Greyline Instruments TTFM 1.0 User Manual

Transit time flow meter
Hide thumbs Also See for TTFM 1.0:
Table of Contents

Advertisement

Quick Links

See also: User Manual
www.greyline.com
USER'S GUIDE
Installation & Operation
Instructions
Transit Time Flow Meter
Model TTFM 1.0
Manual Series A.2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TTFM 1.0 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Greyline Instruments TTFM 1.0

Summary of Contents for Greyline Instruments TTFM 1.0

  • Page 1 USER'S GUIDE Installation & Operation Instructions Transit Time Flow Meter Model TTFM 1.0 Manual Series A.2...
  • Page 2 Note: This page has been left blank intentionally.

  • Page 3: Table Of Contents

    TTFM 1.0 Transit Time Flow Meter INDEX TRANSDUCER INSTALLATION ................. 4   CONNECTIONS ..................... 5   KEYPAD SYSTEM ....................8   CALIBRATION MENU ..................9   MESSAGE ......................10   STATUS ........................ 10   PASSWORD ......................11   UNITS/MODE ....................... 12  ...

  • Page 4: Transducer Installation

    TTFM 1.0 Transit Time Flow Meter TRANSDUCER INSTALLATION *SEPARATION DISTANCE TRANSDUCER TRANSDUCER BNC1 TTJB JUNCTION BNC2 * Shown in display after pipe dimensions are entered. ‘ Message ’ Page 4...

  • Page 5: Connections

    TTFM 1.0 Transit Time Flow Meter CONNECTIONS: POWER INPUT: The standard model requires AC power input between 100 to 240 VAC 50/60Hz . No adjustments are necessary for voltages within this range. Connect L (Live) N (Neutral) and AC Ground.
  • Page 6 TTFM 1.0 Transit Time Flow Meter CONNECTIONS SENSOR DATA LOGGER EXTRA RELAYS OPTION RLY3 RLY4 RLY5 RLY6 POWER INPUT – 4-20mA HEATER OPTION RLY2 TRANSDUCER RLY1 GROUND USB HARNESS CONNECTOR Page 6...
  • Page 7 TTFM 1.0 Transit Time Flow Meter QUICK BENCH TEST: In the TTFM Calibration menu set parameters to perform a bench test: Set Pipe OD = 1.000 inch Set Pipe wall = 0.25 inch Set Pipe material to ABS Press  twice to exit Calibration and return to main display.

  • Page 8: Keypad System

    TTFM 1.0 Transit Time Flow Meter KEYPAD SYSTEM The diagram on page 8 shows the TTFM 1.0 menu system. Arrows show the four directions to leave a menu box. Pressing a corresponding keypad arrow will move to the next item in the direction shown.

  • Page 9: Calibration Menu

    TTFM 1.0 Transit Time Flow Meter CALIBRATION MENU Page 9...

  • Page 10: Message

    The main display shows the units selected from the Units/Mode menu, Flow or Velocity rate being measured, TOTALIZER and RELAY states. The TTFM 1.0 will start-up with this display and will return to this screen after a timeout if keys 20130.8 USG...

  • Page 11: Password

    TTFM 1.0 Transit Time Flow Meter 24 HR LOG (Data Logging option only) --24 hr log---------- Date Feb. 12/2010 Total 50138 USG Press  from the RUN display to view a formatted flow report from instruments Average 34.82 USG/m with a built-in data logger. Press  to scroll down one day or repeatedly to scroll Maximum 52.20 USG/m...

  • Page 12: Units/Mode

    TTFM 1.0 Transit Time Flow Meter UNITS/MODE --Units/Mode-------- Mode Flow Linear press the  and then the  or  to select Mode Flow From Volume Velocity . Flow mode displays the flow rate in engineering units (e.g. gpm, Time litres/sec, etc.) Press the ...

  • Page 13: Calibration

    TTFM 1.0 Transit Time Flow Meter CALIBRATION Press  to and  to enter. Use  or  to position Calibration  before each menu item and  to enter. When settings are completed press  to store and return to the Calibration menu.
  • Page 14 TTFM 1.0 Transit Time Flow Meter Pipe Select pipe material. Other – consult factory. Other/ Consult factory. Pipe Vel Other/ Consult factory. Propagation Lining Enter thickness of bonded liner material. Zero represents no liner. Fluid Temp Enter average fluid temperature.

  • Page 15: Relay Parameters

    TTFM 1.0 Transit Time Flow Meter RELAY PARAMETERS --Relay Parameters-- Relay Function Flow Relay Press  and  or  to select a corresponding relay number (2 Mode Pump 1000 USG relays are standard, 4 additional are optional). 0.000 USG Function Press ...

