KALEA BAY FIREPLACE
See-Through Conversion Kits
Kits: 78009 (36" Fireplace)
78010 (48" Fireplace)
78011 (60" Fireplace)
78012 (72" Fireplace)
Installation Instructions
IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS
DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT
PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE
REV. A
Page 1
PN#90060
Advertisement
Related Manuals for Firegear KALEA BAY
Summary of Contents for Firegear KALEA BAY
- Page 1 KALEA BAY FIREPLACE See-Through Conversion Kits Kits: 78009 (36” Fireplace) 78010 (48” Fireplace) 78011 (60” Fireplace) 78012 (72” Fireplace) Installation Instructions IF YOU CANNOT READ OR UNDERSTAND THESE INSTALLATION INSTRUCTIONS DO NOT ATTEMPT TO INSTALL OR OPERATE THIS PRODUCT PLEASE RETAIN THIS MANUAL FOR FUTURE REFERENCE REV.
- Page 2 NOTE: Some installers may prefer installing the hood(s) before the glass clips, if so, proceed to Step #13 first, then begin at Step #1. Notice: This manual is only a guide to assist with installation of this kit. Ensure you use the Kalea Bay LED Fireplace installation manual for final preparations and wiring diagrams. Kalea Bay LED See-Thru Conversion Kit REV.
- Page 3 Discard back panel and replace the screws previously removed. Side View Detail for Removal Rear Panel Screws BACK VIEW REAR PANEL INSTALLED Nailing Flange Valve Bottom Fin Fig. 2 Removing back wall to convert to see-through model. Kalea Bay LED See-Thru Conversion Kit REV. A Page 3...
- Page 4 Use a fingertip or pliers to carefully press the tab flat against the metal bridge. See Fig. 5. Fig. 5 Installing windshield clips (right side shown) Kalea Bay LED See-Thru Conversion Kit REV. A Page 4...
- Page 5 Step 8: Insert the windshield support into the back glass clip. Install in same manner on the right side. See Figs. 8 & 9. Windshield support installed in glass clip Windshield Support Sits Here Fig. 8 Installing windshield support. Fig. 9 Windshield supported installed. Kalea Bay LED See-Thru Conversion Kit REV. A Page 5...
- Page 6 The protruding area of the hood angles downward to deflect heat, see Hood Detail below. Hood Screw Locations SIDE VIEW FRONT VIEW Hood Hood Detail End View (De ector Facing Downward) Fig. 11 Installing hood(s) on the fireplace. Kalea Bay LED See-Thru Conversion Kit REV. A Page 6...
- Page 7 See Kalea Bay installation manual for any warranty questions. FOR TECHNICAL SERVICE, CALL: (800) 966-8126 Firegear Outdoors 17322 Gothard Street Huntington Beach, CA 92647 WEB SITE: www.firegearoutdoors.com Kalea Bay LED See-Thru Conversion Kit REV. A Page 7...
