  • Page 1 S3100/S3100M...
  • Page 3 Preface Notebook Computer S3100/S3100M Service Manual...
  • Page 4 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent ven- dor.
  • Page 5 This manual is intended for service personnel who have completed sufficient training to undertake the maintenance and inspection of personal computers. It is organized to allow you to look up basic information for servicing and/or upgrading components of the S3100/ S3100M series notebook PC.
  • Page 6 Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock and injury to per- sons when using any electrical equipment: 1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
  • Page 7 Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
  • Page 8 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong mag- netic fields. These can hinder proper performance and damage your data. Take care when using peripheral devices. Use only approved brands of Unplug the power cord before peripherals.
  • Page 9 Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
  • Page 10 Preface Related Documents You may also need to consult the following manual for additional information: User’s Manual on CD/DVD This describes the notebook PC’s features and the procedures for operating the computer and its ROM-based setup pro- gram. It also describes the installation and operation of the utility programs provided with the notebook PC. System Startup 1.

  • Page 11: Table Of Contents

    Contents Introduction ..........1-1 Top ....................A-3 Bottom ................... A-4 Overview ..................1-1 LCD (S3100) ................. A-5 Specifications ..................1-2 LCD (S3100M) ................A-6 External Locator - Top View with LCD Panel Open ......1-4 HDD ....................A-7 External Locator - Front & Right Side Views .........1-5 Schematic Diagrams.........
  • Page 12 Preface Card Reader / LAN JMC251 ............B-26 LAN (JMC 251), SATA HDD ............. B-27 KBC-ITE IT8502E ............... B-28 BT / Power LED / USB CONN ........... B-29 Fan, Click / Charge ............... B-30 Audio Codec VIA1812 ..............B-31 5VS, 3.3VS, 1.5VS / Power SW ..........B-32 Power 1.5V / 0.75V / 1.8V ............

  • Page 13: Introduction

    Chapter 1: Introduction Overview This manual covers the information you need to service or upgrade the S3100/S3100M series notebook computer. Infor- mation about operating the computer (e.g. getting started, and the Setup utility) is in the User’s Manual. Information about dri-vers (e.g. VGA & audio) is also found in the User’s Manual. The manual is shipped with the computer.

  • Page 14: Specifications

    Introduction Specifications Processor Security Intel® Core™ i3 Mobile Processor Kensington Lock Slot i3-330UM (1.20GHz) BIOS Password  3MB L3 Cache, 800MHz FSB, TDP:18W Intel® Pentium® Processor Audio Latest Specification Information U5400 (1.20GHz) The specifications listed here are correct at the High Definition Audio Compliant Interface 3MB L3 Cache, 800MHz FSB, TDP:18W time of sending them to the press.
  • Page 15 Removable Polymer Lithium-Ion Battery Pack, 31.08WH (Factory Option) Removable Polymer Lithium-Ion Battery Pack, 62.16WH Energy Star 5.0 Compliant Dimensions & Weight S3100: 330mm (w) x 221mm (d) x 25.5mm (h) 1.55kg (with 31.08WH Battery) S3100M: 330mm (w) x 221mm (d) x 26mm (h) 1.65kg (with 31.08WH Battery)

  • Page 16: External Locator - Top View With Lcd Panel Open

    Introduction External Locator - Top View with LCD Panel Open Figure 1 Top View 1. Built-In PC Ca- mera 2. LCD 3. Power Button 4. Keyboard 5. Built-In Microphone 6. Touchpad & Buttons 7. LED Indicators 1 - 4 External Locator - Top View with LCD Panel Open...

  • Page 17: External Locator - Front & Right Side Views

    Introduction External Locator - Front & Right Side Views Figure 2 Front View 1. LED Indicators FRONT VIEW Figure 3 Right Side View 1. Speaker RIGHT SIDE VIEW 2. 3-in-1 Card Reader 3. HDMI-Out Port 4. RJ-45 LAN Jack 5. USB 2.0 Port External Locator - Front &...

  • Page 18: External Locator - Left Side & Rear View

    Introduction External Locator - Left Side & Rear View Figure 4 Left Side View 1. 2 * USB 2.0 Ports 2. Microphone-In Jack LEFT SIDE VIEW 3. Headphone-Out Jack 4. Speaker Figure 5 REAR VIEW Rear View 1. External Monitor Port 2.

  • Page 19: External Locator - Bottom View

    Introduction External Locator - Bottom View Figure 6 Bottom View 1. Battery 2. Vent 3. Hard Disk Bay Cover 4. Speakers  Overheating To prevent your com- puter from overhea- ting, make sure no- thing blocks any vent while the computer is in use.

