"Islatros" and other similar power line filters are designed to carry the power
for the control circuit and "buffer" the control circuit from A.C. line noise.
Devices like the lslatrol use media (electromagnetic filtering) other than
electric circuits to filter out electrical noise. Take care in matching the power
capabilities of the filter with power demands of the circuit. Keep line filters as
close to the control as possible to minimize the area for interference pick up.
lslatrols are available from:
I - 101 (1A,l20VAC)
I - 105 (5A, 120VAC)
I - 115 (15A, 120VAC)
The ultimate protection is an "uninterruptable" power supply. This 'senses'
the A.C. power line; when the line fluctuates, a battery powered 6OHz in-
verted circuit takes over, supplying power within one-half to one cycle of the
A.C. line; very expensive.
How To Check For Ground Loops
To check for ground loops, disconnect the ground wire at the ground termina-
tion. Measure the resistance from the wire to the point where it was connected.
The ohmmeter should read a high ohm value. If you have a low ohm value
across this gap, there is at least one ground loop present in your system.
Or check for continuity; your reading should be "open". If you do find continu-
ity, you must now begin looking for the ground loops. Begin disconnecting
grounds in the system one at a time, checking for continuity after each discon-
nection. When continuity reads "open" you have eliminated the ground loop(s).
Also, as you reconnect grounds, keep making the continuity test. It is possible
to reconnect a ground loop.
Noise Suppression Devices Available From Watlow
Watlow Controls stocks a few key noise suppression parts. You may order
these by calling your local Watlow distributor.
Item
Common Mode Line Filter
Differential Mode Line Filter
Metal
Oxide Varistor
MOV
MOV
MOV
Install and Chapter
Wire, 2
Control Concepts Corporation
328 Water Street
P.O. Box 1360
Blnghamton, NY 139O2-1360
Phone: 607/724-2464
I - 202 (2.5A, 208/240VAC)
I - 207 (7.5A, 208/240VAC)
Electrical Ratlngs
25OV, 3 Amp
lslatrol listing above.
Refer to the
15OV, 80 Joule
13OV,38 Joule
275V, 75 Joule
275V, 140 Joule
Part Number
0804-0196-0000
0802-0273-0000
0802-0304-0000
0802-0266-0000
0802-0405-0000
WATLOW Series 98O/985 User's Manual
Table 1 -
NoiseSuppressIon
Device Ratings
