- Page 1 www.greyline.com USER'S GUIDE Installation & Operation Instructions Doppler Flow Meter Model DFM 5.1 Manual Series A.1.1...
- Page 2 Note: This page has been left blank intentionally.
-
Page 3: Table Of Contents
DFM 5.1 Doppler Flow Meter INDEX CONNECTIONS ..................... 4 KEYPAD SYSTEM ....................6 CALIBRATION MENU ..................7 ICONS ........................8 MESSAGE ICON ....................9 STATUS ........................9 PASSWORD......................10 UNITS/MODE ....................... 11 CALIBRATION ....................12 RELAY PARAMETERS..................13 SPECIAL FUNCTIONS ..................14 SENSOR MOUNTING .................. -
Page 4: Connections
DFM 5.1 Doppler Flow Meter CONNECTIONS: POWER INPUT: The standard model requires AC power input between 100 to 240 VAC 50/60Hz. No adjustments are necessary for voltages within this range. Connect L (Live) N (Neutral) and AC Ground. Optional DC input model requires 9-32 VDC/9 Watts. Connect to + and - terminals. Optional Thermostat and Heater modules are available rated for 115 VAC or 230 VAC. - Page 5 DFM 5.1 Doppler Flow Meter CONNECTIONS Page 5...
-
Page 6: Keypad System
DFM 5.1 Doppler Flow Meter KEYPAD SYSTEM The following diagram shows the DFM 5.1 menu system. Arrows show the four directions to leave a menu box. Pressing a corresponding keypad arrow will move to the next item in the direction shown. Move the cursor (highlighted) under numerals and increase or decrease numerals with the ... -
Page 7: Calibration Menu
DFM 5.1 Doppler Flow Meter CALIBRATION MENU Page 7... -
Page 8: Icons
DFM 5.1 Doppler Flow Meter ICONS Page 8... -
Page 9: Message Icon
DFM 5.1 Doppler Flow Meter MAIN DISPLAY The main display shows the units selected from the Units/Mode menu, Flow or Velocity rate being measured, TOTALIZER and RELAY states. The DFM 5.1 will start-up with this display. MESSAGE ICON Press from the main display to view status of the data logger and error/warning messages provided by the instrument. -
Page 10: Password
DFM 5.1 Doppler Flow Meter 24 HR LOG (Data Logging option only) Press from the main display to view a formatted flow report from instruments with a built-in data logger. Press to scroll down one day or repeatedly to scroll to a specific date. -
Page 11: Units/Mode
DFM 5.1 Doppler Flow Meter UNITS/MODE press the and then the or to select From Mode Flow Velocity Flow mode displays the flow rate in engineering units (e.g. gpm, litres/sec, etc.) Press the to store your selection then the to the next menu item and to enter. -
Page 12: Calibration
DFM 5.1 Doppler Flow Meter CALIBRATION Press the to and to enter. Use or to position before Calibration each menu item and to enter. When settings are completed press to store and return to the Calibration menu. Press ... -
Page 13: Relay Parameters
DFM 5.1 Doppler Flow Meter RELAY PARAMETERS Press and or to select a corresponding relay number (2 Relay relays are standard, 4 additional are optional). Press or to select Function Pulse Flow Flow Mode Select Pump Low Alarm Hi Alarm... -
Page 14: Special Functions
DFM 5.1 Doppler Flow Meter DATA LOGGING (OPTIONAL) Refer to Options section of this manual. SPECIAL FUNCTIONS Language Select English French Spanish Select 4-20mA or 0-5V mode for the analog Analog Out output. Backlight Select for continuous High Medium backlight. Select for high backlight for 1 minute Key Hi/Lo... - Page 15 DFM 5.1 Doppler Flow Meter SIMULATION Exercises the 4-20mA (0-5V) output, digital display and control relays. Select and press to simulate maximum Flow or Velocity and Test Maximum to output 20mA (5V) to the analog channel. Select and press to simulate minimum Flow or Velocity and Minimum to output 4mA (0V) to the analog channel.
-
Page 16: Sensor Mounting
DFM 5.1 Doppler Flow Meter SENSOR MOUNTING LOCATION The position of the sensor is one of the most important considerations for accurate Doppler flow measurement. The same location guidelines apply to Doppler as most other types of flow meters. Before permanently mounting a Doppler sensor onsite testing is recommended to determine optimum mounting position. - Page 17 DFM 5.1 Doppler Flow Meter SENSOR MOUNTING Prepare an area 2" wide by 4" long (50mm x 100mm) for sensor bonding by removing loose paint, scale and rust. The objective of site preparation is to eliminate any discontinuity between the sensor and the pipe wall, which would prevent acoustical coupling.