  • Page 20: Mainboard Overview - Top (Key Parts)

    Introduction Mainboard Overview - Top (Key Parts) Figure 7 Mainboard Top Key Parts 1. USIM CardMini- Card Connector (3.5G Module) 2. Embedded CPU 3. Platform Controller Hub 4. Memory Slots DDR3 SO-DIMM 5. Mini-Card Connector (WLAN Module) 6. 3-in-1 Card Reader 1 - 8 Mainboard Overview - Top (Key Parts)

  • Page 21: Mainboard Overview - Bottom (Key Parts)

    Introduction Mainboard Overview - Bottom (Key Parts) Figure 8 Mainboard Bottom Key Parts 1. JMC251 2. Clock Generator 3. Azalia Codec 4. KBC-ITE IT8502E Mainboard Overview - Bottom (Key Parts) 1 - 9...

  • Page 22: Mainboard Overview - Top (Connectors)

    Introduction Mainboard Overview - Top (Connectors) Figure 9 Mainboard Top Connectors 1. USB Cable Connector 2. LCD Cable Connector 3. Audio Board Connector 4. Keyboard Cable Connector 5. Speaker Cable Connector 6. LED Cable Connector 7. TouchPad Cable Connector 8. Fan Cable Connector 9.

  • Page 23: Mainboard Overview - Bottom (Connectors)

    Introduction Mainboard Overview - Bottom (Connectors) Figure 10 Mainboard Bottom Connectors 1. USB Port Mainboard Overview - Bottom (Connectors) 1 - 11...
  • Page 24 Introduction 1 - 12...

  • Page 25: Disassembly

    Chapter 2: Disassembly Overview This chapter provides step-by-step instructions for disassembling the S3100/S3100M series notebook’s parts and sub- systems. When it comes to reassembly, reverse the procedures (unless otherwise indicated). We suggest you completely review any procedure before you take the computer apart.

  • Page 26: Maintenance Tools

    Disassembly NOTE: All disassembly procedures assume that the system is turned OFF, and disconnected from any power supply (the battery is removed too). Maintenance Tools The following tools are recommended when working on the notebook PC: • M3 Philips-head screwdriver •...

  • Page 27: Maintenance Precautions

    Disassembly Maintenance Precautions  The following precautions are a reminder. To avoid personal injury or damage to the computer while performing a re- moval and/or replacement job, take the following precautions: Power Safety Warning 1. Don't drop it. Perform your repairs and/or upgrades on a stable surface. If the computer falls, the case and other Before you undertake components could be damaged.

  • Page 28: Disassembly Steps

    Disassembly Disassembly Steps The following table lists the disassembly steps, and on which page to find the related information. PLEASE PERFORM THE DISASSEMBLY STEPS IN THE ORDER INDICATED. To remove the Battery: To remove the CCD 1. Remove the battery page 2 - 5 1.

  • Page 29: Removing The Battery

    Disassembly Removing the Battery 1. Turn the computer off, and turn it over. Figure 1 2. Slide the latch in the direction of the arrow (Figure 1a Battery Removal 3. Slide the latch in the direction of the arrow, and hold it in place (Figure 1a 4.

  • Page 30: Removing The Hard Disk Drive

    Disassembly Removing the Hard Disk Drive The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5mm Figure 2 (h). Follow your operating system’s installation instructions, and install all necessary drivers and utilities (as outlined in HDD Assembly Removal Chapter 4 of the User’s Manual) when setting up a new hard disk.
  • Page 31 Disassembly 3. Remove the hard disk bay cover (Figure 3b Figure 3 4. Grip the tab and slide the hard disk in the direction of arrow (Figure 3c HDD Assembly 5. Lift the hard disk out of the bay (Figure 3d Removal (cont’d.) 6.

  • Page 32: Removing The Keyboard

    Disassembly Removing the Keyboard Figure 4 Keyboard Removal 1. Turn off the computer and remove the battery (page 2 - from the bottom case of the computer 2. Remove screw (Figure a. Remove screw from the 3. Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position bottom case of the compu- (Figure...

  • Page 33: Removing The System Memory (Ram)

    Disassembly Removing the System Memory (RAM) Figure 5 RAM Module The computer has two memory sockets for 204 pin Small Outline Dual In-line Memory Modules (SO-DIMM) supporting Removal DDR3 1066 and 1333MHz. The main memory can be expanded up to 8GB. The SO-DIMM modules supported are 1024MB, and 2048MB and DDRIII Modules.
  • Page 34 Disassembly 4. The RAM modules & will pop-up (Figure 6c), and you can then remove it. Figure 6 RAM Module Removal (cont’d.) c. Remove the modules. 5. Insert a new module holding it at about a 30° angle and fit the connectors firmly into the memory slot. 6.

  • Page 35: Removing The Wireless Lan Module

    Disassembly Removing the Wireless LAN Module Figure 7 Wireless LAN 1. Turn off the computer, remove the battery (page 2 - 5) and keyboard (page 2 - Module Removal 2. The Wireless LAN module will be visible at point (Figure 7a on the mainboard.

  • Page 36: Removing The 3G Module

    Disassembly Removing the 3G Module Figure 8 3G Module Removal 1. Turn off the computer, remove the battery (page 2 - 5) and keyboard (page 2 - 2. The 3G module will be visible at point (Figure 8a on the mainboard. a.

