Site Master ™
S251A
Antenna and
Cable Analyzer
User's Guide
Hand-Held Tester For Antennas, Transmission
Lines And Other RF Components
Color Cover P/N: 00986-00022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Site Master S251A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Anritsu Site Master S251A

Summary of Contents for Anritsu Site Master S251A

  • Page 1 Site Master ™ S251A Antenna and Cable Analyzer User's Guide Hand-Held Tester For Antennas, Transmission Lines And Other RF Components Color Cover P/N: 00986-00022...
  • Page 2 WARRANTY The Anritsu product(s) listed on the title page is (are) warranted against defects in materials and workmanship for one year from the date of shipment. Anritsu's obligation covers repairing or replacing products which prove to be defective during the warranty period. Buyers shall prepay trans- portation charges for equipment returned to Anritsu for warranty re- pairs.

  • Page 4: Table Of Contents

    Range Errors ..... 2-29 Replacing the Battery ... . 2-29 Using the Soft Carrying Case..2-35 August 1998 10580-00020 Copyright 1998, Anritsu Co. Revision: A...
  • Page 5 Operation ....3-1 Introduction ....3-1 Operating Functions ... . . 3-1 Making Common Function Selections .
  • Page 6 Device-Under-Test Specification ... 3-20 Procedure ..... . . 3-20 Insertion Gain Mode Selection ... . 3-20 Selecting the Frequency Range .
  • Page 7 Saving Data to a Spreadsheet..4-13 Saving Data to a Database ..4-13 “Drag-n-Drop” ....4-14 Printing.
  • Page 8 If you do not have access to proper disposal methods, return the battery to your Anritsu service center. Anritsu service centers will dispose of the unit at no charge. Anritsu service centers are listed in Table 1-2 (page 1-11).
  • Page 9 S i t e s t e Figure 1-1. Site Master System 1 - 0...

  • Page 10: General Information

    Chapter 1 General Information Introduction This chapter provides a description, performance specifications, op- tional accessories, preventive maintenance, and calibration require- ments for the Site Master model S251A. Throughout this manual, the term Site Master will refer to the model S251A. Model Frequency Range S251A...

  • Page 11: Standard Accessories

    Chapter 1 General Information components in antenna systems. Power monitoring and bias tee capa- bilities are available as options. The displayed trace can be scaled and/or enhanced with settable frequency markers and/or a limit line. A menu option provides for an audible “beep” when the limit value is ex- ceeded.

  • Page 12: Options

    Option 5 — Add RF Wattmeter Power Monitor • Option 10 — Add Bias Tee • Optional Accessories Anritsu Precision N (m) Short/Open, Part No. 22N50 • Anritsu Precision N (f) Short/Open, Part No. 22NF50 • Site Master Precision N (m) Load, 42 dB, Part No. SM/PL •...
  • Page 13 Chapter 1 General Information Adapter, Precision N (f) to N (f), Part No. 34NFNF50 • Adapter, 7/16 (f) to N (m), Part No. 510-90 • Adapter, 7/16 (f) to N (f), Part No. 510-91 • Adapter, 7/16 (m) to N (m), Part No. 510-92 •...

  • Page 14: Performance Specifications

    Chapter 1 General Information Transit Case for Site Master, Part No. 760-215 • HP Deskjet 340 Printer, Part No. 2000-766 • Serial-to-Parallel Converter Cable (use with the HP 340 • Printer), Part No. 2000-753 Seiko DPU-414 Thermal Printer, Part No. 2000-754 (U.S.) or •...
  • Page 15 Chapter 1 General Information Table 1-1. Performance Specifications (1 of 2) Specifications are valid when the unit is calibrated at ambient tem- perature after a 5 minute warmup. Description Value Frequency Range: 625 to 2500 MHz Frequency Accuracy (RF Source 75 parts per million @ 25 C* Mode) Frequency Resolution...
  • Page 16 Chapter 1 General Information Table 1-1. Performance Specifications (2 of 2) Wattmeter Power Monitor: Range –50.0 to +20 dBm or 10.0 nW to 100.0 mW Offset Range 0 to +60.0 dB Resolution 0.1 dB or 0.1 xW Test Port, Type N 50 Ohms ***Immunity to Interfering signals up to the level of...

