.6 in. (66 mm) 4.2 in. W (107 mm) Figure 7.16 PPC-AITB Dimensions with Straight SCSI Cable Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 286: Ppc-Eitb-1 Encoder Input Terminal Block Specifications

    RTDs (differential) PPC-EITB-1 Encoder Input Terminal Block Specifications 4.0 in. H (102 mm) 1.5 in. D (38 mm) 3.4 in. (86 mm) 1.6 in. (41 mm) 2.0 in. W (51 mm) Figure 7.17 PPC-EITB-1 Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 287: Table 7.62-Environmental Specifications

    PPC-EITB with HD-Type Cable Height 4.0 in. 102 mm Width 2.0 in. 51 mm Depth 2.2 in. 56 mm Table 7.66 Safety and Agency Approvals 3121-1 Listed, Category II Installation, File # E212113 C-UL Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 288: Figure 7.18-Ppc-Eitb Dimensions With Hd-Type Cable

    2.2 in. H (56 mm) 4.0 in. L (102 mm) 1.5 in. D (38 mm) 3.4 in. (86 mm) 1.6 in. (41 mm) 2.0 in. W (51 mm) Figure 7.18 PPC-EITB Dimensions with HD-Type Cable Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 289: Ppc-Tb50-Scsi, 50-Pin Specifications

    Operating Temperature 0 to 60°C Humidity 10 to 95% non-condensing Table 7.68 Physical Specifications Weight 0.32 lbs. 0.14 kg Height 4.1 in. 104 mm Width 4.0 in. 102 mm Depth 1.45 in. 37 mm Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 290: Figure 7.20-Ppc-Tb50-Scsi Dimensions With Straight Scsi Cable

    163 mm Width 4.0 in. 102 mm Depth 1.45 in. 37 mm 6.4 in. H (163 mm) 4.0 in. W 1.5 in. D (102 mm) (38 mm) Figure 7.20 PPC-TB50-SCSI Dimensions with Straight SCSI Cable Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 291: Figure 7.21-Ppc-Tb50-Scsi Dimensions With Right-Angle Scsi Cable

    137 mm Width 4.0 in. 102 mm Depth 1.5 in. 3.7 mm 5.4 in. H (137 mm) 4.0 in. W (102 mm) 1.5 in. D (38 mm) Figure 7.21 PPC-TB50-SCSI Dimensions with Right-Angle SCSI Cable Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 292: Figure 7.22-Ppc-Ips-2

    Chapter 7: Specifications PPC-2000 User’s Guide PPC-IPS-2 International Power Supply Specifications Watlow Anafaze offers a dual output power supply for PPC- 2000 systems. The PPC-IPS-2 accepts worldwide AC voltages and outputs 5 and 24Vdc 2.5 in. min. Air Flow Space 1.2 in.

  • Page 293: Sdac Specifications

    CE EMC EN 55022 SDAC Specifications Watlow Anafaze offers a Serial DAC for precision open-loop control. The SDAC is jumper selectable for a 0-10Vdc or 4-20mA output. Multiple SDAC modules can be used with one PPC system. The SDAC carries a CE mark.

  • Page 294: Inputs

    The SDAC requires a proprietary serial data signal and the clock signal from the PPC-2010 via the TB50. Any control output can be configured to provide the data signal. The SDAC also requires a 5Vdc power input. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 295: Analog Outputs

    Once per controller A/D cycle nominal. Twice per second maximum for 60 Hz clock rate. Update Rate Output changes are step changes due to the fast time constant. All SDAC loop outputs are updated at the same time. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 296 Chapter 7: Specifications PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 297: Appendix A: Modbus Protocol

    Appendix A: Modbus Protocol Watlow Anafaze offers a modbus driver (.DLL) for use with user-written Windows-based software applications that communicate with the PPC-2000. Using that driver makes it unnecessary for the programmer to understand and implement the modbus protocol. PPC-2000 serial communications use the Modbus RTU protocol.