  • Page 37: Ccd Removal

    Disassembly CCD Removal Figure 9 CCD Removal 1. Turn off the computer, turn it over and remove the battery (page 2 - 5), keyboard (page 2 - 8), and wireless LAN (page 2 - 11). a. Remove the screws. 2. Remove screws from the bottom case (Figure 9a).
  • Page 38 Disassembly 5. Loosen the cables at the back of the top case (Figure 10d). Figure 10 CCD Removal 6. Carefully remove the rubber screw covers & and screws & from the front cover (Figure 10e). (cont’d) 7. Remove the hinge covers &...
  • Page 39 Disassembly 10. Carefully lift the LCD front panel forward from the bottom of the frame in the direction of the arrow (Figure Figure 11 11h). CCD Removal 11. Remove the LCD front panel from the LCD assembly (Figure 11i). (cont’d) 12.

  • Page 40: Removing The Bluetooth Module

    Disassembly Removing the Bluetooth Module Figure 12 Bluetooth Module 1. Turn off the computer, remove the battery (page 2 - 5) and remove the bottom case off the top case (page 2 - 13). Removal 2. The Bluetooth module will be visible at point Figure 12a a.The Bluetooth module will 3.

  • Page 41: Removing The Lcd Back Cover (S3100M)

    Disassembly Removing the LCD Back Cover (S3100M) Figure LCD Back 1. Turn off the computer, and turn the computer over to remove the battery (page 2 - Removal (S3 2. Open the LCD and carefully remove the rubber screw covers &...
  • Page 42 Disassembly 2 - 18 Removing the LCD Back Cover (S3100M)
  • Page 43 Disassembly Removing the LCD Back Cover (S3100M) 2 - 19...
  • Page 44 Disassembly 2 - 20 Removing the LCD Back Cover (S3100M)

  • Page 45: Part Lists

    Part Lists Appendix A:Part Lists This appendix breaks down the S3100/S3100M series notebook’s construction into a series of illustrations. The compo- nent part numbers are indicated in the tables opposite the drawings. Note: This section indicates the manufacturer’s part numbers. Your organization may use a different system, so be sure to cross-check any relevant documentation.

  • Page 46: Part List Illustration Location

    Table A - 1 Part List Illustration Part S3100/S3100M Location page A - 3 page A - 4 Bottom page A - 5 LCD (S3100) page A - 6 LCD (S3100M) page A - 7 A - 2 Part List Illustration Location...

  • Page 47: Top

    Part Lists Figure A - 1 藍 天 7 互 億 凱 碩 Top A - 3...

  • Page 48: Bottom

    Part Lists Bottom Figure A - 2 Bottom A - 4 Bottom...

  • Page 49: Lcd (S3100

    Part Lists LCD (S3100) Figure A - 3 LCD (S3100) LCD (S3100) A - 5...

  • Page 50: Lcd (S3100M

    Part Lists LCD (S3100M) Figure A - 4 LCD (S3100M) A - 6 LCD (S3100M)

  • Page 51: Hdd

    Part Lists Figure A - 5 SATA Blu-Ray Combo HDD A - 7...
  • Page 52 Part Lists A - 8...
  • Page 53 Schematic Diagrams Appendix B: Schematic Diagrams This appendix has circuit diagrams of the S3100/S3100M notebook’s PCB’s. The following table indicates where to find the appropriate schematic diagram. Table B - 1 SCHEMATIC DIAGRAMS Diagram - Page Diagram - Page Diagram - Page...

  • Page 54: Schematic Diagrams

    Schematic Diagrams System Block Diagram CLICK BOARD Calpella System Block Diagram VDD3,VDD5 14.318 MHz POWER GPU 1.8VS POWER ON Clock Generator AND USB0 BOARD Memory Termination SLG8SP585 Arrandale 5V,3V,5VS,3VS,1.5VS, 800/1067/1333 MHz DDR3 / 1.5V DDRIII AUDIO JACK BOARD PROCESSOR SO-DIMM0 AJ_MIC1+AJ_HP1 1.5V,0.75VS(VTT_MEM) SYSTEM SMBUS...

  • Page 55: Clock Generator

    Schematic Diagrams Clock Generator CLKGEN POWER CLOCK GENERATOR CLK_VCC 2 3. 3VS RSVD. for ICS9LVS3158 C LK_3.3V_1.5V CLK_VCC 1 U 17 R 226 * 0_04 1.5VS R 227 0_04 *15mil_short_06 C LK_VCC1 VD D_DOT VDD_SRC_I /O C LK_VCC1 VD D_27 VDD_CPU_I /O C340 C 342...

  • Page 56: Cpu 1/7 (Dmi, Peg, Fdi

    Schematic Diagrams CPU 1/7 (DMI, PEG, FDI) PROCESSOR ( DMI,PEG,FDI ) 20 mil PEG_IRCOMP_R R192 49.9_1%_04 PEG_ICOMPI PEG_ICOMPO DMI_TXN0 DMI_RX#[0] PEG_RCOMPO EXP_RBIAS R193 750_1%_04 DMI_TXN1 DMI_RX#[1] PEG_RBIAS DMI_TXN2 DMI_RX#[2] DMI_TXN3 DMI_RX#[3] PEG_RX#[0] PEG_RX#[1] DMI_TXP0 DMI_RX[0] PEG_RX#[2] DMI_TXP1 DMI_RX[1] PEG_RX#[3] DMI_TXP2 DMI_RX[2] PEG_RX#[4] DMI_TXP3...

