- Page 1 DIGITAL UNIVERSAL SCALE UDS-1V-WP OPERATION MANUAL Read this manual and keep it handy YAMATO SCALE CO., LTD. EXPORT-0703...
-
Page 2: Table Of Contents
This scale features many functions. Please read carefully this Operation Manual and take advantage of the descriptions in it to use Yamato’s UDS-1V-WP in the optimum condition for the longest life. TABLE OF CONTENTS PAGE SAFETY PRECAUTIONS ···············································································... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS Read carefully SAFETY PRECAUTIONS before use, and follow all the instructions. SAFETY PRECAUTIONS are designed for protecting users, other peoples and assets from physical and financial damages by your safety practices. This OPERATION MANUAL should be kept for the entire service life of the product. The hazardous levels and descriptions are defined as follows: Danger Denotes where mishandling without compliance with this sign has a... - Page 4 Warning Do Not Use on Unstable Surface: An inclined equipment may fall down and cause an unexpected accident. When a equipment is used on a table, special care is required for securing the safe operation. Do Not Hold the Pan when Carrying The pan may detach from the body, and the main body may fall on and injure the foot.
-
Page 5: Instructions And Directions For Use
Do not put the equipment upside down (the pan down) except when batteries are replaced. As for all optional devices or parts connected to the UDS-1V-WP, use the devices or parts specified by Yamato. Please note that we cannot assume responsibility for any troubles caused by devices/ parts which are not specified by us and repair or modifications. -
Page 6: Functions
If it shows dirt, soak a cloth in mild detergent diluted by adding water, wring it well and wipe out the dirt. FUNCTIONS The UDS-1V-WP has the following functions. Use these functions in accordance with your purpose. Function / Application How to use the function... -
Page 7: Product Package
PRODUCT PACKAGE NAMES OF PARTS... -
Page 8: To Keep The Scale Working Efficiently
TO KEEP THE SCALE WORKING EFFICIENTLY 1. This waterproof digital scale is graded as IP68. IP68 is the grade of protection against complete, continuous submersion in water. The scale is designed not to admit water even after it has been left at a depth of one meter for 24 hours. -
Page 9: Installation
INSTALLATION How to set batteries Note: Carefully avoid excessive force on the scale when it is turned over. A drop and/or excessive force may damage the scale. 1. Turn over the scale. 2. Wipe off the water or dust on the scale with a dry 3. - Page 10 8. Hang the tabs. 9. Rotate the set screw 90 degrees clockwise to close the battery lid tightly. Note) Make sure that both tabs are hanged firmly, or its waterproof cannot be kept and the scale are damaged. How to set AC adaptor (Option) Note: The waterproof is not effective when using the AC adaptor.
- Page 11 How to clean the Lower Diaphragm Note: Carefully avoid excessive force on the scale when it is turned over. A drop and/or excessive force may damage the scale. 1. Turn over the scale. 2. Wipe off the water or dust on the scale with 3.
- Page 12 Place the scale Make sure that the scale is placed on a leveled surface, or a correct measurement cannot be attained. Make sure that the scale is not shaky, which also results in an incorrect measurement. Do not place the scale on an inclined surface (if the inclination is beyond the adjustable range by the leveler).
-
Page 13: Display And Keyboard
DISPLAY AND KEYBOARD < DISPLAY PART > The battery residual capacity is shown by 3 levels when they are consumed. The indicator is lit while the Checkweighing function is operated. The indicator blinks while the Checkweighing function is set. The indicator is lit while the Fixed weighing function is operated. The indicator blinks while the Fixed weighing function is set. -
Page 14: Calibration
CALIBRATION When you use the UDS-1V-WP for the first time, it is necessary to calibrate the scale at your area before use. If you skip the calibration, the scale may not indicate the weight with accuracy. Therefore be sure to calibrate the scale at your area before using scale. -
Page 15: Basic Operation
3 Confirm that the pan is empty, and then press 4 Put the standard weight of 3,000 g in the center of the pan and press 5 Put the 3,000 g weight additionally (Total 6,000 g) in the center of the pan and press When the calibration has finished, the display will show 6000. -
Page 16: Tare Operation
TARE OPERATION Tare operation is used when you want to display the net weight that is deducted a container weight from the total weight. (Tare means a container.) Operation Display 1 Place an empty container on the pan. The weight of the container (e.g. 25 g) is shown on the display. -
Page 17: User Parameter
USER PARAMETER The UDS-1V-WP has 3 functions that can be used in accordance with the application. Set the user parameter before using the scale based on the following parameter list. USER PARAMETER LIST Parameter Description Available parameter Function Select 000:... - Page 18 (001 to 005). Parameter# 09: Gravity compensation The UDS-1V-WP (non-trade use) is equipped with the function of Gravity compensation. It is available to set the value that is appropriate for the area the scale is used. The value can be evaluated by the below calculating formula.
-
Page 19: How To Change User Parameter
HOW TO CHANGE USER PARAMETER 3) How to change the setting of Auto-off Timer (Parameter No. 05) e.g.) Change the setting value at Parameter No. 05 from 003 (15 min. after no use) to 005 (60 min. after no use). Operation Display 1 Press... - Page 20 4) How to change the setting of Buzzer (Parameter No. 03) e.g.) Change the setting value at Parameter No. 03 from 000 (No sound) to 003 (Beep at over weight). Operation Display 1 Press to turn on the scale. 2 While pressing , press to enter the parameter setting mode.