  • Page 17: Preventive Maintenance

    Chapter 1 General Information Preventive Maintenance Site Master preventive maintenance consists of cleaning the unit and inspecting and cleaning the RF connectors on the instrument and all ac- cessories. Clean the Site Master with a soft, lint-free cloth dampened with water or water and a mild cleaning solution.

  • Page 18: Calibration

    Thus, cables which are NOT phase stable may cause measure- ment errors that are more pronounced as the test fre- quency increases. For optimum calibration, Anritsu recommends using precision calibration components. 1 - 9...

  • Page 19: Annual Verification

    Anritsu recommends an annual calibration and performance verifica- tion of the Site Master and the OSL calibration components by local Anritsu service centers. Anritsu service centers are listed in Table 1-2 beginning on the following page. The Site Master itself is “self calibrating”, meaning that there are no field-adjustable components.
  • Page 20 Chapter 1 General Information Table 1-2. Anritsu Service Centers (1 of 2) UNITED STATES CHINA ANRITSU COMPANY ANRITSU BEIJING SERVICE CENTER 685 Jarvis Drive Beijing Fortune Building Morgan Hill, CA 95037-2809 416W, 5 Dong San Huan Bei Lu Telephone: (408) 776-8300...
  • Page 21 Chapter 1 General Information Table 1-2. Anritsu Service Centers (2 of 2) ISRAEL SOUTH AFRICA TECH-CENT, LTD ETESCSA Haarad St. No. 7, Ramat Haahayal 1st Floor Montrose Place Tel-Aviv 69701 Waterfall Park, Becker Road Telephone: (03) 64-78-563 MIDRAND FAX: (03) 64-78-334...
  • Page 22 Chapter 1 General Information This page intenionally blank. 1 - 13...
  • Page 23 S i t e s t e Figure 2-1. Site Master Controls and Connectors 2 - 0...

  • Page 24: Connectors And Controls

    Indicator light to show that the Site Master is being Power powered by the external charging unit. Serial Provides an RS232 DB9 interface with a Com Port Interface on a personal computer (for use with the Anritsu 2 - 1...

  • Page 25: Keypad Controls

    Chapter 2 Connectors and Controls Software Tools program). Also provides an interface to a HP Deskjet 340 printer or a Seiko DPU-411/ DPU-414 Thermal printer. Refl Test Provides RF output, 50 impedance. Port Trans Test Provides RF input, 50 impedance. Port RF Det Provides RF detector input for the Power Monitor.
  • Page 26 Chapter 2 Connectors and Controls ESCAPE Exits the present operation and/or clears the display. CLEAR If a parameter is being edited, pressing this key will clear the value currently being entered and restore the last valid entry. Pressing this key again will close the parameter.
  • Page 27 Chapter 2 Connectors and Controls When in the Hold mode, the hold symbol (Table 2-1, page 2-30) appears on the left side of the LCD. (HOLD conserves considerable battery power.) +/– When in the Gain/Insertion Loss measurement mode, the +/– key is used in conjunction with the Scale Menu to toggle the top, bottom, and limit numerical value sign.
  • Page 28 Chapter 2 Connectors and Controls SAVE Saves the current system setup to 1 of 4 internal SETUP non-volatile memory locations. When the key is pressed, “Save Setup:” appears on the display. Select an appropriate number using the Up/Down Arrow key and press the ENTER key to implement. CAUTION:The selected memory location will be over- written by the SAVE SETUP operation.
  • Page 29 Chapter 2 Connectors and Controls Connect LOAD to REFL and TRANS ports, press ENTER The Site Master then measures the isolation (50 termination load) that you must attach to the end of the Refl test port and the Trans test port. Connect REFL port to TRANS port, Press ENTER The Site Master then measures the through...