  • Page 57: Cpu 2/7 (Clk, Misc

    Schematic Diagrams CPU 2/7 (CLK, MISC) PROCESSOR ( CLK,MISC,JTAG ) 1.5V Processor Compensation Signals R218 *1K_04 R137 49.9_1%_04 H_COMP0 R180 0_04 DDR3 Compensation Signals H_COMP1 BSS138 ( VGS 1.5V ) R138 49.9_1%_04 SM_RCOMP_0 R161 100_1%_04 * RJU003N03T106 SM_RCOMP_1 SM_DRAMRST# R163 24.9_1%_04 DDR3_DRAMRST# 10,11 20_1%_04...

  • Page 58: Cpu 3/7 (Ddr3

    Schematic Diagrams CPU 3/7 (DDR3) PROCESSOR ( DDR3 ) U 4D BM34 M_CLK_D DR0 10 SA_CK[0] BP35 BU33 M_A_D Q[63:0] M_CLK_D DR#0 10 M_B_DQ[63:0] M_CLK_DDR2 11 SA_CK#[0] BF20 SB_C K[0] BV34 M_CKE0 10 M_CLK_DDR#2 11 SA_CKE[0] SB_CK#[0] M_A_DQ0 M_B_DQ0 BT26 M_CKE2 11 SA_DQ[0] SB_D Q[0]...

  • Page 59: Cpu 4/7 (Power

    Schematic Diagrams CPU 4/7 (Power) P RO CE S SO R 4/ 7 ( P O WE R ) P RO C E S SO R C OR E P OW E R PR O C E SS O R UN C O R E P O W ER ICCMAX_VTT Max Current for VTT Rail SV 18...
  • Page 60 Schematic Diagrams CPU 5/7 (VGFX Power) PROCESSOR 5/7 ( GRAPHICS POWER ) VGFX_CORE AN32 VAXG1 AN30 AF12 GPUVCCSENSE 35 VAXG2 VAXG_SENSE AN28 AF10 C228 C222 GPUVSSSENSE 35 VAXG3 VSSAXG_SENSE AN26 VAXG4 10U_6.3V_X5R_06 10U_6.3V_X5R_06 AN24 VAXG5 AN23 20100202 D02 AN21 VAXG6 VAXG7 AN19 AF71...
  • Page 61 Schematic Diagrams CPU 6/7 (GND) P R O C E S S O R 6 / 7 G N D U 4I AY 24 U 4J BU 62 VSS90 AY 23 VSS1 VSS91 BU 58 AY 21 AH 53 VSS2 VSS92 VSS202 VSS404...
  • Page 62 Schematic Diagrams CPU 7/7 (RESERVED) PROCESSOR 7/7 ( RESERVED ) VREF_CH_A_DIMM R178 *0_04 MVREF_DQ_DIM0 R176 *0_04 VREF_CH_B_DIMM MVREF_DQ_DIM1 1.5V AP2302GN R215 *1K_1%_04 PCI-Express Configuration Select *AO3402L VREF_CH_A_DIMM MVREF_DQ_DIM0 1 : Single PEG CFG0 RSVD32 0 : Bifurcation enable RSVD33 R179 R216 *100K_04 AC69...

  • Page 63: Ddr3 So-Dimm_0

    Schematic Diagrams DDR3 SO-DIMM_0 SO-DIMM A CHANGE TO STANDARD JDIMM1A M_A_A[15:0] M_A_DQ[63:0] 5 M_A_A0 M_A_DQ0 JDIMM1B M_A_A1 M_A_DQ1 M_A_A2 M_A_DQ2 1.5V M_A_A3 M_A_DQ3 M_A_A4 M_A_DQ4 M_A_A5 M_A_DQ5 VDD1 VSS16 M_A_A6 M_A_DQ6 VDD2 VSS17 M_A_A7 M_A_DQ7 Layout Note: VDD3 VSS18 M_A_A8 M_A_DQ8 VDD4 VSS19...
  • Page 64 Schematic Diagrams DDR3 SO-DIMM_1 SO-DIMM B CHANGE TO STANDARD JDIMM2A M_B_A[15:0] M_B_DQ[63:0] 5 M_B_A0 M_B_DQ0 JDIMM2B M_B_A1 M_B_DQ1 M_B_A2 M_B_DQ2 1.5V M_B_A3 M_B_DQ3 M_B_A4 M_B_DQ4 M_B_A5 M_B_DQ5 VDD1 VSS16 M_B_A6 M_B_DQ6 VDD2 VSS17 M_B_A7 M_B_DQ7 VDD3 VSS18 Layout Note: M_B_A8 M_B_DQ8 VDD4 VSS19...

