Page 3 Preface Notice The company reserves the right to revise this publication or to change its contents without notice. Information contained herein is for reference only and does not constitute a commitment on the part of the manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inaccuracies that may appear in this publication nor are they in anyway responsible for any loss or damage resulting from the use (or misuse) of this publication.
Page 4 Preface R&TTE Directive This device is in compliance with the essential requirements and other relevant provisions of the R&TTE Direc- tive 1999/5/EC. This device will be sold in the following EEA countries: Austria, Italy, Belgium, Liechtenstein, Denmark, Lux- embourg, Finland, Netherlands, France, Norway, Germany, Portugal, Greece, Spain, Iceland, Sweden, Ireland, United Kingdom, Cyprus, Czech Republic, Estonia, Hungary, Latvia, Lithuania, Malta, Slovakia, Poland, Slov- enia.
Page 5: Fcc Statement
Preface FCC Statement (Federal Communications Commission) You are cautioned that changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Page 6: Fcc Rf Radiation Exposure Statement
Preface FCC RF Radiation Exposure Statement: This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body.
Page 7: Important Safety Instructions
Preface IMPORTANT SAFETY INSTRUCTIONS Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and injury to persons when using any electrical equipment: Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool.
Page 8: Instructions For Care And Operation
Preface Instructions for Care and Operation The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions: Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged. Do not expose the computer Do not place it on an unstable Do not place anything heavy...
Page 9 Preface Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong magnetic fields. These can hinder proper performance and damage your data. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget to save your work.
Page 10: Power Safety
Preface Power Safety The computer has specific power requirements:  • Only use a power adapter approved for use with this computer. • Your AC/DC adapter may be designed for international travel but it still requires a steady, Power Safety uninterrupted power supply.
Page 11: Polymer Battery Precautions
Preface Polymer Battery Precautions Note the following information which is specific to polymer batteries only, and where applicable, this overrides the general battery precaution information overleaf. • Polymer batteries may experience a slight expansion or swelling, however this is part of the battery’s safety mecha- nism and is not a cause for concern.
Page 12: Battery Precautions
Preface Battery Precautions • Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer. • Do not remove any batteries from the computer while it is powered on. • Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way. Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may possibly result in fire.
Page 13: Cleaning
Preface Cleaning Do not apply cleaner directly to the computer; use a soft clean cloth. Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer. Servicing Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and the computer to electric shock.
Page 14: Travel Considerations
Preface Travel Considerations Packing As you get ready for your trip, run through this list to make sure the system is ready to go: Check that the battery pack and any spares are fully charged. Power off the computer and peripherals. Close the display panel and make sure it’s latched.
Page 15 Preface On the Road In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Troubleshooting, keep these points in mind: Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is very common.
Page 16 Preface Developing Good Work Habits Developing good work habits is important if you need to work in front of the computer for long periods of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your hands, wrists or other joints.
Page 17: Lcd Screen Care
Preface Lighting Proper lighting and comfortable display viewing angle can reduce eye strain and muscle fatigue in your neck and shoulders. • Position the display to avoid glare or reflections from overhead lighting or outside sources of light. • Keep the display screen clean and set the brightness and contrast to levels that allow you to see the screen clearly. •...
Page 18 Preface...
Page 19: Table Of Contents
Preface Contents Notice .................I Function Keys & Visual Indicators .......1-9 FCC Statement ..............III System Map: Front & Rear Views .......1-10 FCC RF Radiation Exposure Statement: ......IV System Map: Left & Right Views .......1-11 Instructions for Care and Operation ....... VI System Map: Bottom View ..........1-12 Power Safety ..............
Page 20 Preface USB Printer ..............2-13 Drivers & Utilities Parallel Printer .............2-13 What to Install ..............4-1 Module Driver Installation ..........4-1 Power Management Driver Installation ............4-2 Overview ................3-1 Updating/Reinstalling Individual Drivers ......4-4 The Power Sources ............3-2 User Account Control ............4-4 AC/DC Adapter .............3-2 Windows Security Message ...........4-4 Battery ................3-2 New Hardware Found ............4-5...
Page 21 Preface BIOS Utilities Boot Menu ..............5-12 Exit Menu ..............5-13 Overview ................5-1 The Power-On Self Test (POST) ........5-2 Upgrading The Computer Failing the POST ............5-3 Overview ................6-1 Fatal Errors ..............5-3 When Not to Upgrade ............6-2 Non-Fatal Errors ............5-3 Removing the Battery ............6-3 The Setup Utility ............5-4 Upgrading the Hard Disk Drive ........6-4 Entering Setup ...............5-4...