  • Page 30: Soft Keys And Menus

    Chapter 2 Connectors and Controls Figure 2-2. Site Master Front Panel Display Layout Soft Keys and Menus Each of the soft keys has a corresponding soft key label area on the dis- play. The label identifies the function of the soft key for the current menu selection.
  • Page 31 Chapter 2 Connectors and Controls Figure 2-3. Site Master Menu Structure 2 - 8...
  • Page 32 Chapter 2 Connectors and Controls Main Menu At turn on, the Main Menu soft keys, below, are dis- played, and the Marker status is shown in the mes- sage area. These soft keys provide the following menu selec- tions: MODE — Selects the type of measurement. Use the Up/Down Arrow key and the ENTER key to select the type of measurement in the FREQ, DTF, POWER MONITOR, and RF SOURCE measure-...
  • Page 33 Chapter 2 Connectors and Controls When the DTF measurement mode is selected, the Main Menu Main Menu soft keys, below, are displayed, and the Marker status is shown in the message area. These soft keys provide the following menu selec- tions: MODE —...
  • Page 34 Chapter 2 Connectors and Controls Power When the Power Monitor measurement mode is se- Monitor lected, the Main Menu soft keys, below, are dis- Main Menu played, and the units, relative, offset, and zero adjust status are shown in the message area. UNITS —...
  • Page 35 Chapter 2 Connectors and Controls MAIN — Returns to the Main Menu. RF Source When the RF Source measurement mode is selected, Main Menu the Main Menu soft keys, below, are displayed and the frequency is shown in the message area. FREQ —...
  • Page 36 Chapter 2 Connectors and Controls Frequency Provides for setting sweep frequency end-points. Se- Menu lected frequency values may be changed using the (FREQ) keypad or Up/Down Arrow key. Choosing FREQ causes the soft keys, below, to be displayed and the corresponding values to be shown in the message area.
  • Page 37 Chapter 2 Connectors and Controls Scale Menu Provides for changing the display scale. Selected val- (SCALE) ues may be changed using the Up/Down Arrow key or keypad. Choosing SCALE causes the soft keys, below, to be displayed and the corresponding values to be shown in the message area.
  • Page 38 Chapter 2 Connectors and Controls Option Provides for selecting Site Master options. Menu (OPT) Choosing OPT causes the soft keys, below, to be dis- played and the corresponding values to be shown in the message area. B1 MATH — Opens a menu of trace math operation modes;...
  • Page 39 Chapter 2 Connectors and Controls Option Provides for selecting additional Site Master options. Sub-Menu Choosing MORE causes the soft keys, below, to be displayed and the corresponding values to be shown in the message area. B5 UNITS — Toggles between ENGLISH and METRIC units.
  • Page 40 Chapter 2 Connectors and Controls Distance Provides for setting Distance to Fault parameters. Se- Menu lected distance values may be changed using the key- (DIST) pad or Up/Down Arrow key. Entry can be in feet or meters, depending on the setting of the B5 soft key in the Option Sub-Menu (page 2-16).
  • Page 41 Chapter 2 Connectors and Controls NOTE: Refer to Appendix A for a listing of common coaxial cables showing values for “Relative Propaga- tion Velocity”and “Nominal Attenuation in dB/m @ 1000 MHz”. Distance Provides for setting the cable loss and relative propa- Sub-Menu gation velocity of the coaxial cable.
  • Page 42 Chapter 2 Connectors and Controls CABLE — Opens a cable folder containing a stan- dared cable list and a custom cable list. Use the Up/Down Arrow key and ENTER key to select ei- ther the standard cable list or custom cable list. Then, use the Up/Down Arrow key and ENTER key to make a cable selection from the selected list.
  • Page 43 Chapter 2 Connectors and Controls WINDW — Opens a menu of FFT windowing types for the DTF calculation. Scroll the menu using the Up/Down Arrow key and make a selec- tion with the ENTER key. NOTE: Using Windowing The theoretical requirement for inverse FFT is for the data to extend from zero frequency to infinity.
  • Page 44 Chapter 2 Connectors and Controls Figure 2-4. Rectangular Windowing Example Figure 2-5. Nominal Side Lobe Windowing Example 2 - 21...
  • Page 45 Chapter 2 Connectors and Controls Figure 2-6. Low Side Lobe Windowing Example Figure 2-7. Minimum Side Lobe Windowing Example 2 - 22...
  • Page 46 Chapter 2 Connectors and Controls Markers Provides for setting marker values. Selected fre- Menu quency marker or distance marker values may be changed using the keypad or Up/Down Arrow key. Pressing the MARKER key causes the soft keys, be- low, to be displayed and the corresponding values to be shown in the message area.
  • Page 47 Chapter 2 Connectors and Controls Markers Provides for turning the selected marker on and off Menu and for setting marker values. Selected frequency (2nd Level) marker and distance marker values can be changed using the keypad or Up/Down Arrow key. Choosing M1 causes the soft keys, below, to be dis- played and the corresponding values to be shown in the message area.
  • Page 48 Chapter 2 Connectors and Controls Markers Provides selections for placing the selected marker at Menu the frequency or distance with the maximum or mini- (3rd Level) mum SWR, RL CL, or IL/IG. Choosing MORE causes the soft keys, below, to be displayed and the corresponding values to be shown in the message area.

