AGITATOR 20
®
120V
INFORMATION
&
OPERATING
INSTRUCTIONS
DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ
ALL SECTIONS OF THESE INSTRUCTIONS
IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY
1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
2. Never use water with a temperature above 130 °F / 54 °C in the machine.
3. Keep machine from rain and snow, avoid extremes in temperatures, and store
in a heated location. Use the machine indoors only.
4. Use approved chemicals only. NO SOLVENTS.
5. Wear gloves or use rags when removing quick disconnects to prevent burns.
6. Never leave the machine plugged in when you are not attending it.
06.04.2007
Advertisement
Table of Contents
Related Manuals for U.S. Products Agitator 20
Summary of Contents for U.S. Products Agitator 20
- Page 1 AGITATOR 20 ® 120V INFORMATION & OPERATING INSTRUCTIONS DO NOT OPERATE THE MACHINE UNTIL YOU HAVE READ ALL SECTIONS OF THESE INSTRUCTIONS IMPROPER USE OF THE MACHINE WILL VOID THE WARRANTY 1. Always use a defoamer when foaming occurs to prevent vacuum motor damage.
-
Page 2: Cleaning Solutions
UNPACKING: Carefully unpack and inspect your Agitator-20 for shipping damage. Each machine is tested and inspected before shipping. Any shipping damage incurred is the responsibility of the carrier. You should notify the carrier immediately if you notice damage to the box or to the machine or parts. CLEANING SOLUTIONS: We recommend a neutral pH, low foam cleaner, applied to the carpet as a pre-spray. -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS This machine is only suitable for commercial use, for example in hotels, schools, hospitals, factories, shops and offices other than normal residential housekeeping purposes. When using any electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this appliance. -
Page 4: 120Vac Grounding Instructions
120VAC GROUNDING INSTRUCTIONS This machine must be grounded. If it should electrically malfunction, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This machine is equipped with a cord having an equipment-grounding conductor and grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances. - Page 5 AGITATOR 20, 120V Push Button “D” Connector Switch and and Swivel Indicator Snap-Hook Panel Receptacle, Latch, power cord cover Inlet Recovery Recovery Water Hose Water Hose Tank, Filters Clear-vue cover Defoamer Tank 4” Wheel Vacuum Shoe Power Switch and Indicator Light Operation...
-
Page 6: Operation
OPERATION Always use a vacuum cleaner on the carpet in the treatment area before using the Agitator-20. Pre-treat spots, stains and heavy traffic areas before extraction. Consult your local distributor for procedures and/or chemical advice. NOTE: the Agitator-20. is intended to provide a clear water rinse and dirt extraction after application of a pre-spray;... - Page 8 AGITATOR-20 PART LIST 120V ITEM PART No. DESCRIPTION ITEM PART No. DESCRIPTION AG2-BLK Cover, component bay FP423 Spray bar assembly, complete 1392 Stud, foam sensor 1371 Spray tip, 11004 V jet AG3-BLK Vacuum nozzle FP434 Solenoid assembly, complete 1387 Knob, access door FP432 Capacitor assembly, agitator drive 1408...
-
Page 9: Specifications
AGITATOR-20 SPECIFICATIONS: Rotomolded Body: Lifetime Warranty Loop Agitator: Patented design Cleaning Path: 20 inches wide Hoses and Power Cord: 80 feet Defoamer System: Automatic Vacuum Motor: 3-stage, 137” of water lift Water Flow: 1 gpm Dump Pump: 5.5 gpm Water Pressure: 50 -80 psi, typically Agitator Brush Motor: 1/10 HP... - Page 10 AGITATOR 20 ® 120V NOTES: 208-772-0573 800-257-7982 FAX: 208-772-0577 • • Coeur d’Alene, Idaho VISIT US AT: http://www.usproducts.com...
