Site Master™ S120A, S235A, S250A, S251A
Figure 1. Site Master S251A
1.
INTRODUCTION
This manual provides maintenance instructions for
Site Master S120A, S235A, S250A, S251A Antenna
and Cable Analyzers. It describes the product and
provides performance verification procedures, parts
replacement procedures, and a replaceable parts list.
2.
DESCRIPTION
The Site Master (Figure 1) is a hand held S
mission gain or loss), SWR/RL (standing wave ra-
tio/return loss), and Distance-To-Fault measurement
instrument. It combines a synthesized source, VSWR
Bridge, and receiver on a single printed circuit board
(PCB). An optional power monitor is also available. A
block diagram is shown in Figure 2.
490 JARVIS DRIVE ¨ MORGAN HILL, CA 95037-2809
Anritsu Site Master S120A Specs
Provided by www.AAAtesters.com
MAINTENANCE MANUAL
Antenna and Cable Analyzers
S i t e
(trans-
21
M a
s t e r
S 2 5
1 A
3.
PERFORMANCE VERIFICATION
Paragraphs 4 through 9 contain tests that can be
used to verify the performance of the Site Master
models S120A, S235A, S250A, and S251A having
any version of firmware.
3.1.
Initial Setup for Testing
1.
Press and hold the ESCAPE/CLEAR key,
then press the ON/OFF key to turn on
the Site Master. (This sets the instru-
ment to the factory preset state.)
2.
Release the ESCAPE/CLEAR key and use
the Up/Down Arrow key to adjust the
contrast to give a readable display.
P/N: 10580-00019
REVISION E
PRINTED: OCTOBER 2001
COPYRIGHT 1999-2001 ANRITSU CO.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Site Master S120A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Anritsu Site Master S120A

  • Page 1 PERFORMANCE VERIFICATION This manual provides maintenance instructions for Paragraphs 4 through 9 contain tests that can be Site Master S120A, S235A, S250A, S251A Antenna used to verify the performance of the Site Master and Cable Analyzers. It describes the product and...
  • Page 2: Frequency Accuracy

    2000.0 MHz (S235A and S250A), then press the ENTER key. · Spectrum Analyzer Connect the RF cable from the Site Mas- Anritsu Model MS2602A ter Refl Test Port to the RF Input on the MS2602A. Procedure: Set up the Spectrum Analyzer as follows: Press and hold the ESCAPE/CLEAR key, (a) Press Preset.
  • Page 3 · 10 dB Attenuator, Weinshel 1R-10 Main Menu. · 30 dB Attenuator, Weinshel 1R-30 Press the START CAL key. · Open/Short, Anritsu 22NF50 Follow the instructions on the display to · 50 Ohm Terminations, perform a OSL-THRU-ISOL calibration Anritsu SM/PL or 28N50-2...
  • Page 4: Return Loss Verification

    Measurement calibra- tion of the Site Master is required for this test. Attenuator Equipment Required: · 20 dB offset, Anritsu SC5270 · 6 dB offset, Anritsu SC5237 · Open/Short, Anritsu 22N50 · 50 Ohm Termination, Anritsu 28N50-2 or SM/PL...
  • Page 5 S235A: 20 dB ±1.7 dB · RF Reference Source, 0.050 GHz, Anritsu MA2418A q S250A: 20 dB ±1.7 dB · DC Power Supply, Anritsu 2000-933 q S251A: 20 dB ±1.7 dB Procedure Connect the 6 dB offset to the Refl Test...
  • Page 6 Equipment Required: clicks on and off. · AC-DC Adapter Power Supply 40-115 Remove the short and install the 100 · Open/Short, Anritsu 22NF50 Ohm load. · 100 Ohm, 1 Watt load (100 Ohm, 1 Watt CAUTION resistor soldered from the center pin to The 100 Ohm resistor will get hot.
  • Page 7 0.01 GHz. Press the Enter key. · Open/Short, Anritsu 22N50 (c) Using the Data Entry Keypad or · 50 Ohm Termination, Anritsu 26N50 Data Entry Knob, set the STOP fre- · Source Adapter, Anritsu 34NN50A quency to 4.0 GHz. Press the Enter key.
  • Page 8 Using the Menu up-down keys: Highlight 1: PRECSN RL (A) 10.0 dB/DIV OFFSET +0.0dB PRECISION RL, then press the Select 54147A 2: OFF key. PRECISION RETURN LOSS CALIBRATION At the PRECISION RETURN LOSS menu display, use the Menu up-down CONNECT OPEN TO AIRLINE keys to highlight FINAL, then press the Select key.
  • Page 9: Battery Pack Removal

    10. BATTERY PACK REMOVAL Remove the bottom half (5) and fold it over to lay upside down on the work surface. This procedure provides instructions for removing the battery pack. Refer to Figure 9 during this proce- Disconnect the battery connector from J6 (6) dure.
  • Page 10: Battery Pack Replacement

    (7) to hold the battery Anritsu service center. Service centers will dispose of bracket in place. the unit at no charge. Anritsu service centers are listed in Table 2 on page 13. Reattach the battery connector to J6 (6) on the main RF PCB assembly (3).
  • Page 11: Lcd Replacement

    NOTE 15. MAIN RF PCB ASSEMBLY Carefully use pliers to pull the rub- REPLACEMENT ber tabs tight to ensure that the membrane is flush with the PCB. This procedure provides instructions for replacing the main RF PCB. Refer to Figure 9 during this pro- cedure.
  • Page 12: Replaceable Parts

    NOTE Part Number Description Take care to not lose the Mylar pad under Q5. ND45417 Battery Pack Kit Main PCB Assy, S120A with RF ND45292 Remove the two hex standoff screws and module and cables nuts holding the serial interface connector to Main PCB Assy, S235A with RF the test port panel.
  • Page 13 Table 1. Anritsu Service Centers UNITED STATES FRANCE JAPAN ANRITSU COMPANY ANRITSU S.A ANRITSU CORPORATION 685 Jarvis Drive 9 Avenue du Quebec 1800 Onna Atsugi-shi Morgan Hill, CA 95037-2809 Zone de Courtaboeuf Kanagawa-Prf. 243 Japan Telephone: (408) 776-8300 91951 Les Ulis Cedex...
  • Page 14 NOTES...
