  • Page 1 Operating manual HK 200S Inner unit Cooperating with air heat pumps 07.09.2016...
  • Page 2 Canceling the settings. SMO 40 The room temperature setting mode is selected by pressing the OK button twice from the start mode lev- el in the main menu. More information to be found in section Room temperature setting. HK 200S...

  • Page 3: Table Of Contents

    Removal of the covers _________________6 8 Service ___________________ 31 3 Indoor module structure _____ 7 Maintenance service _________________31 HK 200S ___________________________7 9 Distorted heat comfort ______ 32 4 Pipe connections ___________ 9 General pipe connections ______________9 Dimensions and pipe connections _______12...

  • Page 4: Important Information

    1 Important information Information regarding Serial number safety The serial number is located at the top of HK 200S. This manual contains installation and maintenance proce- dures for specialists. The device can be operated by childred aged over 8 and persons with physical, sensoric, or mental dis-...
  • Page 5 Mixing valve Safety valve Power supply Communication connection Circuit fuses Fuses, internal module Building fuses temperature sensor outdoor Room sensor Energy meter Emergency switch Switch differential Thermostat emergency mode setting Miscellaneous Connected to HK 200S Chapter 1 | Important information...

  • Page 6: Supply And Operation

    2 Supply and operation Transport Included items HK 200S heat pump must be transported and stored vertically in a dry place. HK 200S can be, however, carefully placed on the rear side of the casing when carrying the device into the building. Assembly...

  • Page 7: Indoor Module Structure

    3 Indoor module structure HK 200S XL10 BT12 XL11 BT64 QN12 GP12 BT15 BT25 BT63 QN10 BT71 EB15 HK 200S Chapter 3 | Indoor module structure...
  • Page 8 Diaphragm expansion vessel, closed QN10 Isolation valve, domestic hot water / cen- tral heating Różne QN12 Isolation valve, cooling/heating EB15 HK 200S GP12 Circulation pump Serial number Heat exchanger Domestic hot water tank Chapter 3 | Indoor module structure HK 200S...

  • Page 9: Pipe Connections

    The system can cooperate with a low- and medium- heating system temperature heating system. Recommended temper- The inner capacity of HK 200S for the purposes of ature of the heating medium at minimum designed calculating the diaphragm expansion vessel in the outdoor temperature DOT must not exceed 55°C on...
  • Page 10 Installation diagram The HK 200S indoor unit is equipped with a coil water The connection of the outdoor unit and indoor unit heater, diaphragm expansion vessel , safety group, HK 200S with a system of pipes filled with a cooling...
  • Page 11 The floor must be solid, concrete at best. • The HK 200S module must be set with its back • to the outer wall, at best in a room where noise is not a problem.

  • Page 12: Dimensions And Pipe Connections

    Connection, cold water Ø22 mm Connection, circulation Ø15 mm Connection, liquid cooling medium ⅜” Connection, gas cooling medium ⅝” XL10 Connection, cooling Ø22 mm XL11 Connection, safety group Ø22 mm, manometer Other information Serial number plate Chapter 4 | Pipe connections HK 200S...

  • Page 13: Connection Options

    Pipe connections of the heating system are to be made at the top. All the required protections and cut-off valves • must be installed as close to the HK 200S mod- ule as possible. Where necessary, install the vents. •...
  • Page 14 R100~R150). Do not bend pipes many Ø9.52 times. Use a bending machine. 0.0~0.5 0.7~1.3 Ø15.88 • Connect the socket connection and tighten with appropriate torque. Apply the appropriate tighten- ing angle if the torque wrench is not available. Chapter 4 | Pipe connections HK 200S...
  • Page 15 Pressure test and leakage test IMPORTANT Both HK 200S and AMS 10 are factory-tested for In the case of systems with cooling medium pipes with the length of up to 15 m, the supplied volume of the pressure and leakage, but pipe connections between cooling medium is sufficient.
  • Page 16 Connections General information NIBE SPLIT can be connected in many various ways. More information on connections to be found at web- site www.nibe.eu. Mounting requirements AMS 10-8 AMS 10-12 Max pressure, climate system 0.25 MPa (2.5 Bar) Highest recommended supply/return temperature at dimensioned outdoor 55/45 °C...
  • Page 17 20 mm thickness. floor heating pipes have been equipped with thermo- HK 200S is not equipped with cut-off valves, which stat valves, in order to assure appropriate flow, install must be installed outside the indoor module to make a discharge valve or a buffer in the parallel layout, or future maintenance easier.

  • Page 18: Electrical Connections

    0.5 mm² with the length of up to 50 m, for example EKKX or LiYY, or similar. When laying cables in HK 200S, apply cable • passes UB1 and UB2 (as marked in the illustra- tion).

