Display
17) Machine Serial #
*=Next D=Back
USE FOR
CHANGER SN?
1-YES
18) FILL / DISPENSE: Allows coin count to be viewed for up to 5 coin changer
tubes. Coins may be dispensed from tubes 1 through 5.
Display

18) FILL / DISPENSE

*=Next D=Back
Select Tube 1 to 5
# - EXIT
19) TOKENS & COUPONS – This allows the machine to recognize coupons and
tokens as free vends when the Promotional feature is on. Item and price will be
recorded as a free vend in the DEX
Display
19) TOKENS & COUPONS
*=Next D=Back
Tokens / Coupons off
*= Change
20) FIELD TEST – Enters a diagnostic mode to allow troubleshooting
assistance.
Display

20) FIELD TEST

*=Next D=Back
Press # to Exit Test
Press # to Exit Test
S XXX E
a) Press the #=Yes key to enter Menu
#=Yes Option.
d) Select 1 to assign this number to
coin changer. Select 2 if no.
2-NO d) Select option 1 or option2.
a) Press the #=Yes key to enter Menu
Option.
#=Yes
b) Enter any tube number: 1 to 5 to
dispense a coin and view coin count.
report.
a) Press the #=Yes key to enter menu
#=Yes option.
b) Press the "*" key to scroll between
"On" and "Off".
#=Accept
c) Press the "#" key to accept selection.
a) Press the #=Yes key to enter Menu
Option.
#=Yes
b) Second line displays changes to the
position of switches and encoders.
c) Move any motor by pressing the
associated Service Keypad key.
d) Press "VAC" key. The Vacuum
Pump will turn on then slowly turn off.
e) Press * key to inspect position
YYY sensor values for Shoulder and Elbow
Sensors.
- 38
