Generac Power Systems PV Link Installation Manual page 19

NOTE: See Figure
same number of the same type of PV modules, and there must be one SnapRS device for each
module in the array.
A
D
A PWRcell inverter
B PV Link
C
SnapRS device
16
5-5. When dual strings are connected in parallel, each string must use the
B
E
E
C
Figure 5-5. Parallel-Input PV Array with SnapRS Devices
D PV module
E MC4 branch connector
Installation Manual for PV Link and SnapRS
