- Page 1 Kraken Flood Extractor 120V INFORMATION & OPERATING INSTRUCTIONS READ AND UNDERSTAND THESE INSTRUCTIONS BEFORE OPERATING THE MACHINE...
-
Page 2: Table Of Contents
Contents: Machine Specifications Set Up & Operating Instructions Record Important Information Troubleshooting Safety Information & Cautions Unit Exploded View Your New Machine Parts List System Features Vac Box Exploded View Tools & Accessories Wiring Diagram Care & Maintenance Warranty Views of Machine Machine Specifications: Neptune 500 120V Auto Dump Pump... - Page 3 CRITICAL SAFETY INFORMATION & CAUTIONS • To avoid electric shock, do not expose to rain or The acceptable use of this machine is for commercial/professional cleaning, for example, in snow and keep from extremes in temperature. hotels, schools, hospitals, and offices, rather than Store in a heated location.
-
Page 4: Your New Machine
TOOLS & ACCESSORIES: YOUR NEW MACHINE: When you receive your new Kraken Flood The Kraken is designed to be used with Extractor, examine the packaging for signs of all flood extraction tools. shipping damage. Carefully unpack the machine and inspect it. If you see evidence of damage to CARE AND MAINTENANCE: the container or the contents, contact the freight carrier immediately. - Page 5 VIEWS OF THE MACHINE: REAR VIEW FRONT VIEW Recovery Inlet Recovery Access Hose connects here Loading Wheels Power Recovery Tank Drain Cords Hose Dump Out Lifting Hose Handle Connection SIDE VIEW Extraction Tool Switches Vacuum Relief Valve Vacuum 2 Vacuum 1 Pump out Switch Switch...
-
Page 6: Set Up & Operating Instructions
SET-UP AND OPERATION: 1. Before each use, inspect the machine, hoses and power cords NOTE: Foam will not lift the ball float. 2. Make sure filter basket is in place , vacuum inlet cover is locked into position and the cap is pushed into the drain hose. -
Page 7: Troubleshooting
TROUBLESHOOTING ALWAYS UNPLUG THE MACHINE BEFORE DISCONNECTING OR CONNECTING ANY WIRES OR COMPONENTS SYMPTOM POSSIBLE CAUSE No Vacuum No power to Vacuum motors-Check power cords for connection Check that switches are in ON position Check connections on switches for bad connection Weak Vacuum Vacuum inlet cover not latched down Vacuum inlet cover gasket damaged... -
Page 8: Unit Exploded View
Kraken Flood Extractor Exploded View... -
Page 9: Parts List
Kraken Flood Extractor Parts List Item No. Part No. Description 01-10791-001 Recovery Tank Inlet (Molded Part) 01-10789-001 Recovery Tank (Molded Part) 01-10788-001 Base (Molded Part) 01-10787-001 Back Wall (Molded Part) 39-00216 ABS Cover for Ball Floats 41-01342 Gasket for ABS Cover 39-00218 12in. -
Page 10: Vac Box Exploded View
Kraken Flood Extractor Vac Box Exploded View Parts list Item No. Part No. Description Above Unit 05-20035 Vac Box Full Assembly (Replacement) 01-10791-001 Vac Box (Molded Part) 39-00217 ABS Vac Cover 52-00017 Vac Motors 52-00013 Cooling Fan 41-01305 Vac Box Gasket 41-09556 Ball Float Heavy 39-00220... -
Page 11: Wiring Diagram
Wiring Diagram PUMP VAC #2 VAC #1 14GA BLACK WIRE 14GA BLACK WIRE 18GA ORANGE WIRE MARKED #3 12GA BLACK WIRE PUMP FLOAT SWITCH 12GA GREEN WIRE 14GA GREEN WIRE MARKED #1 14GA GREEN WIRE POWER MARKED #2 CORD #2 GROUNDING BAR POWER CORD #1... -
Page 12: Warranty
KRAKEN WARANTY This limited warranty begins on the date of the customers purchase and is valid and available to the original purchaser only. 10-YEAR LIMITED HOUSING WARRANTY Manufacture warrants that all rotationally molded housing and tanks will be free from manufacturing defects, defects in workmanship, and defects in material for Ten (10) years from the date of original purchase, for the original purchaser only.