  • Page 49: Determining Remaining Battery Life

    Chapter 2 Connectors and Controls Determining Remaining Battery Life When the AC-DC adapter is disengaged from the Site Master, a bat- tery indicator symbol is continuously displayed at the top-right corner of the display (Figure 2-8). A totally black bar indicates a fully charged battery.

  • Page 50: Printing

    Chapter 2 Connectors and Controls Printing Printing is accomplished with any of the following printers: the Seiko DPU-411 thermal printer, the Seiko DPU-414 thermal printer, or the Hewlett Packard DeskJet 340 ink jet printer. Figure 2-9 shows a setup diagram for these two types of printers. Printer Switch Settings Set the switches, SW1 and SW2, on the Seiko DPU-411 thermal printer as follows:...

  • Page 51: Printing A Screen

    Chapter 2 Connectors and Controls Printing a Screen Step 1. Connect the printer as shown in Figure 2-9. Step 2. Obtain a SWR, RL, CL, Insertion Loss/Insertion Gain, or Distance-to-Fault measurement display. Step 3. Select the printer using the B7 soft key from the Option Sub-Menu (page 2-16).

  • Page 52: Symbols

    A listing of Range Error messages is given in Table 2-3. Replacing the Battery Replacing the battery is the only recommended field-level maintenance action. If your battery fails, contact your Anritsu Sales Office or Serv- ice Center. Table 1-2 (page 2-11) provides a listing of current service centers.
  • Page 53 Indicates internal data processing. Lock fail indication. Check battery. (If Site Master fails to lock with a fully charged bat- tery, call your Anritsu Service Center.) Processor timeout failure. Symbol appears at the frequency that causes an input RF overload;...
  • Page 54 OUT OF TEMP. specified operating range. Return tempera- RANGE ture to specified operating range. If condi- tion persists, call your Anritsu Service Center. Note: A listing of current Anritsu service centers is given in Table 1-2, page 1-11. 2 - 31...
  • Page 55 Chapter 2 Connectors and Controls Table 2-3. Range Error Messages (1 of 3) Error Message Description RANGE The start (F1) frequency is greater than the ERROR:F1 > F2 stop (F2) frequency. The start (D1) distance is greater than the RANGE ERROR:D1 >...
  • Page 56 Chapter 2 Connectors and Controls Table 2-3. Range Error Messages (2 of 3) Description Error Message DIST REQUIRES Valid distance to fault plots require a non- zero frequency span. F1 < F2 DIST REQUIRES Distance-to-fault measurements do not pro- vide usable data with CAL OFF. NO STORED Attempting to recall a display from a loca- SWEEP AT THIS...
  • Page 57 Chapter 2 Connectors and Controls Table 2-3. Range Error Messages (3 of 3) Error Message Description Attempting to use Bias Tee function without BIAS TEE OPTION NOT INSTALLED Option 10 installed. BIAS TEE ONLY Attempting to use Bias Tee function without external power connected to the battery re- VALID WHEN charger port.

