SPECIFICATIONS*

Specifications
Model
Camera TYPE
Scanning
Min. Scene Illumination
WDR
DIP Switch
Lens
Resolution
Video Output
S/N Ratio
Environmental Conditions
Power
Physical Specification
Certifications
MC355T
Color
Mount
Device
Pixels-Total
Pixels-Effective
System
Horizontal Frequency Internal Mode
Vertical Frequency Internal Mode
F1.2
Wide Dynmic Range
NTSC/PAL
Length
Horizontal
VBS 1.0Vp-p
S/N Ratio
Operating Temperature
Humidity
Power Requirement
Power Consumption
Dimensions(φ x H)
Nema Type
Weight
CE, FCC, RoHS
Vandal-Proof Micro Dome Camera
Surface
1/3" PIXIM
742(H) x 552(V)
720(H) x 540(V)
525 line, 2:1Interlace
15,734Hz
59.94Hz
0.08 Lux, 0.01 Lux [TDN]
120dB [Max]
ON / OFF
3.6mm Fixed Lens
480TV Lines [Color], 520TV Lines [B/W]
VBS 1.0Vp-p(75 Load)
48dB
-10℃ ~ +55℃(14℉ ~ 131℉)
Less than 90%
12VDC
1.5W or Less
80 X 59.5 mm (3.15 X 2.34 in)
IP66
255g (0.562 lbs)
Certified
