Transient Modules 2M Diy Building Manual page 6

DIY building manual - Version 1.3
24. Connect the ribbon cable. The red stripe
on the cable must line up with the RED
indication on the module's power connector.
And...
: ) Module fnished! : )
Check that all the inputs and both outputs
are working correctly, as well as the
normalization between the mixers in case
you're using it.
Something is not working as it should? *
Did you like the build manual? *
Had problems during the build process? *
Do you have any suggestions to make the build process better? *
Are you missing any part? *
Were you soldering slighlty drunk and did a mess? *
* Based in real e-mails.
Then, write us!
contact@transientmodules.com
If everything went fne: congratulations and enjoy the module!