- Page 21 5) How to change the setting of flicker of display (Parameter No. 07) e.g.) Change the setting value at Parameter No. 07 from 000 (No flicker) to 003 (Flickers at over weight). Operation Display 1 Press to turn on the scale. 2 While pressing , press to enter the parameter...
-
Page 22: Multi-Function
MULTI-FUNCTION The UDS-1V-WP is equipped with 3 unique functions that are useful for speeding up your work with the bar charts and weighing display. The unique functions are as follows. FIXED WEIGHING FUNCTION Application : Packing items to the target weight... - Page 23 GRADING FUNCTION Application : Sorting items up to 15 ranks How to weigh : Store the lower limits of each rank of the items on the scale and display the rank of the item based on the stored lower limits. Features : 1) Stating the rank in figures instead of the weighing value avoids man-caused errors.
-
Page 24: Fixed Weighing Function
FIXED WEIGHING FUNCTION PRE-SETTING Operation Display Press to turn on the scale. While pressing , press to enter the pre-setting mode. Set the value 001 (Fixed weighing function) by pressing Press twice. The display goes to the parameter No. 03 (Buzzer setting). If you would like to sound the beep at acceptable weight, enter “003”... - Page 25 Operation Display Press . The display goes to the parameter No. 07 (Flash setting). If you would like to flash the weight display at under weight, enter “001” by pressing No Flicker Flickers at under weight Flickers at over weight Flickers at acceptable weight Flickers at under &...
- Page 26 SETUP Note) The registered data of each item are stored even if the scale is turned off. e.g.) Set the target weight of the Item No. 13 at 100g and the allowable weight at 5g. Operation Display 1 Press to turn on the scale. 2 Confirm the pan is empty, and then press briefly.
- Page 27 OPERATION e.g.) Recall the Item No. 13 (the target weight =100g , the allowable weight = 5g) Operation Display Press to turn on the scale. Press briefly to recall the stored item No. PACK blinks. Chose the item number by pressing e.g.) Items No.
- Page 28 Operation Display When the weight is over than the allowable weight, the bar charts move to the range of over weight. Remove the items until the bar charts move back to the range of acceptable weight. e.g.) The display shows the case that placing the items for 109g under the setting of target wt = 100g and allowable wt = 10 Press to switch to the normal weighing mode after...
-
Page 29: Checkweighing Function
CHECKWEIGHING FUNCTION PRE-SETTING Operation Display 1 Press to turn on the scale. 2 While pressing , press to enter the pre-setting mode. 3 Set the desired value 002 by pressing 4 Press twice. The display goes to the parameter No. 03 (Buzzer setting). - Page 30 SET-UP Note) The registered data of each item are stored even if the scale is turned off. e.g.) Set the acceptable weight of the Item No. 22 at 100 g to 110 g. Operation Display 1 Press to turn on the scale. 2 Confirm the pan is empty, and then press briefly.
- Page 31 OPERATION e.g.) Recall the Item No. 22 (the lower limit 100g and the upper limit: 110g). Operation Display 1 Press to turn on the scale. 2 Press briefly to recall the stored item No. Press to choose your desired item No. (e.g.
-
Page 32: Grading Function
GRADING FUNCTION PRE-SETTING Operation Display 1 Press to turn on the scale. 2 While pressing , press to enter the pre-setting mode. 3 Set the parameter No. 01 at 003 (Grading function) by pressing 4 Press to go to the next parameter 02. Set the desired value by pressing When sorting the item to 2 ranks, set the value 002. - Page 33 7 Press to store the setting value. To finish the pre-setting, keep pressing The scale turns off. SETUP Set the lower limit of each rank and the upper limit of the upper rank. When sorting items to 2 ranks, it is necessary to input the 3 set-points. Note) The registered data of each item are stored even if the scale is turned off.
- Page 34 Press to shift the digit and set the lower limit of rank 2 by pressing e.g.) When set the rank 2 at 200g to 300g, set the lower limit at 200. Press The display goes to the upper-setting screen of rank 2. Press to shift the digit and set the upper limit of rank 2 by pressing...
- Page 35 6 If the net weight is lighter than Rank 1, the display does not show the rank. e.g.) Net weight = 95 g 7 If the net weight is heavier than Rank 2, the display does not show the rank. e.g.) Net weight = 310 g 8 When you set the parameter #04 (stability restriction) at 001 (grading only at stability), the display shows “- -“...
-
Page 36: Error Messages
ERROR MESSAGES The scale automatically checks up various functions. When one of the following error messages appears on the display, follow the troubleshooting instruction. Contact the retailer from which the product was purchased, if other messages than the following appear, or an error is not recovered after following the troubleshooting. Display Cause Troubleshooting... - Page 37 Display Cause Troubleshooting Turned on the scale while Remove the item from the pan, and a heavy item was placed. then press The initial error (A) Turn on the scale while a Check if a foreign material is not stuck foreign material was stuck or does not contact the pan.
-
Page 38: Specifications
SPECIFICATIONS The appearance and specifications are subject to change without notice for improvement. Name of the scale (Model): UDS-1V-WP Weighing system: Strain-gauge load cell Dimensions of the platform: 232 mm x 202 mm Capacity and Increment Weighing capacity Minimum Increment... - Page 39 Power supply: 6VDC (4 “D” size batteries) or AC adaptor Battery life: Approx. 1400 hours in continuous use (alkaline dry battery) Power consumption: Max. 0.07W Weight: 3.7 kg Outside dimensions...
- Page 40 YAMATO SCALE CO., LTD. 5-22 Saenba-cho, Akashi 673-8688, Japan Telephone: +81-78-918-6157 Telefax. +81-78-918-5552 PRINTED IN JAPAN...