  • Page 65: Lvds, Inverter

    Schematic Diagrams LVDS, Inverter LCD PANEL CONN 3. 3VS PLVDD C351 *0.1u_16V_04 CLOSE TO LVDS CONN. PANEL POWER 0.1u_16V_Y 5V_04 C 355 C353 4.7U_6.3V_X5R_06 J_LCD 1 2. 2K_04 R237 3.3VS 2. 2K_04 R236 BKLT_CTR L P_D DC_CLK BKLT_CTRL 17 LVD S-LCLKN P_DDC_DATA LVDS-LC LKN 17 LVDS-LCLKP...

  • Page 66: Hdmi, Crt

    Schematic Diagrams HDMI, CRT For ESD HCB1005KF-121T20 HDMI PORT Z1315 BAV99 RECTIFI ER BAV99 RECTIFIER FOR INTEL GRAPHIC 0_06 J_HDMI1 Z1308 BAV99 RECTIFI ER HDMIB_DATA2P HDMIB_D2BP IN_D1+ OU T_D1+ HDMIB_DATA2N 10U_6.3V_X5R_06 22U_6.3V_X5R_08 HDMIB_D2BN IN_D1- OUT_D 1- HDMI B_EXT1_HPD HOT PLU G DETECT HDMIB_DATA1P RN11 2009.06.18...

  • Page 67: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 1/9 IBEXPEAK - M (HDA,JTAG,SATA) RTCVCC 20 mils 2 0mils VDD3 15p_50V_NPO_04 C404 2.2u_16V_X5R_06 RTC_VBAT_1 20K_1%_04 CM200S327681220_32.768KHz BAT54CS3 10M_04 RTC CLEAR R247 JOPEN2 15p_50V_NPO_04 RTC_X1 RTCX1 FWH0 / LAD0 LPC_AD0 24,27 *OPEN_10mil-1MM RTC_X2 LPC_AD1 24,27 10 m ils RTCX2 FWH1 / LAD1...
  • Page 68 Schematic Diagrams IBEXPEAK - M 2/9 IBEXPEAK - M (PCI-E,SMBUS,CLK) 3.3V RN20 2.2K_4P2R_04 SMB_CLK SMB_DATA RN16 2.2K_4P2R_04 BG30 PCH_BT_EN# SML0_DATA PCH_BT_EN# 28 PERN1 SMBALERT# / GPIO11 BJ30 SML0_CLK PERP1 BF29 SMB_CLK SMB_CLK 2 PETN1 SMBCLK BH29 RN18 PETP1 SMB_DATA 10K_8P4R_04 SMB_DATA 2 SMBDATA AW30...

  • Page 69: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 3/9 IBEXPEAK - M (DMI,FDI,GPIO) BA18 FDI_TXN0 3 FDI_RXN0 BC24 BH17 DMI_RXN0 DMI0RXN FDI_RXN1 FDI_TXN1 3 BJ22 BD16 FDI_TXN2 3 DMI_RXN1 DMI1RXN FDI_RXN2 AW20 BJ16 FDI_TXN3 3 DMI_RXN2 DMI2RXN FDI_RXN3 BJ20 BA16 FDI_TXN4 3 DMI_RXN3 DMI3RXN FDI_RXN4 BE14...

  • Page 70: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 4/9 IBEXPEAK - M (LVDS,DDI) BJ46 BLON L_BKLTEN SDVO_TVCLKINN BG46 NB_ENAVDD L_VDD_EN SDVO_TVCLKINP Y 48 BJ48 BKLT_CTRL L_BKLTCTL SDVO_STALLN BG48 SDVO_STALLP AB48 P_DDC_CLK L_DDC_CLK Y 45 BF45 3.3VS P_DDC_DATA L_DDC_DATA SDVO_INTN BH45 SDVO_INTP L_CTRL_CLK AB46 R311 10K_04 L_CTRL_CLK...

  • Page 71: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 5/9 IBEXPEAK - M (PCI,USB,NVRAM) AY 9 NV_CE#0 NV_CE#1 AP15 B o o t B I O S S t r a p NV_CE#2 NV_CE#3 P C I _ G N T # 0 P C I _ G N T # 1 B o o t B I O S L o c a t i o n NV_DQS0 NV_DQS1...

  • Page 72: Ibexpeak

    Schematic Diagrams IBEXPEAK- M 6/9 IBEXPEAK - M (GPIO,VSS_NCTF,RSVD) AH45 EDP_CARD_DET# BMBUSY # / GPIO0 CLKOUT_PCIE6N AH46 0213 S_GPIO CHANGE TO EDP_CARD_DET# CLKOUT_PCIE6P SMI# SMI# TACH1 / GPIO1 EDP_CARD_DET# 1K_1%_04 3.3VS DGPU HDP (NV CONTROL BYSELF) DGPU_HPD_INTR# TACH2 / GPIO6 AF48 CLKOUT_PCIE7N AF47...