  • Page 58: Using The Soft Carrying Case

    Chapter 2 Connectors and Controls Using the Soft Carrying Case The soft carrying case has been designed such that the strap can be un- snapped to allow the case to be easily oriented horizontally; thus allow- ing the Site Master controls to be more easily accessed (Figure 2-10). Figure 2-10.

  • Page 59: Operation

    Chapter 3 Operation Introduction This chapter provides a description of the Site Master operating func- tions and examples of frequency domain and distance domain mea- surements. Operating Functions Site Master operation is divided into five functional areas: common functions, frequency domain, distance domain, power monitor, and RF source.
  • Page 60 Chapter 3 Operation Distance domain measurements—commonly known as • distance-to-fault (DTF)—are made over a selectable distance range. They include RL or SWR, but they also return informa- tion that can help locate discontinuities in a transmission line. CL cannot be measured in the distance domain. Power monitor measurements can be either absolute or rela- •...

  • Page 61: Making Common Function Selections

    Chapter 3 Operation Making Common Function Selections Common functions are options, marker, and scale functions that are common to both frequency- and distance-domain measurements. Applying Power Step 1. Turn the Site Master on using the ON/OFF key. Step 2. Observe that the Site Master opening screen appears and that it performs a self test.

  • Page 62: Setting Scale/Limits

    Chapter 3 Operation Refer to pages 2-23 thru 2-25 for a description of marker functions. Setting Scale/Limits Step 7. Press the SCALE key on the keypad or the SCALE soft key, from the Main Menu. Step 8. Accept or change the settings. To change, press the applicable TOP, BOTTOM, or LIMIT soft key and either: Enter a numeric value from the keypad and press...

  • Page 63: Return Loss (Swr) And Cable Loss (One Port) Measurement

    Required Equipment Site Master Model S251A • Precision Open/Short, Anritsu 22N50 • Precision Load, Anritsu SM/PL • Test Port Extension Cable, Anritsu 15NNF50-1.5A • Device-Under-Test Specification Type Typical Loss @1.5m 0.40 dB @800 MHz 0.45 dB @900 MHz 15NNF50-1.5A 0.86...
  • Page 64 Chapter 3 Operation Step 3. Use the Up/Down Arrow key to scroll to Return Loss (or SWR). Press the ENTER key to select Return Loss (or SWR) measurement mode. Calibration Measurement S i t e s t e Figure 3-1. One-Port Calibration/Measurement Setup...

  • Page 65: Selecting The Frequency Range

    Chapter 3 Operation Selecting the Frequency Range Step 4. Press the FREQ soft key. Step 5. Press the F1 soft key. Step 6. Enter 8,0,0 using the keypad or Up/Down Arrow key. Press ENTER to set F1 to 800 MHz. Step 7.
  • Page 66 Chapter 3 Operation Figure 3-2. Return Loss Measurement Mode Calibration Results Figure 3-3. SWR Measurement Mode Calibration Results...

  • Page 67: Cable Return Loss Measurement

    Chapter 3 Operation Cable Return Loss Measurement Step 13. Disconnect the Load and connect the test port exten- sion cable to the REFL test port. Connect the Load to the open end of the test port extension cable as shown in Figure 3-1. Setting the Limit Line Step 14.
  • Page 68 Chapter 3 Operation Figure 3-4. Cable Return Loss Measurement Results Figure 3-5. Cable SWR Measurement Results 3-10...

  • Page 69: Saving Display To Memory

    Chapter 3 Operation Saving Display to Memory Step 20. Press the SAVE DISPLAY key to save the return loss measurement. Press ENTER to save to the cur- rent empty memory location or use the keypad or the Up/Down Arrow key to select another memory loca- tion.

  • Page 70: Saving Display To Memory

    Chapter 3 Operation Saving Display to Memory Step 24. Press the SAVE DISPLAY key to save the cable loss measurement to the next memory location (see step 20 for details). Figure 3-6. Cable Loss Measurement Results 3-12...

