- Page 1 USER'S GUIDE Installation & Operation Instructions Multi-Sensor Area Velocity Flow Meter Model AVMS 5.1 Manual Series A.1.2...
- Page 2 Note: This page has been left blank intentionally.
-
Page 3: Table Of Contents
Multi-Sensor Area Velocity Flow Meter INDEX CONNECTIONS ....................4 FUNCTION TEST ....................4 KEYPAD SYSTEM .................... 7 CALIBRATION MENU ..................8 ICONS ......................... 8 MESSAGE ICON ..................... 10 STATUS ......................10 PASSWORD ..................... 11 ... -
Page 4: Connections
Connect AVMS 5.1 to AVQZ3 using interface cable. Connect sensor to the sensor A and D terminals as shown on page 6, then apply power. Allow 30 seconds for the AVMS 5.1 to initialize. A. Place the QZ02L sensor (flat to the bottom) in a bucket of Level water about 6”... - Page 5 Multi-Sensor Area Velocity Flow Meter CONNECTIONS DATA LOGGER OPTION 4-20mA 4-20mA Connect to VELOCITY LEVEL AVQZ3 4-20 OUTPUT MODULE – – 4-20mA – FLOW HEATER OPTION RLY2 White/Green RLY1 Green USB HARNESS CONNECTOR Page 5...
- Page 6 Multi-Sensor Area Velocity Flow Meter AVQZ3 CONNECTIONS Sensor D Sensor A Sensor B Sensor C White/Green Green Page 6...
-
Page 7: Keypad System
Multi-Sensor Area Velocity Flow Meter KEYPAD SYSTEM The AVMS 5.1 uses a menu system. Arrows show the four directions to leave a menu box. Pressing a corresponding keypad arrow will move to the next item in the direction shown. Move the cursor (underline) under numerals and increase or decrease numerals with the ... -
Page 8: Calibration Menu
Multi-Sensor Area Velocity Flow Meter CALIBRATION MENU Page 8... -
Page 9: Icons
Multi-Sensor Area Velocity Flow Meter ICONS Ç Message waiting. Press Data logging Data logging USB file download. File download completed. Download Error. Echo OK. No Echo. Echo OK (PZxx series level sensor option). No Echo (PZxx series level sensor option). Page 9... -
Page 10: Message Icon
USG/m 0.000 Units/Mode The main display shows the units selected from the menu, Flow or Velocity rate being measured, TOTALIZER and RELAY states. The AVMS 5.1 will start-up with this display. 20130.8 USG Relays --Message----------- MESSAGE ICON Data Log Logging Log Use Press ... -
Page 11: Password
Multi-Sensor Area Velocity Flow Meter 24 HR LOG (Data Logging option only) --24 hr log------Flow Date Feb. 12/2010 Total 50138 USG Press from the MAIN display to view a formatted flow report from instruments Average 34.82 USG/m with a built-in data logger. Press to pan through Level Velocity Maximum... -
Page 12: Units/Mode
Multi-Sensor Area Velocity Flow Meter UNITS/MODE --Units/Mode-------- Mode Flow Linear press the and then the or to select Mode Flow From Volume Velocity Level . Flow mode displays the flow rate in engineering Time units (e.g. gpm, litres/sec, etc.) Press the to store your selection then the to Temperature the next menu item. -
Page 13: Calibration
Multi-Sensor Area Velocity Flow Meter CALIBRATION --Calibration------- } Vel Sensors 20mA Flo 10.000ft /s ³ Press to and to enter. Use or to position Calibration before 4mA Flo 0.000ft /s ³ each menu item and to enter. When settings are completed press to store and 20mA Vel 10.000 ft/s 4mA Vel... - Page 14 Multi-Sensor Area Velocity Flow Meter LEVEL SENSOR SENSOR ELEVATED ABOVE FLOOR OF TOP VIEW PIPE OR CHANNEL USE THE MB-QZ STAINLESS STEEL MOUNTING BRACKET (SUPPLIED) SENSOR SENSOR U-SHAPE STAINLESS STEEL 18 GA. RECOMMENDED HEIGHT AS REQUIRED SIDE VIEW END VIEW Min Vel Press ...
- Page 15 Multi-Sensor Area Velocity Flow Meter CHANNEL SETUP --Channel Setup------ Type Round Max Height 0.75ft Round Round Max Height Select for open pipes. Set to the inner diameter of the pipe. Rectangle Rectangle Select for rectangular channels. Enter the channel width. Trapezoid Trapezoid Select...
