Chapter 4: Configure the Network Interfaces
5 Enter the IP address and the Gateway of the route in the
appropriate field.
The gateway of the route is the local interface of the router.
6 Click Submit.
To remove a route, select the appropriate entry and click Remove.

View Network Statistics

The SOHO 6 has a configuration page that displays a variety of
network statistics to assist in monitoring data traffic as well as
troubleshooting potential problems.
Follow these instructions to view this page:
1 With your Web browser, go to the System Status page using the
Trusted IP address of the SOHO 6.
For example, if using the default IP address, go to: http://192.168.111.1
2 From the navigation bar on the left side, select
Network = > Network Statistics.
The Network Statistics page appears.
42 WatchGuard Firebox SOHO 6.1