  • Page 16: Special Functions

    TTFM 1.0 Transit Time Flow Meter DATA LOGGING (OPTIONAL) Refer to Options section of this manual. SPECIAL FUNCTIONS Language English French Spanish Select Analog Out Select 4-20mA or 0-5V mode for the analogue output. Backlight High Medium Select continuous backlight.
  • Page 17 TTFM 1.0 Transit Time Flow Meter SIMULATION --Simulation-------- Test Actual Exercises the 4-20mA output, digital display and control relays (does not affect Flow 250USG/m the totalizer or optional data logger). 4-20mA Flow 5.60mA Relays 1 2 3 4 5 6 reading.

  • Page 18: Transducer Mounting

    TTFM 1.0 Transit Time Flow Meter TRANSDUCER MOUNTING LOCATION The position of the transducer is one of the most important considerations for accurate Transit Time flow measurement. The same location guidelines apply to Transit Time as most other types of flow meters.
  • Page 19 TTFM 1.0 Transit Time Flow Meter TRANSDUCER MOUNTING Prepare an area 2" wide by 4" long (50mm x 100mm) for transducer bonding by removing loose paint, scale and rust. The objective of site preparation is to eliminate any discontinuity between the transducer and the pipe wall, which would prevent acoustical coupling.
  • Page 20 SEPARATION DISTANCE Measure separation distance with a ruler or tape measure. Separation distance is automatically calculated Calibration by the TTFM 1.0 based on parameters entered in the menu. To view separation distance from the RUN display press  to view the...
  • Page 21 Warm temperatures, moisture and vibration will accelerate this process. Dow Corning Silicone Compound #4 as supplied with the TTFM 1.0 (and available from Greyline Instruments) is recommended for semi-permanent installations.
  • Page 22 TTFM 1.0 Transit Time Flow Meter TRANSDUCER MOUNTING/COUPLING RECOMMENDATIONS GOOD Page 22...

  • Page 23: Enclosure Installation

    TTFM 1.0 Transit Time Flow Meter ENCLOSURE INSTALLATION Locate the enclosure within 20 ft (6 m) of the transducer (500 ft -150 m optional). The enclosure can be wall mounted with the four mounting screws (included) or panel mounted with Option PM Panel Mount kit from Greyline Instruments.

  • Page 24: Field Troubleshooting

    TTFM 1.0 Transit Time Flow Meter FIELD TROUBLESHOOTING Corrective Action: Possible Causes: METER READING WHEN THERE IS NO FLOW?  Erratic measurement (set damping to 0% to check) due Ensure all Flowmeter wiring is in METAL to electrical noise or poor signal quality.
  • Page 25 TTFM 1.0 Transit Time Flow Meter NO ECHO INDICATION (EC = 0)?  Transducer Connections Check transducer connections at TTFM and at transducer junction box.  Note: Refer to Transducer Cable Resistance Test to test final connections.  Transducers not mounted to Pipe or mounted...
  • Page 26 TTFM 1.0 Transit Time Flow Meter TRANSDUCER CABLE RESISTANCE TEST Unplug the green transducer terminal from the Transit Time board and connect the transducer wires as shown. With a multimeter, perform resistance checks for each set of wires. One single loose terminal may cause false readings.

  • Page 27: Common Questions And Answers

    TTFM 1.0 Transit Time Flow Meter COMMON QUESTIONS AND ANSWERS The pipe vibrates. Will it affect the flow meter? Common vibration frequencies are far lower than the sonic frequencies used by the Greyline flow meter, and will not normally affect accuracy or performance. However, applications where very weak Transit Time signal is present (when sensitivity is adjusted to maximum and signal strength is low), accuracy may be affected by pipe vibration, or the flow meter may show readings under no-flow conditions.
  • Page 28 Does the TTFM 1.0 require periodic recalibration? No. TTFM 1.0 calibration does not drift over time. The solid state transducer has no moving parts to wear and affect calibration. All Greyline timing/counting circuits use crystal-controlled frequency references to eliminate any drift in the processing circuitry.

  • Page 29: Applications Hotline

    TTFM 1.0 Transit Time Flow Meter APPLICATIONS HOTLINE For applications assistance, advice or information on any Greyline Instrument contact your Sales Representative, write to Greyline or phone the Applications Hotline below: United States: Tel: 315-788-9500 Fax: 315-764-0419 Canada: Tel: 613-938-8956...