  • Page 19: Connections

    The cable must be dimensioned according to the applicable standards. HK 200S must be connected to the power supply 400 V 3N AC 50Hz as specified on the clamp (X2). Electrical connections...
  • Page 20 Connection between HK 200S and AMS 10 Connections between HK 200S and SMO 20/40 The conductor connecting the devices must be con- Power supply connection nected to the power supply clamp (TB) at AMS 10 SMO 20/40 must be connected via the cut-off switch and to clamp (X2) at HK 200S.
  • Page 21 X4:1 (A), X4:2 (B) and X4:3 (GND), according ing. to the drawing. SMO 20 SMO 20 SMO 20 SMO 20 SMO 20 SMO 20 HK 200S Externt HK 200S HK 200S HK 200S GP12 SMO 40 SMO 40 AA5- X4...
  • Page 22 X6:15 and X6:16.Use a two-wire cable with the cross- section of at least 0.5 mm². SMO 20 SMO 20 SMO 20 SMO 20 SMO 20 SMO 20 HK 200S HK 200S HK 200S HK 200S SMO 40 SMO 40 AA3-X6 SMO 40...
  • Page 23 - see SMO40 installation man- ual. Use a two-wire cable with the cross-section of at least 0.5 mm². SMO 20 SMO 20 SMO 20 SMO 20 HK 200S SMO 20 HK 200S HK 200S BT25 HK 200S BT63...
  • Page 24 AUX2 AUX1 AUX2 AUX3 AUX3 AUX4 SMO 20 SMO 20 AUX4 SMO 20 SMO 20 SMO 20 SMO 20 HK 200S HK 200S HK 200S HK 200S BT64 BT71 SMO 40 SMO 40 AUX1 AUX 1 AUX2 AUX 2 AUX3...
  • Page 25 4.9.3 and menu 5.1.12. All auxiliary heaters can be blocked by connecting the potential-free relay function to clamp X2 of the program-controlled input (see SMO manual, Chap- ter Electrical connections, section Optional Connec- HK 200S tions). HK 200S K2 K3 AA7-X2...
  • Page 26 Isolation valve (QN10) SMO 40 HK 200S is equipped with an isolation valve (QN10) for hot water regulation. Connect the isolation valve (QN10) to clamps X4:2 AA3-X7 (N), X4:3 (control) and X4:4 (L) at motherboard (AA2), AA3-X7 SMO 40 as shows in the drawings.

  • Page 27: Settings

    The volume of domestic hot water is limited. Load sensor has not been connected. • • Constant temperature in the supply pipeline; more information to be found in the Chapter w Emergency Mode Thermostat. Electrical connections HK 200S Chapter 5 |...

  • Page 28: Start-Up And Regulation

    2. Check whether the drain valve has been com- pletely closed, and whether the temperature lim- iter has not been activated (F3). 3. Compatible NIBE air/water heat pumps have been listed in the Connection Options section. Filling and venting Filling the DHW heater at HK 200S 1.

  • Page 29: Start-Up And Acceptance

    Pump speed Start-up and acceptance The circulation pump in HK 200S is controlled by fre- Start-up wizard quency, and is automatically regulated via control and based on the heating demand. IMPORTANT Before setting the SMO controller switch in the posi- tion „I”, fill the heating system with water.

  • Page 30: Control

    Service (Menu 5) Advanced settings. These settings are not available to the end user. This menu will be visible if the Back button is pressed in the start menu for 7 seconds. Chapter 7 | Control HK 200S...

  • Page 31: Service

    Maintenance service IMPORTANT Maintenance service must only be performed by per- sons with the required technical knowledge. When replacing components in HK 200S, use exclu- sively original spare parts. Emergency mode Emergency mode is used in the event of problems with operation and during maintenance service.

  • Page 32: Distorted Heat Comfort

    Accessories that can be used depend on the applied Control Module SMO 20 or SMO 40. The list of all possible accessories can be found in the relevant manual of the Control Module applied. Chapter 9 | Distorted heat comfort HK 200S Chapter 10 | Accessories...

  • Page 33: Technical Data

    11 Technical data Dimensions and layout of connections 93.5 92.5 87 63 600.5 20-40 HK 200S Chapter 11 | Technical data...
  • Page 34 Enamel + titanium anode Anticorrosive protection Maximum DHW capacity 230 l, 40°C Kit energy class 12 kW AMS 10 + HK 200S + SMO Energy class (acc. to ErP, at supply temp. 55°C) Performance class / Load profile (DHW) A/XL Chapter 11 |...

  • Page 35: Diagram Of Electrical Connections, 3X400V

    Diagram of electrical connec- tions, 3 x 400 V HK 200S Chapter 11 | Technical data...
  • Page 36 Chapter 11 | Technical data HK 200S...
  • Page 37 HK 200S Chapter 11 | Technical data...
  • Page 38 Notes: HK 200S...
  • Page 39 HK 200S...
  • Page 40 NIBE-BIAWAR Sp. z. o.o. 15-703 Białystok, al. Jana Pawła II 57 Tel. 85 662 84 90, fax. 85 662 84 09 e-mail: sekretariat@biawar.com.pl...
