Step 8: Plug in and connect
the 50A current sensors
If your Vue has 50A sensors, open the clasps
on the 50A sensors and place each sensor
clamp around the hot leg from the breaker
you wish to monitor. Then shut the clasps to
secure the sensors.
imprint on the bottom of the sensors should
point away from the breakers.
the plugs attached to them into the 2.5mm
ports on the sides of the energy monitor. Note
the port numbers so you can name the
circuits in the app.
IMPORTANT! The K→L
Then, insert
WARNING: The service
mains are always live!
Breaker
Load
