ERASE ALL PROGRAMMED INFORMATION:
On occasion it may become necessary to erase all programmed and sales data.
Press the VAC button on the Service Keypad to release the security locking
feature.
Go to the Service Menu and press the "*" key repeatedly until the display reads,
"4) Create Selection". Press and hold the Reset button. The VMC will beep as
you hold the Reset button. The display will immediately read:
Continue holding the Reset button. The VMC will continue to beep. The display
will change to:
Continue holding the Reset button. The VMC will continue to beep. The display
will change to:
Release the reset button and press the #-Yes button. You will be prompted to
"SET ARM AT LEFT WALL". Position the arm shown in figure 9A in the previous
section. Press the "#" key to accept. Display will show "SELECTION STORED"
Now you will be prompted to "SET ARM AT DELIVERY". Position the arm as
shown in figure 9B in the previous section. Press the "#" key to accept. Display
will show "SELECTION STORED"
You may now program your selections as described in the "PROGRAMMING
YOUR MACHINE" section.
THIS FORCES RE-SETUP
*-Next D-Back
Arm Uncalibrated
*-Next D-Back
Products Cleared
*-Next D-Back
- 30
#-Yes
#-Yes
#-Yes