Page 22 Preface Text Messaging Service ..........7-24 Interface (Ports & Jacks) BandLuxe HSDPA Utility ...........7-25 Overview ...............A-1 BandLuxe HSDPA Utility Installation ......7-25 BandLuxe HSDPA - Connection Manager ....7-26 Intel Video Driver Controls Creating a Profile ............7-29 Intel Video Driver Installation ........B-1 Choosing a Profile ............7-32 Dynamic Video Memory Technology ......B-1 Editing a Profile ............7-33...
Page 23 Preface Slots ................C-3 Communication ............. C-3 Power Management ............C-3 Power ................C-3 Security ................. C-3 Operating System ............C-3 Environmental Spec ............C-4 Dimensions & Weight ..........C-4...
Page 24 Preface XXII...
Page 25: Quick Start Guide
Quick Start Guide Chapter 1: Quick Start Guide Overview This Quick Start Guide is a brief introduction to the basic features of your computer, to navigating around the computer and to getting your system started. The remainder of the manual covers the following: •...
Page 26: Advanced Users
Quick Start Guide Advanced Users If you are an advanced user you may skip over most of this Quick Start Guide. However you may find it useful to refer to “What to Install” on page 4 - “BIOS Utilities” on page 5 - 1 “Upgrading The Computer”...
Page 27: Not Included
Quick Start Guide Not Included Operating Systems (e.g. Windows 7) and applications (e.g. word processing, spreadsheet and database programs) have their own manuals, so please consult the appropriate manuals.  Drivers If you are installing new system software, or are re-configuring your computer for a different system, you will need to install the drivers listed in “Drivers &...
Page 28: System Software
Quick Start Guide System Software Your computer may already come with system software pre-installed. Where this is not the case, or where you are re-configuring your computer for a different system, you will find that this manual refers to the Windows 7 operating system.
Page 29: System Startup
Quick Start Guide System Startup Remove all packing materials, and place the computer on a stable surface. Securely attach any peripherals you want to use with the notebook (e.g. keyboard and mouse) to their ports. Attach the AC/DC adapter to the DC-In jack at the rear of the computer, then plug the AC power cord into an outlet, and connect the AC power cord to the AC/DC adapter.
Page 30: System Map: Lcd Panel Open
Quick Start Guide System Map: LCD Panel Open Figure 1 - 2 LCD Panel Open  Built-In PC Camera (Optional) Wireless Device Operation Aboard Power Button Aircraft Keyboard The use of any portable Built-In Microphone electronic transmission de- Touchpad & vices aboard aircraft is usu- Buttons ally prohibited.
Page 31: Led Indicators
Quick Start Guide LED Indicators The LED indicators display helpful information about the current status of the computer. Icon Color Description Orange DC Power is Plugged In Green The Computer is On (Power Status) Blinking Green The Computer is in Sleep Mode Orange The Battery is Charging Green...
Page 32: Keyboard
Quick Start Guide Keyboard  The keyboard has a numerical keypad for easy numeric data input, and features func- Other Keyboards tion keys to allow you to change operational features instantly. See Table 1 - 2, on page 1 - 9 for full function key combination details.
Page 33: Function Keys & Visual Indicators
Quick Start Guide Function Keys & Visual Indicators The function keys (F1 - F12 etc.) will act as hot keys when pressed while the Fn key is held down. Make sure the hot key driver is installed (see “Hot Key” on page 4 - Keys Function/Visual Indicators Keys...
Page 34: System Map: Front & Rear Views
Quick Start Guide System Map: Front & Rear Views Figure 1 - 4 Front & Rear Views LED Indicators External Monitor Port Vent/Fan Intake/ Outlet Security Lock Slot DC-In Jack  Overheating To prevent your computer from overheating make sure nothing blocks the vent(s)/fan in- take(s) while the computer is in use.
Page 35: System Map: Left & Right Views
Quick Start Guide System Map: Left & Right Views Figure 1 - 5 Left & Right Views USB 2.0 Ports Microphone-In Jack Headphone-Out Jack Speakers 3-in-1 Card Reader HDMI-Out Port RJ-45 LAN Jack  3-in-1 Card Reader  The card reader allows you to use the most popular digital storage card formats: MMC (MultiMedia Card) / RS MMC Optical Device SD (Secure Digital) / Mini SD / SDHC / SDXC Compatible...