  • Page 71: Dtf Measurement

    (DTF) measurement over a selectable distance range. Required Equipment Site Master Model S251A • Precision Open/Short, Anritsu 22N50 • Precision Load, Anritsu SM/PL • Test Port Extension Cable, Anritsu 15NNF50-1.5A • Device-Under-Test Specification Type Typical Loss @1.5m 0.40 dB @800 MHz 0.45 dB @900 MHz 15NNF50-1.5A 0.86...
  • Page 72 Chapter 3 Operation Step 4. In the DTF parameters table, scroll to D2 using the Up/Down Arrow key, then press ENTER to select cable length. NOTE: Where CAL ON is indicated on the Site Master , press the DIST soft key, then the DTF AID soft key to acti- vate the DTF parameters table.

  • Page 73: Performing A Calibration

    Chapter 3 Operation Step 9. Enter ., 8, 6 using the keypad or Up/Down Arrow key. Press ENTER to set PROP VEL value to 0.86. Step 10. Use the Up/Down Arrow key to scroll to LOSS and press ENTER to customize cable loss. Step 11.

  • Page 74: Dtf Measurement (Determining The Length Of The Cable)

    Chapter 3 Operation DTF Measurement (Determining the Length of the Cable) Step 16. Disconnect the Load and connect the test port exten- sion cable to the REFL test port. Connect the Short (or Open) to the open end of the test port extension cable as shown in Figure 3-1.
  • Page 75 Chapter 3 Operation Figure 3-7. DTF-Return Loss Measurement Results (Cable Length) Figure 3-8. DTF-SWR Measurement Results (Cable Length) 3-17...

  • Page 76: Dtf Measurement (Determining The Quality Of The Cable)

    Chapter 3 Operation DTF Measurement (Determining the Quality of the Cable) Step 20. Disconnect the Short (or Open) and connect the Load to the test port extension cable (Figure 3-1). Optional: Press the AUTO SCALE key to optimize the amplitude scale. Step 21.
  • Page 77 Chapter 3 Operation Figure 3-9. DTF-Return Loss Measurement Results (Cable Quality) Figure 3-10. DTF-SWR Measurement Results (Cable Quality) 3-19...

  • Page 78: Insertion Gain (Amplifier) Measurement

    Gain (Amplifier) measurement over a selectable frequency range. Required Equipment Site Master Model S251A • (2) Precision 7/16(f) Open/Short/Load, Anritsu 2000-768 • (2) Test Port Extension Cable, Anritsu 15NDF50-1.5A • 7/16(f) Adapter, Anritsu 510-97 • Tower Mount Amplifier, Ericsson A57001HQ85 • Device-Under-Test Specification...

  • Page 79: Selecting The Frequency Range

    Chapter 3 Operation Selecting the Frequency Range Step 4. Press the FREQ soft key. Step 5. Press the F1 soft key. Step 6. Enter 1, 8, 4, 0 using the keypad or Up/Down Arrow key. Press ENTER to set F1 to 1840 MHz. Step 7.
  • Page 80 Chapter 3 Operation S i t a s t S 2 5 Figure 3-11. Two-Port Measurement Calibration Setup 3-22...
  • Page 81 Chapter 3 Operation Step 15. When the measurement is complete, disconnect both Loads from the test port extension cables and con- nect the 7/16(f) adapter to the open ends of the test port extension cables to complete a through path from the REFL to TRANS test port.

  • Page 82: Amplifier Gain Measurement

    Chapter 3 Operation Amplifier Gain Measurement Step 16. Disconnect the 7/16(f) adapter. The resulting display should be similar to Figure 3-13. Figure 3-13. Measurement Display before Amplifier Connection Step 17. Connect the amplifier to the test port extension ca- bles as shown in Figure 3-14. Setting the Markers Step 18.
  • Page 83 Chapter 3 Operation S i t e s t e 2 5 1 Figure 3-14. Amplifier Gain Measurement Setup 3-25...
  • Page 84 Chapter 3 Operation Step 19. Press the M1 soft key to select the M1 marker func- tion. Press the EDIT soft key and enter 1, 8, 8, 0 us- ing the keypad or Up/Down Arrow key. Press ENTER to set M1 to 1880 MHz. (Note: Pressing the ON/OFF soft key activates or deactivates the M1 marker function.) Step 20.