- Page 18 Warm temperatures, moisture and vibration will accelerate this process. Dow Corning Silicone Compound #4 as supplied with the DFM 5.1 (and available from Greyline Instruments) is recommended for semi-permanent installations. Page 18...
- Page 19 DFM 5.1 Doppler Flow Meter SENSOR MOUNTING/COUPLING RECOMMENDATIONS Page 19...
-
Page 20: Enclosure Installation
Locate the enclosure within 20 ft (6 m) of the sensor (500 ft -150 m optional). The enclosure can be wall mounted with the four mounting screws (included) or panel mounted with Option PM Panel Mount kit from Greyline Instruments. Avoid mounting the enclosure in direct sunlight to protect the electronics from damage due to overheating and condensate. - Page 21 DFM 5.1 Doppler Flow Meter FUSE REPLACEMENT 1. Turn OFF power. 2. Loosen cover screw and open. 3. Remove power module. 4. Locate fuse on Power Board. 5. Replace fuse with 2 AMP/ 250V, 5 x 20mm fuse. 6. Reinstall power module into chassis. Page 21...
-
Page 22: Field Troubleshooting
DFM 5.1 Doppler Flow Meter FIELD TROUBLESHOOTING Corrective Action: Possible Causes: METER READING LOWER THAN EXPECTED Calibration Error Review menu and UNITS/MODE Pipe ID Lower flow rate than expected Investigate pump/valves. Compare velocity with alternate instrument Signal not penetrating far enough into the flow stream Relocate sensor closer to elbows or flow disturbances ... - Page 23 DFM 5.1 Doppler Flow Meter Corrective Action: Possible Causes: METER READING ERRATIC Sensor mounted too close to valve, pump or elbow Change sensor placement. Recommended 6-10 diameters from elbows, and 30 diameters from pumps, controlling valves, orifice plates, nozzles or open pipe discharge NO FLOW INDICATION ...
- Page 24 DFM 5.1 Doppler Flow Meter Corrective Action: Possible Causes: METER READING DOES NOT TRACK FLOW Sensor and GND wires reversed or not properly Check Sensor connections connected Improper AC power input Ground Use direct connection with 12 AWG wire to nearest Ground pole (<1 ohm resistance).
-
Page 25: Common Questions And Answers
DFM 5.1 Doppler Flow Meter COMMON QUESTIONS AND ANSWERS The pipe vibrates. Will it affect the flow meter? Common vibration frequencies are far lower than the sonic frequencies used by the Greyline flow meter, and will not normally affect accuracy or performance. However, applications where very weak Doppler signal is present (when sensitivity is adjusted to maximum and signal strength is low), accuracy may be affected by pipe vibration, or the flow meter may show readings under no-flow conditions. - Page 26 DFM 5.1 Doppler Flow Meter Can I change the length of the sensor cable? Yes. Technological advances in Greyline Doppler design allow cable lengths up to 500 ft (152 m) with no loss of signal strength. Extended cable (Greyline Option DXC) should be installed in rigid or flexible conduit for mechanical protection.
-
Page 27: Applications Hotline
Tel: 613-938-8956 Fax: 613-938-4857 Toll Free: 888-473-9546 Email: info@greyline.com Web Site: www.greyline.com Greyline Instruments Inc. Canada USA: 16456 Sixsmith Drive 11451 Belcher Road South Long Sault, Ont. K0C 1P0 Largo, FL 33773 PRODUCT RETURN PROCEDURE Instruments may be returned to Greyline for service or warranty repair. -
Page 28: Flow Meter Data Sheet
DFM 5.1 Doppler Flow Meter FLOW METER DATA SHEET Page 28... - Page 29 DFM 5.1 Doppler Flow Meter LIMITED WARRANTY _____________________________________ Greyline Instruments warrants, to the original purchaser, its products to be free from defects in material and workmanship for a period of one year from date of invoice. Greyline will replace or repair, free of charge, any Greyline product if it has been proven to be defective within the warranty period.
