To assemble your Fee-N-G start by attaching the EVF Standard Mount w/ Rubber Stopper to the
1
DSLR Universal Baseplate w/ Hand Grip as shown
LEFT LOOSE
RIGHT TIGHT
Next, screw combined 7" and 4.5" Rods into
2
the DSLR Universal Baseplate as shown
NOTE:
Using 5/32" allen tighten screw to
secure EVF Standard Mount with
With Rods secure slide Fee-N-G Handle
3
onto Rod as shown and tightren red
ratcheting lever
For more information, watch our tutorial video at Zacuto.com
Assembling your Fee-N-G
Rubber Stopper
Parts
Included:
DSLR Universal
Baseplate w/ Hand Grip
EVF Standard Mount
w/ Rubber Stopper
Z-Lite Double
5/32''
Allen Wrench
Shoulder Pad
Fee-N-G Handle
7'' and 4.5'' Rods
Advertisement
Related Manuals for Zacuto Fee-N-G
Summary of Contents for Zacuto Fee-N-G
- Page 1 Assembling your Fee-N-G Parts To assemble your Fee-N-G start by attaching the EVF Standard Mount w/ Rubber Stopper to the Included: DSLR Universal Baseplate w/ Hand Grip as shown LEFT LOOSE DSLR Universal Shoulder Pad Baseplate w/ Hand Grip RIGHT TIGHT...
- Page 2 Assembling your Fee-N-G With Fee-N-G Handle in place, slide shoulder pad onto rods final assembly LEFT LOOSE PULL UP TO RE-POSITION RIGHT TIGHT NOTE: Finally, slide Z-Lite Double onto rods and tighten red knob until To aid in weight it is secure...
