CAMERA SETTINGS*

Camera Position Adjustment :
(1) Loosen the SCREW(B) on the UPPER CASE(C), using L-WRENCH(A).
(2) Separate BOTTOM CASE(E) from UPPER CASE(C) by twisting UPPER CASE(C) to the right.
(3) Separate CLEAR DOME(D) from BOTTOM CASE(E).
(4) Fix the camera gimbal located in the BOTTOM CASE(E).
(5) Assemble CLEAR DOME(D) and UPPER CASE(C) with BOTTOM CASE(E).
(6) Tighten SCREW(B) onto UPPER CASE(C), using L-WRENCH(A).