  • Page 73: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 7/9 IBEXPEAK - M (POWER) 0828 3.3VS R318 *0_06 1.1VS_VTT VCCA_DAC_3.3VS POWER HCB1608KF-121T25 AB24 AE50 Z2001 VCCCORE[1] VCCADAC[1] AB26 VCCCORE[2] AB28 AE52 C408 C369 C386 C383 C430 C429 C431 C432 R319 C433 VCCCORE[3] VCCADAC[2] AD26 VCCCORE[4] AD28 AF53...

  • Page 74: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 8/9 Voltage Rail Voltage S0 Iccmax Current (A) IBEXPEAK - M (POWER) V_CPU_IO 1.1/1.05 < 1 (mA) V5REF < 1 (mA) V5REF_Sus < 1 (mA) POWER 1.1VS_VCCA_CLK 1.1VS_VTT U 7J Vcc3_3 0.357 * HCB1005KF-121T20 52mA AP51 VccAClk 1.05...

  • Page 75: Ibexpeak

    Schematic Diagrams IBEXPEAK - M 9/9 U 7I IBEXPEAK - M (GND) AY 7 H 49 VSS[ 159] VSS[259] VSS[ 160] VSS[260] VSS[ 161] VSS[261] VSS[ 162] VSS[262] VSS[ 163] VSS[263] VSS[ 164] VSS[264] VSS[ 165] VSS[265] VSS[ 166] VSS[266] VSS[ 167] VSS[267] VSS[ 168]...

  • Page 76: Mini Pcie

    Schematic Diagrams Mini PCIE MINI CARD (WLAN,Port 5) 20 mil 3.3V Layout Show "WLAN(Wimax, 802.11N)" Note C457 0.1u_10V_X7R_04 J_MINI1 WLAN1.5V 1.5V PCIE_WAKE# 16,25 PCIE_WAKE# WAKE# 3.3VAUX_0 20 mil R331 *0_04 R333 *15mil_short_06 BT_EN# COEX1 1.5V_0 UIM_PWR_1 R332 *0_04 27,28,29 BT_EN COEX2 UIM_PWR R330...

  • Page 77: Ccd, 3G, Tpm

    Schematic Diagrams CCD, 3G, TPM MINI CARD 3G(Port 6) 3G POWER R275 *0_06 Layout Show "3.5G(HSDPA)" Note 3G_3.3V 3.3V 3G_3.3V 3A 120mils AO3415 3A 120mils J_3G1 60mils WAKE# 3.3VAUX_0 COEX1 1.5V_0 UIM_PWR COEX2 UIM_PWR UIM_DATA C399 C350 C348 R276 C397 UIM_DATA UIM_CLK C398...

  • Page 78: Card Reader / Lan Jmc251

    Schematic Diagrams Card Reader / LAN JMC251 S5 WAKE ON LAN Switching Regulator close to PIN6 JMC251 DVDD VDD3 SD_CLK R207 22_1%_04 Z2505 (>20mil) REGLX DVDD 3.3V_LAN 3.3V_LAN (>20mil) 3.3V SWF2520CF-4R7M-M C258 C312 C358 3.3V_LAN MDIO Single 10U_6.3V_X5R_06 0.1u_10V_X7R_04 For JMC251/261 Pin#7 Pin#7 *0.1u_10V_X7R_04...

  • Page 79: Lan (Jmc 251), Sata Hdd

    Schematic Diagrams LAN (JMC 251), SATA HDD 20100409 D03 R121 *10mil_short DLMX1+ DLMX1- GIGA LAN (JMC251) *WCM2012F2S-161T03 R120 *10mil_short J_RJ1 R119 *10mil_short DLMX2+ LAN_MDIP0 LMX1+ LAN_MDIP0 TD4+ MX4+ LAN_MDIN0 LMX1- DLMX2- LAN_MDIN0 TD4- MX4- LAN_MDIP1 LMX2+ *WCM2012F2S-161T03 LAN_MDIP1 MX3+ TD3+ LAN_MDIN1 LMX2- R118...

  • Page 80: Kbc-Ite It8502E

    LPCR ST#/WUI4/GPD 2( PU ) KSI7 KBC_WRESET# KB-SO0 4.7K_04 VER. VOLTAGE MODEL_ID WR ST# KSO0/PD0 KB-SO1 KSO1/PD1 KB-SO2 S3100 V1.0 R278 10K/ R279 X 3.3V GA20 GA20/GPB5 KSO2/PD2 KB-SO3 AC _IN # KBR ST#/GPB6( PU ) KSO3/PD3 KB-SO4 R278 X /R279 10K...

  • Page 81: Bt / Power Led / Usb Conn

    21,24,29,30,31,32,34 H 7_0B4_8D 4_7 H7_0B4_8D 4_7 C158D 158N C158D158N C158D 158N C158D 158N H 16 tc236bc169d165-pt O-S3100-D106-P2 MTH 276B217D87 MTH 276B217D87 H 7_0B4_8D4_7 H 7_0B4_8D 4_7 H 14 H 17 H11C AP, CER 470PF 10% 50V X7R EIA(0402) tc 236bc150d146-pt...

