The Handset Layout

1
2
3
4
5
6
7
8
1. Antenna
2. Earpiece
3. Headset Jack and Audio
Patch Cable Jack (2.5mm)
4. Soft/Select Key
5. On/Flash Key
6. Dialing Keys (0-9, * , #)
7. Speakerphone Key
8. Speakerphone LED
9. Message LED
10. Colour LCD Display
11. 5-Way Joystick
12. Volume Keys
13. Softkey
14. Off/Cancel Key
15. Sound Select Key
16. Microphone
17. USB Cable Jack
5
9
10
11
12
13
14
15
16
17