  • Page 30: Product Return Procedure

    TTFM 1.0 Transit Time Flow Meter PRODUCT RETURN PROCEDURE Instruments may be returned to Greyline for service or warranty repair. Obtain an RMA Number from Greyline - Before shipping a product to the factory please contact Greyline by telephone, fax or email to obtain an RMA number (Returned Merchandise Authorization).
  • Page 31 TTFM 1.0 Transit Time Flow Meter FLOW METER DATA SHEET Please complete and return this form to Greyline.  It is important.  We  [  ]   16456 Sixsmith Drive, Long Sault, ON  K0C 1P0    Tel: 613‐938‐8956 / Fax: 613‐938‐4857  use this information to check our database for performance of Greyline     flow meters in similar applications, and to provide advice and  [  ]   105 Water Street, Massena, NY 13662    recommendations to you.  Thank you for your cooperation.   Tel: 315‐788‐9500 / Fax: 315‐764‐0419     Contact     Title/Dept     Company     Address     Address    ...
  • Page 32 TTFM 1.0 Transit Time Flow Meter LIMITED WARRANTY _____________________________________ Greyline Instruments warrants, to the original purchaser, its products to be free from defects in material and workmanship for a period of one year from date of invoice. Greyline will replace or repair, free of charge, any Greyline product if it has been proven to be defective within the warranty period.

  • Page 33: Appendix A - Options

    TTFM 1.0 Transit Time Flow Meter APPENDIX A – OPTIONS EXTRA TRANSDUCER CABLE (OPTION DXC) Each Greyline flow meter includes 25 ft / 7.6m (or 50 ft / 15 m optional) continuous shielded coaxial pair cable. Additional cable may be ordered with the Flow Meter, or the cable may be spliced and extended up to 250 ft (75 m) as required during installation.
  • Page 34 TTFM 1.0 Transit Time Flow Meter ENCLOSURE HEATER AND THERMOSTAT - Option TH Instruments can be factory-equipped with an Enclosure Heater and Thermostat or the module can be customer-installed. The Thermostat is factory set to turn ON at 40°F (4.5°C) and OFF at 60°F (15.5°C).
  • Page 35 TTFM 1.0 Transit Time Flow Meter POWER INPUT OPTION 9-32VDC TTFM 1.0 Flow Meters may be ordered factory-configured for 9-32VDC power input. CONNECTIONS: POWER INPUT: Connect 9-32VDC to the + and - terminals. The Power Input GND terminal must be connected to the nearest Ground pole.

  • Page 36: Data Logging

    TTFM 1.0 Transit Time Flow Meter DATA LOGGING (Optional) --Data Logging------- Log Site ID Setup Mode Level Range Flow Data Logging Select from Menu Selections. Volume Set Date Feb 18/2008 Log Site ID Enter a number from . The site ID will become...
  • Page 37 TTFM 1.0 Transit Time Flow Meter Download letter will be A for the first download from an instrument. B for the second, then C etc. At the letter Z a - character will appear indicating that the maximum number of downloads for that instrument are on the USB flash drive.

  • Page 38: Specifications

    TTFM 1.0 Transit Time Flow Meter SPECIFICATIONS 7.4 / 188 mm " 6.46 / 164 mm " 5.12 / 130 mm " Flow Rate Range: ±0.07 to 39 ft/sec (±0.02 to 12 m/sec) typical Pipe Size: ½” to 24” (12 to 610 Accuracy: ±1% of flow rate,...

  • Page 39: Appendix B - Conversion Table

    TTFM 1.0 Transit Time Flow Meter APPENDIX B - CONVERSION TABLE CONVERSION GUIDE FROM MULTIPLY BY US GALLONS CUBIC FEET 0.1337 US GALLONS IMPERIAL GALS 0.8327 US GALLONS LITRES 3.785 US GALLONS CUBIC METERS 0.003785 LITRES/SEC 15.85 LITRES CUBIC METERS 0.001...

  • Page 40: Pipe Charts

    TTFM 1.0 Transit Time Flow Meter PIPE CHARTS Carbon Steel & PVC Pipe Standard Extra Heavy Dbl. Extra Pipe Pipe Schedule 40 Schedule 80 Heavy Schedule 10 Schedule 20 Schedule 30 Schedule 40 Size O.D. I.D. WALL I.D. WALL I.D.
  • Page 41 TTFM 1.0 Transit Time Flow Meter Stainless Steel, Hastelloy "C" & Titanium Pipe Pipe Pipe Schedule 5 S (a) Schedule 10 S (a) Schedule 40 S Schedule 80 S Size O.D. I.D. WALL I.D. WALL I.D. WALL I.D. WALL ½...
  • Page 42 TTFM 1.0 Transit Time Flow Meter Cast Iron Pipe - ASA Standard Pipe Pipe Class Class Class Class Class Class Class Size O.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. 3.96 0.32 3.32 0.32...

  • Page 43: Appendix C - Liquid Speed Of Sound

    TTFM 1.0 Transit Time Flow Meter APPENDIX C – Liquid Speed of Sound FLUID FORMULA SOUND SPEED m/s Acetic Acid 1180 Acetone 1174 Ammonia 1729 Benzene 1306 Bromine Carbon dioxide Carbon tetrachloride Chloro-benzene 1273 Chloroform CHCI Ethanol 1207 Ethylene glycol 100%...