  • Page 82: Fan, Click / Charge

    Schematic Diagrams Fan, Click / Charge FAN CONTROL CHARGE CONN 5VS_FAN J_DDB1 J_FAN1 QPOFZ46R2B010K C302 C301 0.1u_10V_X7R_04 5VS_FAN 5VS 10U_6.3V_X5R_06 85204-03001 FON# CHG_EN SMC_BAT CHG_EN SMC_BAT 27 BAT_DET SMD_BAT JFAN BAT_DET SMD_BAT 27 VOUT BAT_VOLT AC_IN# BAT_VOLT AC_IN# 27 CPU_FAN CPU_FANSEN VSET G990P11U...

  • Page 83: Audio Codec Via1812

    Schematic Diagrams Audio Codec VIA1812 CODEC (VIA1812 /ALC272) 3.3VS 1.5V R358 *15mil_short_06 Z3006 *RB551V30 R357 *0_04 C446 C445 5VS_AUD 0.1u_10V_X7R_04 10U_6.3V_X5R_06 PC BEEP HCB1608KF-121T25 3.3VS 3.3VS_AUD BAT54CS3 C465 C436 HCB1608KF-121T25 AUDG 0.1u_10V_X7R_04 10U_6.3V_X5R_06 C462 C463 C467 C468 *0.1u_10V_X5R_04 KBC_BEEP *1U_6.3V_X5R_04 BEEP 0.1u_10V_X7R_04 10U_6.3V_X5R_06...

  • Page 84: 5Vs, 3.3Vs, 1.5Vs / Power Sw

    Schematic Diagrams 5VS, 3.3VS, 1.5VS / Power SW VIN1 POWER SWITCH PC129 0.1u_50V_Y 5V_06 DD_ON "L" TO "H" FROM EC VIN1 VIN1 PC131 PC130 DD_ON_LATCH DD_ON_LATCH 27 0.1u_50V_Y5V_06 0.1u_50V_Y 5V_06 M_BTN# M_BTN# PW R_SW # 27 M_BTN# PWR_SW# PR157 100K_04 PR155 INSTANT-ON 10K_04...

  • Page 85: Power 1.5V / 0.75V / 1.8V

    Schematic Diagrams Power 1.5V / 0.75V / 1.8V PD14 PQ14 QM3002S RB0540S2 VDDQ uP6163 PC100 10U_10V_Y 5V_08 PC99 0.1u_X7R_04 1.5V Z3210 VLDOIN VBST VDDQ PJ15 PR123 Z3202 Z3211 Z3217 BCIHP1040-2R5M VTT_MEM DRVH Z3207 0_06 1.5V OPEN_2A PR108 OPEN_8A PC90 PC89 VTTGND 0_04 PC33...

  • Page 86: Vdd3, Vdd5

    Schematic Diagrams VDD3, VDD5 VREF Z3314 PR37 *0_04 PR39 0_04 PC124 1U_10V_06 Z3312 2 0 1 0 0 1 2 0 D 0 2 F O R O C P 2 0 1 0 0 1 2 0 D 0 2 F O R O C P PR36 PR147 EN_3V...

  • Page 87: Power 1.1Vs_Vtt

    Schematic Diagrams Power 1.1VS_VTT CONTROL 1.1VS_VTT Clarksfield --> 1.1V H_VTTVID1 = LOW, 1.1V Auburndale -->1.05V H_VTTVID1 = HIGH, 1.05V H_V TTV ID1 +1.05V +1.1V 3.3V PR135 3.3V 10K_04 20100413 D03 R353 Z3410 R352 100K_04 PC110 PQ37 PD13 *100K_04 Z3411 MTN7002ZHS3 *1U_6.3V_X5R_04 PR134 15K_1%_04...

  • Page 88: Power Vgfx_Core

    Schematic Diagrams Power VGFX_Core 1.1VS_VTT 40mil PR68 10K_04 Z3504 3.3V DFGT_VID_0 DFGT_VID_1 DFGT_VID_2 DFGT_VID_3 DFGT_VID_4 DFGT_VID_5 DFGT_VID_6 DFGT_VID_0 DFGT_VID_1 DFGT_VID_2 DFGT_VID_3 DFGT_VID_4 PJ13 40mil Z3517 DFGT_VR_EN DFGT_VID_5 PR67 10K_04 3.3VS DFGT_VID_6 3.3VS DFGT_VR_EN PR27 PR28 4.7K_04 10K_1%_04 PR26 1.1VS_VTT 10_06 Sheet 35 of 43 Z3501 Power VGFX_Core...

  • Page 89: V-Core

    Schematic Diagrams V-Core 40mil PR 12 10K_04 Z3604 1.1VS_VTT 3.3V H _VID 0 H_VID0 H _VID 1 H_VID1 H _VID 2 H_VID2 H _VID 3 H_VID3 H _VID 4 H_VID4 H _VID 5 H_VID5 H _VID 6 H_VID6 H _VID0 3.3VS H _VID1 H _VID2...

