This guide is for building the 2M module from Transient Modules.
It is good to have basic soldering skills and to be able to identify electronic components
before starting this kit. In case you're an experienced DIYer, please read all the steps
thoroughly before starting as some of them are not so obvious.
The 2M kit consists of two boards and all the parts comes in only two bags separated.
See the parts list below to identify each one of them easily before start building:
Part
Resistors:
Resistor 100K
Resistor 1K
Capacitors:
22pF
100nF
47uF electrolytic
Diodes:
1N4007
Screws:
M2 hexagonal screw
M2 phillips screw
M3 silver screw
M3 black screw
Potentiometers:
100KA
100KB
Hello!
Qty
13
2
2
2
2
2
1
1
2
2
6
2
ʕ•ᴥ•ʔ
2M DIY kit build manual - Version 2.0
Part
Headers:
10 pin header female
10 pin header male
Power connector
Spacers:
10mm spacer
11mm spacer
Sockets:
8 pin DIP sockets
Jacks sockets
Various:
LME49720
Ferrites
Knurled nuts
Panel
Bottom PCB
Top PCB
Ribbon cable
Qty
1
1
1
1
1
2
8
2
2
8
1
1
1
1
Advertisement
Related Manuals for Transient Modules 2M
Summary of Contents for Transient Modules 2M
- Page 1 The 2M kit consists of two boards and all the parts comes in only two bags separated. See the parts list below to identify each one of them easily before start building:...
- Page 2 2M DIY kit build manual - Version 2.0 1. Let's begin with the back PCB. Start by emptying the bag into a bowl or container. This makes it much easier to pick parts as you need them and you’re a lot less likely to lose anything.
- Page 3 2M DIY kit build manual - Version 2.0 9. Next solder the power header. 10. Place the 10 pin female header and solder it ensuring it is 90º to the PCB. 11. Solder the two IC Sockets. Make sure t h e notches in the sockets match the silkscreen.
- Page 4 2M DIY kit build manual - Version 2.0 2. When no cable is connected at the output jack of the mixer on the left, its output is summed to the inputs of the mixer on the right. This normalization may be useful if you want to mix 6 drum sounds to one output.
- Page 5 2M DIY kit build manual - Version 2.0 17. Screw the 11mm spacer (the one which is slightly bigger) using one M3 black screw as shown. 18. Place the eight jacks into their position DO NOT SOLDER yet. 19. Use your hands to screw the 10mm spacer to the panel using the hexagonal M2 screw (the one which is slightly tiny).
- Page 6 2M DIY kit build manual - Version 2.0 24. Join the front PCB and the back PCB using the pin headers and ensuring the 3mm hole match the spacer. Screw both boards with the last M3 black screw. 25. Connect the ribbon cable. The red stripe on the cable must line up with the white line on the module’s power...