  • Page 85: Activating The Bias Tee

    Chapter 3 Operation Activating the Bias Tee Step 22. Press the MAIN soft key to return to the Main menu. Step 23. Press the OPT soft key, then the B3 soft key to acti- vate the bias tee. NOTE: The Site Master must have Option 10 installed and the battery charger must be connected for the bias tee to activate.

  • Page 86: Saving Display To Memory

    Chapter 3 Operation Figure 3-16. Measurement Display of Amplifier Gain Saving Display to Memory Step 25. Press the SAVE DISPLAY key to save the amplifier gain measurement. Press ENTER to save to the cur- rent empty memory location or use the keypad or the Up/Down Arrow key to select another memory loca- tion.

  • Page 87: Making Power Measurements

    Chapter 3 Operation Making Power Measurements Power measurement is accomplished using a broadband (1 Mhz to 3 Ghz) RF detector, P/N 5400-71N50. The power monitor displays the measured power in dBm or Watts. Entering Power Monitor Mode Step 1. Press the MODE soft key, from the Main menu (page 2-9).

  • Page 88: Displaying Power In Dbm And Watts

    Chapter 3 Operation Displaying Power in dBm and Watts Step 7. Press the UNITS soft key to display power in Watts. Displaying Relative Power Step 8. With the desired base power level input to the Site Master, press the REL soft key. The message area will show REL: ON and the power reading will indi- cate 100%.

  • Page 89: Rf Source Operation

    Chapter 3 Operation RF Source Operation RF source allows the user to generate a single CW frequency with +6 dBm or –30 dBm output power within the instrument’s operating frequency band. Generating a CW Frequency Step 1. Press the MODE soft key, from the Main menu (page 2-9).

  • Page 90: Software Tools Program

    Chapter 4 Software Tools Program Description The Site Master Software Tools program provides the means for trans- ferring the measured trace, along with any applied markers and/or a limit, to the screen of an MS-DOS based personal computer (PC) run- ning Windows, Windows for Workgroups 3.xx, Windows NT, or Win- dows 95.

  • Page 91: Communication Port Setting

    Chapter 4 Software Tools Program Communication Port Setting The Site Master Software Tools communicates with the Site Master through a standard COM port on the PC. It is important that your Win- dows COM port settings conform to the actual hardware settings. Table 3-1 provides a listing of standard COM port settings for most IBM AT-Compatible computers.
  • Page 92 Chapter 4 Software Tools Program Figure 3-1. Windows 3.1 COM Port Setting Dialog Boxes Step 4. Change to the following settings if necessary: Baud Rate: 9600 Data Bits: Parity: None Stop Bits: Flow Control: None Step 5. Click on the Advanced... button. At the Advanced Settings dialog box verify the COM Port Base Address and IRQ.

  • Page 93: Changing Com Port Settings-Windows 95

    Chapter 4 Software Tools Program Note: If you changed the COM Port Base Address and/or IRQ, you will need to restart Windows. Figure 3-2. Windows 95 COM Port Setting Dialog Boxes Changing COM Port Settings–Windows 95 Refer to Figure 3-2 while performing the following procedure. Step 1.
  • Page 94 Chapter 4 Software Tools Program Step 4. Double click on the item Ports (COM & LPT) in the device list. Step 5. Double click on the Communications Port you want to set. The Communications Port Properties window appears. NOTE: If Windows doesn't show any available COM Ports, consult your computer manufacturer.