-
Page 30: Appendix A - Options
DFM 5.1 Doppler Flow Meter APPENDIX A – OPTIONS EXTRA SENSOR CABLE (OPTION DXC) Each Greyline flow meter includes 20 ft / 6m (or 50 ft / 15 m optional) continuous shielded coaxial pair cable. Additional cable and Cable Junction Box (Option JB2X) may be ordered with the Flow Meter, or the cable may be spliced and extended up to 500 ft (152m) as required during installation. - Page 31 DFM 5.1 Doppler Flow Meter SENSOR CABLE JUNCTION BOX (OPTION JB2X) Optional Watertight steel NEMA4 Junction Boxes with terminal strips are available from Greyline Instruments. Velocity Sensor QZ02L-B Minimum Velocity: 0.1 ft/sec (0.03 m/sec) Maximum Velocity: 20 ft/sec (6.2 m/sec) Operating Temperature: 5 to 150°F (-15 to 65°C) Exposed Materials:...
- Page 32 DFM 5.1 Doppler Flow Meter SENSOR INTRINSIC SAFETY (OPTION 2ISB) When connected through Intrinsic Safety Barriers, the Greyline Sensor Model SE4 is CSA certified for installation in a hazardous location rated: Class I, Groups C,D Class II, Groups E,F,G Class III Intrinsic Safety Barriers may be ordered with the Greyline instrument and are supplied mounted in the Greyline instrument enclosure.
- Page 33 DFM 5.1 Doppler Flow Meter Page 33...
- Page 34 DFM 5.1 Doppler Flow Meter ENCLOSURE HEATER AND THERMOSTAT - Option TH Instruments can be factory-equipped with an Enclosure Heater and Thermostat or the module can be customer-installed. The Thermostat is factory set to turn ON at 40°F (4.5°C) and OFF at 60°F (15.5°C). Power consumption is 15 Watts.
- Page 35 DFM 5.1 Doppler Flow Meter POWER INPUT OPTION 9-32VDC DFM 5.1 Flow Meters may be ordered factory-configured for 9-32VDC power input. QUICK BENCH TEST: Connect Sensor as shown below, then Power. Test operation of the DFM 5.1 by holding the sensor in one hand and rubbing your thumb or fingers briskly across the face (plastic surface) of the sensor.
-
Page 36: Data Logging
DFM 5.1 Doppler Flow Meter DATA LOGGING (Optional) Setup Select from Menu Selections. Data Logging Enter a number from . The site ID will become part Log Site ID of the downloaded file name to help distinguish downloads from different instruments. Press to store the setting. Select Velocity (e.g. - Page 37 DFM 5.1 Doppler Flow Meter Download letter will be A for the first download from an instrument. B for the second, then C etc. At the letter Z a - character will appear indicating that the maximum number of downloads for that instrument are on the USB flash drive. Older files can be erased or moved from the flash memory drive or a new memory drive can be used.
-
Page 38: Specifications
DFM 5.1 Doppler Flow Meter SPECIFICATIONS Flow Rate Range: -40 to -0.25 ft/sec, +0.25 to +40 ft/sec (-12.2 to - 0.076 m/sec, +0.076 to +12.2 m/sec,) in most applications Pipe Size: Any pipe ID from ½ " to 180" (12.7 mm to 4.5 m) Accuracy: ±2% of full scale. - Page 39 DFM 5.1 Doppler Flow Meter APPENDIX B - CONVERSION TABLE CONVERSION GUIDE FROM MULTIPLY BY US GALLONS CUBIC FEET 0.1337 US GALLONS IMPERIAL GALS 0.8327 US GALLONS LITRES 3.785 US GALLONS CUBIC METERS 0.003785 LITRES/SEC 15.85 LITRES CUBIC METERS 0.001 BARRELS US GALLONS BARRELS...
-
Page 40: Pipe Charts
DFM 5.1 Doppler Flow Meter PIPE CHARTS Ductile Ir on Pipe - Standard Classes Size OUTSIDE Clas s Class Class C lass C lass C lass C la ss C EMEN T LIN IN G IN CH D IA. **S TD ** DOUB LE INC H WA LL... - Page 41 DFM 5.1 Doppler Flow Meter Stainless Steel, Hastelloy "C" & Titanium Pipe Pipe Pipe Scheule 5 S (a) Schedule 10 S (a) Schedule 40 S Schedule 80 S Size O.D. I.D. WALL I.D. WALL I.D. WALL I.D. WALL ½ .840 .710 .065 .674...
- Page 42 DFM 5.1 Doppler Flow Meter Cast Iron Pipe - ASA Standard Pipe Pipe Class 50 Class 100 Class 150 Class 200 Class 250 Class 300 Class 350 Size O.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D. WALL I.D.
