  • Page 1 HMF 10-55 Installatörshandbok, HMF 10-55 Installer manual, HMF 10-55 Installateurhandbuch, HMF 10-55 IHB 1450-1 331276...
  • Page 3 Svenska, Installatörshandbok - HMF 10-55 Allmänt Innehåll Detta tillbehör används då F1155/F1255 installeras 1 st HMF 10 mot elnätet för att förhindra eventuell störning från värmepumpen. 1 st Compact connector 3-P 1 st Kablage Winsta 5G2,5 1 st Kabelfäste 1 st...
  • Page 4 HMF 10-55 Konstruktion Kabelfäste Elkomponenter Anslutningsplint (Brun ledare) Anslutningsplint (Svart ledare) Anslutningsplint (Grå ledare) Jordpunkt Övrigt Typskylt Beteckningar i komponentplacering enligt standard IEC 81346-1 och 81346-2.
  • Page 5 Det är viktigt att elanslutningen görs med rätt fasföljd. Kontakt HMF 10-55 ska installeras via allpolig brytare med minst 3 mm brytaravstånd. Minsta kabelarea ska vara dimen- 3. Koppla ihop kontakten med kablage Winsta 5G2,5. sionerad i förhållande till avsäkringen som ska vara 4.
  • Page 6: Tekniska Data

    3 x 10 A Märkfrekvens ~ 50 Hz Art nr 218 667 Genomföring 6. Anslut kablage Winsta 5G2,5 till HMF 10-55 i kopplingsplint L1-L3. Brun ledare Svart ledare Grå ledare 7. Koppla ihop den blå ledaren (N) i kablage Winsta 5G2,5 med den blå...
  • Page 7 English, Installer manual - HMF 10-55 General Contents This accessory is used when F1155/F1255 is installed HMF 10 to the electrical network to prevent any interference from the heat pump. Compact connector 3-P Wiring Winsta 5G2,5 Cable mount Nut M8...
  • Page 8 HMF 10-55 Design Cable mount Electrical components Terminal block (Brown cable) Terminal block (Black cable) Terminal block (Grey cable) Ground terminal Miscellaneous Type plate Designations in component locations according to standard IEC 81346-1 and 81346-2.
  • Page 9: Electrical Connection

    NOTE It is important that the electrical connection is made with the correct phase sequence. HMF 10-55 must be installed via an isolator switch with Contact a minimum breaking gap of 3 mm. Minimum cable area must be dimensioned in relation to the fuse rating 3.
  • Page 10: Technical Specifications

    (GND) with supplied nut and washer. 9. Secure the cable mounting in the designated place and tighten the cable tie around the wiring Winsta 5G2,5. 10. Connect the external cable to HMF 10-55 in termin- al block L1-L3. Brown cable Black cable...
  • Page 11 Deutsch, Installateurhandbuch - HMF 10-55 Allgemeines Inhalt Dieses Zubehör wird verwendet, wenn F1155/F1255 1 St. HMF 10 mit dem Stromnetz verbunden wird, um etwaige Stö- rungen von der Wärmepumpe zu verhindern. 1 St. Compact connector 3-P 1 St. Verkabelung Winsta 5G2,5 1 St.
  • Page 12 HMF 10-55 Konstruktion Kabelbefestigung Elektrische Komponenten Anschlussklemme (brauner Leiter) Anschlussklemme (schwarzer Leiter) Anschlussklemme (grauer Leiter) Erdungspunkt Sonstiges Typenschild Bezeichnungen der Komponentenpositionen gemäß Standard IEC 81346-1 und 81346-2.
  • Page 13: Elektrischer Anschluss

    1. Das Zubehör HMF 10-55 wird gemäß der folgenden Elektrischer Anschluss Anleitung mit F1155/F1255 verbunden. 2. Lösen Sie den Anschluss in F1155/F1255 von der HINWEIS! Elektroheizpatronenplatine im linken Schalt- Alle elektrischen Anschlüsse müssen von einem schrank. geprüften Elektriker ausgeführt werden.
  • Page 14: Technische Daten

    Scheibe im Lieferumfang. 9. Bringen Sie die Kabelbefestigung an der angege- benen Position an und fixieren Sie Kabelstrang Winsta 5G2,5 mit Kabelbinder. 10. Verbinden Sie das externe Kabel mit HMF 10-55 an Anschlussklemme L1-L3. Brauner Leiter Schwarzer Leiter Grauer Leiter...
  • Page 15 Sakregister Sakregister Allgemeines, 11 Allmänt, 3 Contents, 7 Design, 8 List of components, 8 Electrical connection, 9 Elektrischer Anschluss, 13 Elinkoppling, 5 General, 7 Inhalt, 11 Innehåll, 3 Konstruktion, 4, 12 Komponentenverzeichnis, 12 Komponentlista, 4 Technical Specifications, 10 Technische Daten, 14 Tekniska Data, 6...