  • Page 90: (Ac_In, Charge) / Con Board

    Schematic Diagrams (AC_IN, Charge) / Con Board Notice: Z3720 M_VA MPR30 #Charge Current 2.0A * 15m il_short_06 M_VIN #Charge Voltage 12.6V DC JACK H=7.3 MPQ4 P2003EVG #Total Power 60W PN:6-20-B3400-003 20100127 D02 M_VA M_J_DC-JACK1 2DC-G026-B22 MPL1 HCB4532K-800_18 MPQ2A M_BAT 3.6A P2003EVG Z3739 SP8K10SFD5TB...

  • Page 91: Audio / Usb / Board

    Schematic Diagrams Audio / USB / Board USB PORT U_USBVCC U_USBVCC U_USBVCC1 60mils HCB1608KF-121T25 60mils U_5V U_USB_OC#01 FLG# VOUT1 *0_04 VIN1 VOUT2 60mils VIN2 VOUT3 100u_6.3V_B_A 0.1u_10V_X7R_04 10U_6.3V_X5R_06 U_DD_ON# 100K_04 20100409 D03 RT9715BGS U_GND U_GND U_GND U_GND *10mil_short U_J_USB1 6-02-09715-920 U_GND U_GND 20100126 D02...

  • Page 92: Led Board

    Schematic Diagrams LED Board C_3.3VS CJ_LED1 Conn. WLAN CRT5 CRT6 HDD/ODD C_3.3VS C_3.3VS 220_04 220_04 C_VDD3 CJ_LED1 C_SATA_LED# CDT4 CJ_LED1 C_LED_ACIN# CQT1 RY-SP155HYYG4 C_LED_PWR# DTA114EUA C_BT_EN C_WLAN_EN CRT7 Sheet 39 of 43 C_LED_BAT_CHG# C_LED_BAT_FULL# 220_04 LED Board C_SATA_LED# C_WLAN_EN 87152-1207 CQT2 CDT3 PDTC114EU...

  • Page 93: Click Board

    Schematic Diagrams Click Board CLICK BOARD 87151-1207G CCF2 0.1u_10V_X5R_04 CTPBUTTONL CF_5VS_TP C_J_TP1 CTPBUTTONR 85201-04051 CF_GND CJ_TP2 CTP_DATA CF_GND CTP_CLK CTP_CLK CTP_DATA CF_5VS_TP C_J_TPF2 CF_GND Sheet 40 of 43 CCF1 PN:6-20-94A50-104 C_J_TPF1 Click Board 0.1u_10V_X5R_04 20100106 D02 CF_GND LIFT RIGHT C_SWF1 C_SWF2 TJG-532-V-T/R TJG-532-V-T/R...

  • Page 94: Od100

    Schematic Diagrams OD100 O_3.3V SATA ODD CON J_ODD1 TXP_R 0.01U_16V_X7R_04 0.01U_16V_X7R_04 TXN_R RXN_R 0.1U_10V_X7R_04 0.01U_16V_X7R_04 RXP_R 0.01U_16V_X7R_04 Near J_ODD1 O_USB_5V O_1.8V Z0101 2.5A 100mil 1.8V 1A Z0102 10U_6.3V_X5R_06 0.1U_10V_X7R_04 202001-1 * 220u_6.3V_6.3* 6_B *100U_6.3V_B2 10U_6.3V_X5R_06 10U_6.3V_X5R_06 1U_6.3V_X5R_04 0.1U_10V_X7R_04 0.1U_10V_X7R_04 GPIO3 GPIO21 GPIO3 GPIO2...

  • Page 95: Power Swusb0 / Lid

    Schematic Diagrams Power SWUSB0 / LID POWER ON LED LID SWITCH IC ISW1 TJG-533-V-T/R I_M_BTN# I_3.3V *BAV99 RECTIFIER I_3.3V I_GND 100K_04 I_LID_SW# MH-248 I_3.3VS 0.1u_10V_X7R_04 100p_50V_NPO_04 I_GND 20mil I_GND I_GND I_GND Sheet 42 of 43 220_04 220_04 SU1, SU2 Power SWUSB0 / C138B67D67 H5_0B4_5D2_7 I_GND...

  • Page 96: Sequence

    Schematic Diagrams Sequence S3100 POWER SEQUENCE 0114 1 . DD_ON# 2.09 ms 2 . 5V 2.28 ms 3 . 3V 230.62 ms 4 . SUS_PWR_DN_ACK 226 ms 5 . RSMRST# 231 ms 6 . ACPRESENT Sheet 43 of 43 30 ms...

  • Page 97: Updating The Flash Rom Bios

    Download the BIOS computer model. 1. Go to www.clevo.com.tw and point to E-Services and click E-Channel. Note that BIOS versions 2. Use your user ID and password to access the appropriate download area (BIOS), and download the latest BIOS files...

  • Page 98: Use The Flash Tools To Update The Bios

    BIOS Update Use the flash tools to update the BIOS 1. Make sure you are not loading any memory management programs such as HIMEM by holding the F8 key as you see the message “Starting MS-DOS”. You will then be prompted to give “Y” or “N” responses to the programs being loaded by DOS.
