Thank you for purchasing the Kirsch
quality materials. To avoid errors and save valuable time, please read these instructions before installing your new shade.
Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation.
Tools You Will Need
Pencil or Marker
■
Needlenose Pliers
■
Carpenter's Level
■
Mounting Fasteners
■
Parts
All the required installation components are wrapped in your package along with these instructions. Check that the parts you have
correspond to the parts shown below.
NOTE: Some parts may vary depending upon your chosen shade system or mounting option.
Installation Brackets
■
Spacer Blocks (optional)
■
Extension Bracket (optional)
■
Side Mount Bracket (optional)
■
Screws
■
STEP 1: Mounting the Brackets
The installation brackets may be for INSIDE or OUTSIDE mounts.
Mounting the brackets level is essential for proper operation of the shade. Shim the brackets if necessary to achieve a level
■
alignment.
The bracket requirements and placements are the same for inside and outside mounts. Refer to the following spacing diagram
■
and bracket requirement chart.
Inside Mounts
For inside mounts the installation brackets will be screwed in place through the top hole of each bracket. Refer to the mounting
depth chart below.
Minimum Depth
1"
NOTE: Prior to mounting the brackets, add any clearance depth required to avoid obstructions such as window cranks or
handles.
GETTING STARTED
®
Basics Cellular Shade Collection. This shade has been custom built for you from the highest
INSTALLATION
Fully Recessed
2-
⁄
"
1
2
Measuring Tape
■
Phillips Screwdriver
■
Power Drill
■
Shade Width
31-
79-
2
Brackets
Required
12" to 31"
2
⁄
" to 79"
3
1
8
⁄
" to 84"
4
1
8