- Page 16 Multi-Sensor Area Velocity Flow Meter CUSTOM CHANNELS --Custom Channel----- Type Custom Reset Data Reset Data Old data MUST be removed before entering data for a new Max Height 0.75 ft channel. Press then press to and press to clear Division 0.05 ft old data.
-
Page 17: Relay Parameters
Multi-Sensor Area Velocity Flow Meter RELAY PARAMETERS --Relay Parameters-- Relay Function Velocity Press and or to select a relay. Relay Sensor Average 1000 USG /min Press or to select Function Pulse Flow 0.000 USG /min Velocity Level Velocity... -
Page 18: Special Functions
Multi-Sensor Area Velocity Flow Meter DATA LOGGING (OPTIONAL) Refer to Options section of this manual. SPECIAL FUNCTIONS --Special Functions- Language English Analog Out 4-20mA Language English French Spanish Select Backlight High Reset Totalizer Analog Out Select 4-20mA or 0-5V mode for the analog output. Negative Totals Flo Direction Cal Constant... - Page 19 Multi-Sensor Area Velocity Flow Meter SIMULATION --Simulation-------- Test Actual Level 0.00in Exercises the 4-20mA (0-5V) outputs, digital display and control relays. Velocity 10ft/s Flow 1982.88USG/m and press to simulate maximum Flow, Level and Test Maximum Select 4-20mA Level 20.00 4-20mA Velocity20.00 Velocity and to output 20mA (5V) to the analog channels.
-
Page 20: Installation - Sensor Location
Multi-Sensor Area Velocity Flow Meter INSTALLATION - SENSOR LOCATION 1. Choose sensor mounting locations where silt or deposits are least likely to accumulate. 2. For best results the three AVMS submerged velocity sensors should be positioned to obtain average velocity across the channel width. 3. - Page 21 Multi-Sensor Area Velocity Flow Meter One QZ02L sensor is providing level measurement and it must be mounted parallel to the water surface. GOOD END VIEW SENSOR SENSOR FLOW FLOW SENSOR SENSOR SENSOR SENSOR END VIEW END VIEW Page 21...
- Page 22 Multi-Sensor Area Velocity Flow Meter OPTIONAL PZ12-LP LEVEL SENSOR MOUNTING Mount the PZ12-LP non-contacting ultrasonic level sensor in an unobstructed position at least 8” (203.2 mm) above the high water level. Install the stainless steel mounting bracket in a horizontal position (check with a level) and then insert the PZ12-LP sensor.
-
Page 23: Enclosure Installation
Locate the enclosure within 20 ft (6 m) of the sensor (up to 500 ft -150 m optional). The enclosure can be wall mounted with the four mounting screws (included) or panel mounted with Option PM Panel Mount kit from Greyline Instruments. Avoid mounting the enclosure in direct sunlight to protect the electronics from damage due to overheating and condensate. - Page 24 Multi-Sensor Area Velocity Flow Meter FUSE REPLACEMENT 1. Turn OFF power. 2. Loosen cover screw and open. 3. Remove power module. 4. Locate fuse on Power Board. 5. Replace fuse with 2 AMP/ 250V, 5 x 20mm fuse. 6. Reinstall power module into chassis. Fuse POWER MODULE Page 24...
-
Page 25: Field Troubleshooting
Multi-Sensor Area Velocity Flow Meter FIELD TROUBLESHOOTING The AVMS 5.1 uses an ultrasonic level sensor to determine channel AREA and an ultrasonic Doppler sensor to measure flow VELOCITY. The QZ02L sensor combines both sensors in one housing. An optional configuration uses the PZ12-LP “down-looking” level sensor and a QZ02L-DP velocity sensor. - Page 26 Multi-Sensor Area Velocity Flow Meter SENSOR CABLE RESISTANCE TEST Unplug the green sensor terminal from the Doppler board and connect the sensor wires as shown. With a multimeter, perform resistance checks for each set of wires. One single loose terminal may cause false readings.