  • Page 298: Query

    The error check field allows the master to confirm that the message contents are valid. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 299: Message Framing

    An example message frame is shown in Table A.1. Table A.1 Example Message Frame Start Address Function Data Check T1-T2-T3-T4 8 Bits 8 Bits n X 8 Bits 16 Bits T1-T2-T3-T4 Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 300: Address Field

    The master device’s application program has the responsibility of handling exception responses. Typical processes are to post subsequent retries of the message, to try diagnostic messages to the slave, and to notify operators. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 301: Data Field

    (left to right): Least Significant Bit (LSB)..Most Significant Bit (MSB) The bit sequence is: • With Parity Checking Start Parity Stop • Without Parity Checking Start Stop Stop Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 302: Parity Checking

    For example, if Odd Parity checking is used, and two 1 bits are dropped from a character containing three 1 bits, the result is still an odd count of 1 bits. Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 303: Crc Checking

    The final contents of the register, after all the bytes of the message have been applied, is the CRC value. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 304: Table A.2-Function Codes

    Preset Single Register 06 Presets a value into a single holding register (4X reference). When broadcast, the function presets the same register reference in all attached slaves. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 305 Mode, a normal response is returned. This occurs before the restart is executed. Subfunction Data Field (Query) Data Field (Response) 00 01 00 00 Echo Query Data 00 01 FF 00 Echo Query Data Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 306 The response data field returns the quantity of messages that the slave has detected on the communications system since its last restart, clear counters operations, or power-up. Subfunction Data Field (Query) Data Field (Response) 00 0B 00 00 Total Message Count Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 307 (neither a normal response nor an exception response), since its last restart, clear counters operation, or power-up. Subfunction Data Field (Query) Data Field (Response) 00 0F 00 00 Slave No Response Count Doc.# 30002-00 Rev 2.3 Watlow Anafaze...

  • Page 308: Read Examples

    Reading PV of loop 2 (1600), controller 1 (single point read) Reading loops 4 & 5 (primary) out- put% (50%, 60%), of controller 3 Reading digital input 4 to 13, controller 1 (input status read) Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 309 Sample Packet for Slave Response Slave Address Address Data Data Example Function Address High High Writing loop 1 PB (20), controller 4 (single point write) Writing digital out- put 30 (on), con- troller 2 (single coil write) Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 310 Appendix A: Modbus Protocol PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...

  • Page 311: Appendix B: Declaration Of Conformity

    Appendix B: Declaration of Conformity Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 312 Modell-Nummern: PPC–2 (010, 02X*, 040, 05X*, 06X*, oder 07X*), PPC-AITB, PPC-TB50 *X anstelle einer Nummer 0 to 9 Klassifikation: Offenes Prozessregelsystem, Installationskategorie II, WATLOW Anafaze Verschmutzungsgrad II 314 Westridge Drive Nennspannung: 12 bis 24 VÎ (DC) Nennstromverbrauch: 50 VA max.

  • Page 313: Glossary

    Process Vari- ambient. able (PV) and the setpoint. Current The rate of flow of electricity. The unit of mea- sure is the ampere (A). 1 ampere = 1 coulomb per second. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 314 2/3 its final value within A set of compact toggle switches used to config- the numbers of scans that are set. ure electronic hardware. The toggle switches are housed in a Dual In-line Package. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 315 A signal that is tied to a set maximum value that A signal that is tied to a set minimum value that can be used as either an alarm or control function. can be used as either an alarm or control function. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 316 See PID. Proportional Control Parameters A control using only the P (proportional) value of The programmed instructions and readings that PID control. are stored in a microprocessor software. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 317 The Rotary wire RTD is a positive temperature coefficient A switch with multiple dial-in settings used to sensor only, while the thermistor can have either configure electronic hardware. a negative or positive temperature coefficient. Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 318 In other words, one volt (V) is equal to one ampere of current (I) flowing through one ohm of resistance (R), or V=IR. Watlow Anafaze Doc.# 30002-00 Rev 2.3...
  • Page 319 PPC-2000 User’s Guide Glossary Doc.# 30002-00 Rev 2.3 Watlow Anafaze...
  • Page 320 Glossary PPC-2000 User’s Guide Watlow Anafaze Doc.# 30002-00 Rev 2.3...
