Important Safety Instructions
When using your telephone equipment, basic safety precautions should always be followed
to reduce the risk of fire, electric shock and injury, including the following:
1. Read and understand all instructions.
2. Follow all warnings and instructions marked on the product.
3. Unplug this product from the wall outlet before cleaning. Do not use liquid or aerosol
cleaners. Use a damp cloth for cleaning.
4. Do not use this product near water (for example, near a bath tub, kitchen sink or
swimming pool).
5. Do not place this product on an unstable surface such as a table, shelf or stand.
The product may fall, causing serious damage.
6. Slots and openings in the back or bottom of the Base Unit and Handset are provided
for ventilation. To protect them from overheating, these openings must not be
blocked by placing the product on a soft surface such as a bed, sofa or rug. This
product should never be placed near or over a radiator or heat register. Nor should
this product should not be placed in any area where proper ventilation is not
provided.
7. This product should be operated only from the type of power source indicated on
the packaging. If you are not sure of the type of power supply in your home, consult
your dealer or local power company.
8. Do not allow anything to rest on the power cord. Do not install this product where
the cord may have anyone walking on it.
9. Never push objects of any kind into this product through slots in the Base or Handset
as they may touch dangerous voltage points or short out parts that could result in
a risk of fire or electric shock. Avoid spilling liquid of any kind on the product.
10. To reduce the risk of electric shock, do not disassemble this product, but take it to
an authorized service facility. Opening or removing parts of the Base or Handset
other than specified access doors may expose you to dangerous voltages or other
risks. Incorrect reassembling can cause electric shock when the product is
subsequently used.
11. Do not overload wall outlets and extension cords as this can result in the risk of fire
or electric shock.
12. Unplug this product from the wall outlet and refer servicing to an authorized service
facility under the following conditions:
A. When the power supply cord or plug is damaged or frayed.
B. If liquid has been spilled onto the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions, as
improper adjustment of other controls may result in damage and often requires
extensive work by an authorized technician to restore the product to normal
operation.
E. If the product has been dropped and the Base and/or Handset has been damaged.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the i 5867 and is the answer not in the manual?

Questions and answers

Summary of Contents for VTech i 5867

  • Page 1 Important Safety Instructions When using your telephone equipment, basic safety precautions should always be followed to reduce the risk of fire, electric shock and injury, including the following: 1. Read and understand all instructions. 2. Follow all warnings and instructions marked on the product. 3.
  • Page 2: Important Safety Instructions

    Handset is next to your ear. WARNING: To insure your safety from possible electric shock, only use the enclosed VTech Audio Patch Cable to record custom ring tones. Do NOT leave the Audio Patch Cable attached to the Handset while charging in its cradle.
  • Page 3 Your i 5867 is an advanced cordless telephone that operates in the 5.8GHz frequency range. Your i 5867 is capable of supporting up to a maximum of 8 Handsets. Using additional Handsets, up to 2 people can be conferenced on a call (2 Handsets), or two extensions can be conferenced on a call, while two other extensions can be talking inter- nally, using the Intercom feature.
  • Page 4: Parts Checklist

    6. Quick Start Guide To purchase replacement battery cells, call VTech Communications, Inc. at 1-800- 595-9511. In Canada, call VTech Telecommunication Canada Ltd. at 1-800-267-7377. Note: Use only VTech batteries (part number 80-5461-00-00) or equivalent AA NiMH re- chargeable batteries. OPER...
  • Page 5: The Handset Layout

    The Handset Layout OPER OPER OPER TONE TONE TONE Antenna In Use/Incoming Ringing LED Earpiece 10. LCD Display Headset Jack and Audio 11. Navigation Key (NavKey) Patch Cable Jack (2.5mm) 12. Volume Keys Soft/Select Key 13. Softkey On/Flash Key 14. Off/Cancel Key Dialing Keys (0-9, *, #) 15.
  • Page 6: The Base Unit Layout

    The Base Unit Layout 1. Volume Keys 10. Menu 2. Charging LED 11. Mailbox Keys (Play/Stop) 3. Repeat/Slow 12. In Use LED 4. Skip/Quick 13. Page 5. Delete 14. On/Off 6. Record 15. Spare Battery Drawer 7. Change 16. Spare Battery Release Button 8.
  • Page 7 Base Unit, and allow it to charge for at least 12 hours. After initial charge, a maintenance charge of 8 hours should be sufficient. The original Handset that is shipped with your i 5867 system will be automatically registered to the Base. This Handset is HANDSET 1.
  • Page 8: Charging Of The Handset Battery Cells