  • Page 95: Software Installation

    For users new to Windows 3.x, a detailed procedure is given below. Step 1. Insert the Anritsu Site Master Software Tools For Windows disk in floppy drive A:\ or B:\. Step 2. In the Windows Program Manager, pull down the File menu and select Run.
  • Page 96 Chapter 4 Software Tools Program Serial Interface S i t e s t e r S 2 5 Com port (Program defaults to Com2) Figure 3-3. Equipment Setup for Site Master Tools Operation Step 7. Double-click on the “Site Master Help” icon to ac- quaint yourself with the comprehensive on-line man- ual.

  • Page 97: Plot Capture

    Chapter 4 Software Tools Program Plot Capture Plots (traces) can be captured either singly from the Site Master dis- play or in multiples from one or more stored-display locations. Both methods are described below. The recommended method is the Capture Multiple Traces option in the Capture pull-down menu.

  • Page 98: Capture Multiple Traces To Pc Screen

    Chapter 4 Software Tools Program Step 4. Click on Capture, in the top menu bar, and select Capture Multiple to Database from the drop-down menu. Step 5. Follow the database instructions to download the plot(s) to either a new database or an existing data- base.

  • Page 99: Single Trace Capture

    Chapter 4 Software Tools Program Single trace capture Step 1. Perform steps 1, 2, and 3 of the capture-multiple-to- database procedure. Step 2. Click on “Start a Plot Capture” icon or click on Capture, in the top menu bar, and select Start Cap- ture from the drop-down menu.

  • Page 100: Program Operation

    Chapter 4 Software Tools Program Program Operation The captured trace on the PC can be scaled and have its limit line, markers, and properties changed. (Select Plot Properties under the View menu to make these changes.) The operation of the various menus that allow these operations to be accomplished is straightfor- ward.

  • Page 101: Smith Chart Software

    Chapter 4 Software Tools Program Smith Chart Software After obtaining a frequency SWR or RL plot on the computer display, click the Smith Chart icon. Read the Help file to see how this feature functions (under Smith Chart and Data Readout). Saving a Plot as a Windows Metafile Plots can be saved as Windows Metafiles (.WMF).

  • Page 102: Saving Data To A Spreadsheet

    Chapter 4 Software Tools Program Saving Data to a Spreadsheet The data points from a plot can be exported to a spreadsheet via the clipboard. To transfer data to a Windows spreadsheet program: Step 1. Select Settings and Clipboard Format from the top menu bar and pull-down menu and choose Format- ted Text.

  • Page 103: Drag-N-Drop

    Chapter 4 Software Tools Program “Drag-n-Drop” Site Master Software Tools is Windows based. Graphs can “Drag-n- Drop” onto each other. Site Master Software Tools allows quick com- parison of “before” and “after” Distance-To-Fault measurements. Re- cent data is compared to a historical PC database record, which is usually recorded during site installation/commissioning.
  • Page 104 Appendix A Reference Data Description Table A-1 provides a standard listing of common coaxial cables along with their “Relative Propagation Velocity” and “Nominal Attenuation in dB/m @1000 MHz” values. Figure A-1 (page A-4) is a plot of maxi- mum range and resolution vs frequency span. Table A-1.
  • Page 105 Appendix A Reference Data Table A-1. Coaxial Cable Technical Data (2 of 3) Relative Propagation Nominal Attenuation Cable Type Velocity ( V dB/m @ 1000 MHz FSJ1-50A 0.840 0.197 FSJ2-50 0.830 0.134 FSJ4-50B 0.810 0.119 LDF4-50A 0.880 0.077 LDF5-50A 0.890 0.043 LDF6-50 0.890...
  • Page 106 Appendix A Reference Data Table A-1. Coaxial Cable Technical Data (3 of 3) Relative Propagation Nominal Attenuation Cable Type Velocity ( V dB/m @ 1000 MHz HCC300-50J 0.960 0.014 HCC312-50J 0.960 0.013 HF 4-1/8" Cu2Y 0.970 0.010 HF 5" Cu2Y 0.960 0.007 HF 6-1/8"...

  • Page 107: Appendix A Reference Data

    Appendix A Reference Data Figure A-1. Maximum Distance and Resolution vs Frequency Span...
