Chapter 2 – ADSL Ethernet Modem Description
The ADSL2+ Ethernet Modem is the perfect high-speed WAN bridge/router. This full-
featured product is specifically designed to connect to the Internet and directly connect
to your local area network via high speed 10/100 Mbps Ethernet. The Modem has also
full NAT firewall and DMZ services to block unwanted users from accessing your
network.
For game users, the ADSL Modem had already pre configured for several low latency
game ports. Just click on the game you are playing on line and the rest is done for you.
The ADSL Modem is fully compatible with all PCs; as long as the PC supports an
Ethernet interface and is running a TCP/IP protocol stack, your PC can have high-speed
WAN access. So, plug in the ADSL Modem (refer to easy start guide), configure it (per
your ISP's requirements) and enjoy the fast Internet access like never before.
2.1

ADSL Modem Overview

Fig 1-1 shows the system configuration diagram of a typical ADSL Modem connection.

Figure 1-1 : ADSL Modem Configuration Diagram