    Base ID to register the new Handset. Charging of the Handset Battery Cells The Handset of your i 5867 cordless telephone is powered by rechargeable battery cells which charge automatically whenever the Handset is in its Base Unit or charger.
  • Page 9 Setup Tone/Pulse Selection Your i 5867 is preset for tone dialing. See Settings for tone/pulse options and other details. CAUTION: Use only the VTech power supply provided with your telephone. FOR MAXIMUM PERFORMANCE IMPORTANT: OF YOUR CORDLESS TELEPHONE SYSTEM: 1. Choose a central location for your Base Unit.
  • Page 10: Spare Battery Charger/Power Backup Feature

    Spare Battery Charger/Power Backup Feature Power Guard Feature The i 5867 uses the spare battery charger in the Base Unit to provide power backup in the event of a power failure or outage. With fully charged battery cells in the spare battery charger, you will be able to place and receive calls from the Handset only, for up to 2 1/2 hours during a power outage.
  • Page 11: Installation/Registration Of Accessory Handset

    Expand your i 5867 system by adding accessory Handsets. Bring telephone service to rooms where a phone jack isn’t available! Your VTech i 5867 system can operate up to 8 Handsets. To order additional Handsets (model number i 5803 or i 5807), call VTech Customer Service at 1-800-595-9511. In Canada, call: 1-800-267-7377.
  • Page 12: Installation Of Accessory Handset

    12 OPER OPER OPER hours. After the initial charge, a TONE TONE TONE maintenance charge of 8 hours should be sufficient. DC 6V CORDLESS TELEPHONE MODEL: 5807 VTECH TELECOMMUNICATIONS LTD. DC 6V 300mA CLASS 2 POWER SOURCE ONLY...
  • Page 13: Registration Of Accessory Handset

    Base ID Code. NOTE: The 15-digit BASE ID Code may contain numbers and characters, including 0 through 9, as well as *. Make sure you enter all 15 digits. Congratulations! You can now enjoy the benefits of your VTech Multi-Handset system.
  • Page 14: Handset And Base Indicators

    Handset and Base Indicators Handset Icons Icon Description Line In Use Indicator On steady with one or more numbers next to it, indicating which exten- • sions are using the line. For example, 12 indicates that Handset 1 and Handset 2 are on an outside call. Indicates when a parallel set is in use.
  • Page 15: Handset Leds

    On/Off Charging • On when the Handset is charging in the cradle. • Lights when the line is being used by a i 5867 system Handset. IN USE • Flashes when another telephone on the same line (parallel exten- sion) is in use or when the answering machine is currently answering a...
  • Page 16: Handset Menu

    Handset Menu Navigation Keys (NavKeys): Press any NavKey to display the Main Menu. Press the NavKeys (left, right, up and • down) to maneuver through menus. Press the middle NavKey to select the highlighted menu item. Menu Shortcuts When viewing menu options, pressing the corresponding number on the dialing pad will •...
  • Page 17 If there are no entries, the screen will display Phonebook is empty. The i 5867 Handset can store up to 50 numbers with names in the phonebook directory, along with a distinctive ring and image for each. Each memory location can hold...
  • Page 18 Handset Menu When prompted to Enter Name, use the digit keys to spell the name. Each press of a key will cause characters to be displayed as follows: Number Key Characters (in order) & ’ Space Adding Phonebook Entries From the Handset idle (OFF) mode, press any •...
  • Page 19 Handset Menu Enter the number you want to store in the Phonebook. • Press and hold the # key to insert a pause. If you make a mistake, press the softkey. When finished, press OK. The screen will display: NOTE: If you do not wish to assign a distinctive ring tone or image to this Phonebook entry, press SAVE now.
  • Page 20 Handset Menu NOTE: For directions on the Picture Download Fea- ture, please refer to page 26. Once you’ve selected a picture, press SAVE. • 3 of 11 Your phonebook entry has been saved and the • screen will display: John Smith Pat Johnson Rose 3 of 11...
