Zacuto Z-Finder Eyecup Installing

Zacuto Z-Finder Eyecup Installing

Advertisement

Quick Links

1

Remove existing accessories

5
Line up lens ring with the groove inside the
lower lip of eyecup
2

Turn the red diopter clockwise

until it stops (should be raised all
the way up)
6
Apply pressure evenly around upper opening
of eyecup, then press firmly

Installing your Z-Finder Eyecup

3
Replace antifog and sunshield on
top of lens
4
Take the new eyecup and secure the
lens cap to the base of the eyecup
as shown
7

Place lens cap over lens and secure tightly

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z-Finder Eyecup and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Zacuto Z-Finder Eyecup

  • Page 1 Installing your Z-Finder Eyecup Take the new eyecup and secure the Remove existing accessories Turn the red diopter clockwise Replace antifog and sunshield on lens cap to the base of the eyecup until it stops (should be raised all top of lens...
  • Page 2 Installing your Z-Finder Eyecup Flip Z-finder unit upside down to snap Apply pressure with thumbs to hold lens lower lip of eyecup completely over cap and eyecup firmly in place to avoid Precaution the lens ring smudging the antifog shield...