-
Page 27: Applications Hotline
United States: Tel: 315-788-9500 Fax: 315-764-0419 Canada: Tel: 613-938-8956 Fax: 613-938-4857 Toll Free: 888-473-9546 Email: info@greyline.com Web Site: www.greyline.com Greyline Instruments Inc. Canada USA: 16456 Sixsmith Drive 105 Water Street Long Sault, Ont. K0C 1P0 Massena, NY 13662 Page 27... -
Page 28: Product Return Procedure
Ship to Greyline - After obtaining an RMA number please ship the product to the appropriate address below: Canadian and International Customers: Customers: Greyline Instruments Inc. Greyline Instruments Inc. 16456 Sixsmith Drive 204 150th Avenue Long Sault, Ont. K0C 1P0... -
Page 29: Area-Velocity Flow Data Sheet
Multi-Sensor Area Velocity Flow Meter AREA-VELOCITY FLOW DATA SHEET Greyline Instruments Inc. Please complete and return this form to Greyline. It is 16456 Sixsmith Dr., Long Sault, Ont. K0C 1P0 important. We use this information to check our database Tel: 613-938-8956 / Fax: 613-938-4857... - Page 30 Multi-Sensor Area Velocity Flow Meter LIMITED WARRANTY _____________________________________ Greyline Instruments warrants, to the original purchaser, its products to be free from defects in material and workmanship for a period of one year from date of invoice. Greyline will replace or repair, free of charge, any Greyline product if it has been proven to be defective within the warranty period.
-
Page 31: Appendix A - Options
EXTRA SENSOR CABLE (OPTION VXC) Each Greyline AVMS 5.1 flow meter includes 25 ft. (7.6 m), 50 ft. (15 m) or 100 ft. (30 m) tri-coaxial sensor cable. This cable is shielded from electrical interference and is watertight with a polyurethane jacket. - Page 32 Multi-Sensor Area Velocity Flow Meter COAXIAL CABLE PREPARATION VXC Doppler sensor cable can be cut and spliced up to a maximum length of 500 ft (152 m). Cable ends must be prepared as illustrated below. GOOD BLACK BLACK (CONDUCTIVE) (CONDUCTIVE) SLEEVE SLEEVE HAS BEEN...
- Page 33 Multi-Sensor Area Velocity Flow Meter JUNCTION BOX - OPTION JB2X & JB4X NEMA4X (IP66) polycarbonate Junction Box with terminal strips is available from Greyline Instruments. Includes compression fittings for watertight coaxial cable entries. Page 33...
- Page 34 The Thermostat is factory set to turn ON at 40°F (4.5°C) and OFF at 60°F (15.5°C). Power consumption is 15 Watts. Please note: Only the AVMS 5.1 enclosure can be fitted with the Enclosure Heater and Thermostat module. The remote AVQZ3 enclosure does not support a heater option.
- Page 35 Multi-Sensor Area Velocity Flow Meter POWER INPUT OPTION 9-32VDC AVMS 5.1 Flow Meters may be ordered factory-configured for 9-32VDC power input. CONNECTIONS: POWER INPUT: Connect 9-32VDC to the + and - terminals. The Power Input GND terminal must be connected to the nearest Ground pole. A 1-amp fuse in line is recommended.
-
Page 36: Data Logging (Optional)
View 24-hr formatted Reports on the AVMS 5.1 display. Press from the MAIN display to view a formatted flow report from instruments with a built-in data logger. Press to pan through... - Page 37 Multi-Sensor Area Velocity Flow Meter RETRIEVE LOG FILE Plug a USB Flash Memory Drive (not supplied by Greyline) into the USB output cable from the instrument. The instrument display will show the USB file download icon until the log file is transferred to the memory card and then display file download completed icon.
-
Page 38: Specifications
Multi-Sensor Area Velocity Flow Meter SPECIFICATIONS Electronics Enclosure: NEMA4X (IP 66), watertight and dust tight, polycarbonate with clear, shatterproof hinged Lexan cover Accuracy: Level: ± 0.25% of Range Velocity: ± 2% of Reading Repeatability: 0.1% F.S., Linearity: 0.1%F.S. Display: White, backlit matrix – displays flow rate, totalizer, relay states, operating mode and calibration menu Programming: Built-in 5-key calibrator with English, French or Spanish language... - Page 39 Multi-Sensor Area Velocity Flow Meter Velocity/Level Sensor QZ02L Minimum Velocity: 0.1 ft/sec (0.03 m/sec) Maximum Velocity: 20 ft/sec (6.2 m/sec) [reverse flow to -5 ft/sec (-1.5 m/sec)] Minimum Head: 1 in. (25.4 mm) Maximum Head: 16 ft. (4.88 m) Operating Temperature: 5 to 150°F (-15 TO 65°C) Exposed Materials: PVC, epoxy resin, polyurethane, ultem...
- Page 40 Multi-Sensor Area Velocity Flow Meter Optional Sensor PZ15 25 ft (7.6 m) RG62AU COAXIAL CABLE (50 ft 15 m OR 100 ft 30 m OPTIONAL Maximum Range: 15 ft (4.57 m) Minimum Range (Deadband): 8" (203.2 mm) 3/4“ NPT Operating Frequency: 92 KHz Beam Angle: 8°...
- Page 41 www.greyline.com...
