- Page 1 In-Wall 802.11ac Wave 2 Wi-Fi Access Point Model: UAP-IW-HD...
-
Page 2: Package Contents
Introduction Thank you for purchasing the Ubiquiti Networks® UniFi® In‑Wall 802.11ac Wave 2 Wi‑Fi Access Point. This Quick Start Guide is designed to guide you through installation and also includes warranty terms. UniFi Controller v5.7 is recommended for IMPORTANT: managing the UAP-IW-HD and is available for download at: www.ubnt.com/download/unifi... -
Page 3: System Requirements
System Requirements • Linux, Mac OS X, or Microsoft Windows 7/8/10 • Java Runtime Environment 1.8 (or above) • Web Browser: Google Chrome (Other browsers may have limited functionality.) • UniFi Controller software v5.7 or newer (available at: www.ubnt.com/download/unifi) Network Topology Requirements •... -
Page 4: Hardware Overview
Hardware Overview Back Panel PoE In + Data 10/100/1000 Ethernet port supports data and PoE In + Data 802.3af PoE input. The UAP-IW-HD itself requires 11W. 802.3at PoE+ input is required to use PoE passthrough. Connect this port to a UniFi Switch with PoE that is connected to your LAN and DHCP server. -
Page 5: Bottom Panel
Bottom Panel Reset PoE Out + LAN 1 LAN 3 LAN 4 LAN 2 10/100/1000 Ethernet port supports data PoE Out + LAN 1 and PoE passthrough (requires 802.3at PoE+ input). The maximum PoE passthrough output is 12W. Note: To power and connect an 802.3af device to the LAN, you must use 802.3at PoE+ input. - Page 6 Color State Status Flashing Initializing. White Steady Factory defaults, waiting for integration. Device is busy; do not touch or Alternating White/ unplug it. This usually indicates that a process such as a firmware Blue upgrade is taking place. Steady Successfully integrated into a network and working properly.
-
Page 7: Side Panel
Side Panel Security Screw Security Screw (Optional) The Security Screw secures the Cover Plate after installation. You have the option to use the included Torx (shown) or Philips Security Screw. -
Page 8: Security Tab
Security Tab In addition to the optional Security Screw, the Security Tab helps to secure the Cover Plate after installation. If you need to remove it, use a flathead screwdriver to depress the Security Tab while detaching the Cover Plate: Security Tab... -
Page 9: Back Plate
Back Plate The Back Plate offers a variety of mounting holes for use with different wall boxes. Here are a few examples with the appropriate mounting holes outlined in blue: USA or China Europe... -
Page 10: Hardware Installation
Hardware Installation An electrical wall box should be pre‑installed with an Ethernet cable running from the box to a UniFi Switch with PoE. 1. Detach the UAP-IW-HD from the Back Plate. 2. Pull the Ethernet cable through the Back Plate, and attach the Back Plate to the wall box using the Wall‑Mount Screws. - Page 11 3. Connect the Ethernet cable in the wall box to the port labeled PoE IN + DATA. 4. Attach the UAP-IW-HD to the Back Plate using the two Torx or Phillips Screws.
- Page 12 5. Attach the Cover Plate to the bottom of the UAP-IW-HD. Then press the Cover Plate into position until the Security and mounting tabs snap into place. 6. Optional: Secure the Cover Plate to the UAP-IW-HD using the included Torx or Phillips Security Screw.
-
Page 13: Software Installation
UniFi Controller management interface. For information on configuring and using the UniFi Controller software, refer to the User Guide. Mobile App Installation Ubiquiti Networks also offers the UniFi mobile app, which is available from the App Store® (iOS) or Google Play ™ Store (Android). -
Page 14: Specifications
Specifications UAP-IW-HD Dimensions 139.7 x 86.7 x 25.75 mm (5.5 x 3.41 x 1.01") Weight 210 g (7.41 oz) (5) 10/100/1000 Ethernet Ports Networking Interface Button(s) Reset Power Method 802.3af PoE Supported 802.3at PoE+ Supported Power Supply UniFi Switch (PoE) Power Save Supported 48V Passthrough (Pins 1, 2+;... -
Page 15: Safety Notices
Safety Notices Read, follow, and keep these instructions. Heed all warnings. Only use attachments/accessories specified by the manufacturer. Do not use this product in a location that can WARNING: be submerged by water. WARNING: Avoid using this product during an electrical storm. -
Page 16: Limited Warranty
Ubiquiti MAC label, or is missing any other original (VI) Ubiquiti label(s); or (VII) has not been received by Ubiquiti within 30 days of issuance of the RMA. In addition, the above warranty shall apply only if: the product has been properly installed and used at all times in accordance, and in all material respects, with the applicable Product documentation;... - Page 17 No Products will be accepted for replacement or repair without obtaining a Return Materials Authorization (RMA) number from UBIQUITI NETWORKS during the warranty period, and the Products being received at UBIQUITI NETWORKS’ facility freight prepaid in accordance with the RMA process of UBIQUITI NETWORKS.
-
Page 18: Limitation Of Liability
Limitation of Liability EXCEPT TO THE EXTENT PROHIBITED BY LOCAL LAW, IN NO EVENT WILL UBIQUITI OR ITS SUBSIDIARIES, AFFILIATES OR SUPPLIERS BE LIABLE FOR DIRECT, SPECIAL, INCIDENTAL, CONSEQUENTIAL OR OTHER DAMAGES (INCLUDING LOST PROFIT, LOST DATA, OR DOWNTIME COSTS), ARISING... - Page 19 Compliance Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions. This device may not cause harmful interference, and This device must accept any interference received, including interference that may cause undesired operation.
- Page 20 ISED Canada CAN ICES-3(A)/NMB-3(A) This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: This device may not cause interference, and This device must accept any interference, including interference that may cause undesired operation of the device. This radio transmitter (IC: 6545A-UAPIWHD) has been approved by ISED Canada.
-
Page 21: Rf Exposure Warning
RF Exposure Warning The antennas used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be located or operating in conjunction with any other antenna or transmitter. Les antennes utilisées pour ce transmetteur doivent être installé... - Page 22 RoHS/WEEE Compliance Statement English European Directive 2012/19/EU requires that the equipment bearing this symbol on the product and/or its packaging must not be disposed of with unsorted municipal waste. The symbol indicates that this product should be disposed of separately from regular household waste streams.
- Page 23 Español La Directiva 2012/19/UE exige que los equipos que lleven este símbolo en el propio aparato y/o en su embalaje no deben eliminarse junto con otros residuos urbanos no seleccionados. El símbolo indica que el producto en cuestión debe separarse de los residuos domésticos convencionales con vistas a su eliminación.
-
Page 24: Declaration Of Conformity
Íslenska [Icelandic] Hér með lýsir UBIQUITI NETWORKS yfir því að UAP-IW-HD er í samræmi við grunnkröfur og aðrar kröfur, sem gerðar eru í tilskipun 2014/53/EU. Fullur texti ESB samræmisyfirlýsing er að finna á eftirfarandi netfangi: www.ubnt.com/compliance... -
Page 25: Online Resources
New York, NY 10017 ©2018 Ubiquiti Networks, Inc. All rights reserved. Ubiquiti, Ubiquiti Networks, the Ubiquiti U logo, the Ubiquiti beam logo, and UniFi are trademarks or registered trademarks of Ubiquiti Networks, Inc. in the United States and in other countries. Apple and the Apple logo are trademarks of Apple Inc., registered in the United States and in other countries.