Page 36: System Map: Bottom View
Quick Start Guide System Map: Bottom View Figure 1 - 6 Bottom View Battery Hard Disk Bay Cover Vent/Fan Intake/ Outlet Speakers  The CPU is not a user ser- viceable part. Opening this  compartment, or accessing the CPU in any way, may vi- Battery Information olate your warranty.
Page 37: 3.75G/Hspa Module Usim Card Installation
Quick Start Guide 3.75G/HSPA Module USIM Card Installation If you have included an optional 3.75G/HSPA module in your purchase option, follow the instructions below to install the USIM card (which will be provided by your service provider), and then run the appropriate applica- tion.
Page 38: Windows 7 Start Menu & Control Panel
Quick Start Guide Windows 7 Start Menu & Control Panel Most of the control panels, utilities and programs within Windows 7 (and most other Windows versions) are ac- cessed from the Start menu. When you install programs and utilities they will be installed on your hard disk drive, and a shortcut will usually be placed in the Start menu and/or the desktop.
Page 39: Video Features
Quick Start Guide Video Features You can configure display options from the Display (Control Panel) and Screen Resolution in Windows. For more detailed video information see Appendix To access Display (Control Panel) and Screen Resolution in Windows: Click Start and click Control Panel. Click Display (icon) - In the Appearance and Personalization category.
Page 40 Quick Start Guide To access the Intel(R) Graphics Media Accelerator Driver for mobile control panel: Click Advanced settings (Figure 1 - 9 on page 1 - 15) in the Screen Resolution control panel in Win- dows. Click the Intel(R)... tab and click Graphics Properties (button) (Figure 1 - 10 on page 1 - 16) .
Page 41: Power Options
Quick Start Guide Power Options The Power Options (Hardware and Sound menu) control panel icon in Windows (see page 14) allows you to configure power management features for your computer. You can conserve power by means of power plans and configure the options for the power button, sleep button, computer lid (when closed), display and sleep mode from the left menu.
Page 42: Mofa Lcd Back Covers
Quick Start Guide MOFA LCD Back Covers MOFA (Magic of Film Art) technology allows fashionable and unique pictorial designs to be printed on the spe- cially designed changeable LCD back covers. If your purchase option includes the specially designed change- able LCD back cover option, then follow the instructions in “Changing the Optional LCD Back Covers”...
Page 43: Features & Components
Features & Components Chapter 2: Features & Components Overview Read this chapter to learn more about the following main features and components of the computer: • Hard Disk Drive • External USB Optical (CD/DVD) Device • 3-in-1 Card Reader • Touchpad and Buttons/Mouse •...
Page 44: Hard Disk Drive
Features & Components Hard Disk Drive  The hard disk drive is used to store your data in the computer. The hard disk can be Power Safety taken out to accommodate other 2.5" serial (SATA) hard disk drives with a height of 9.5 mm.
Page 45: External Usb Optical (Cd/Dvd) Device
Features & Components External USB Optical (CD/DVD) Device  An external USB optical (CD/DVD) device is available as an option for this com- USB Cables puter. The optical device may be used as a boot device if properly set in the BIOS (see “Boot Menu”...
Page 46: Handling Cds Or Dvds
Features & Components Handling CDs or DVDs  Proper handling of your CDs/DVDs will prevent them from being damaged. Please follow the advice below to make sure that the data stored on your CDs/DVDs can be CD Emergency Eject accessed. If you need to manually eject a CD (e.g.
Page 47: Dvd Regional Codes
Features & Components DVD Regional Codes Go to the Control Panel and double-click Device Manager (Hardware and Sound), then click the + next to DVD/CD-ROM drives. Double-click on the DVD- ROM device to bring up the Properties dialog box, and select the DVD Region (tab) to bring up the control panel to allow you to adjust the regional code.
Page 48: 3-In-1 Card Reader
Features & Components 3-in-1 Card Reader  The card reader allows you to use some of the latest digital storage cards. Push the Card Reader Cover card into the slot and it will appear as a removable device, and can be accessed in the same way as your hard disk (s).
Page 49: Touchpad And Buttons/Mouse
Features & Components Touchpad and Buttons/Mouse  The Touchpad is an alternative to the mouse; however, you can also add a mouse to Touchpad Scrolling your computer through one of the USB ports. The Touchpad buttons function in much the same way as a two-button mouse. This computer model se- ries may feature different Touchpad versions.
Page 50: Gestures And Device Settings
Features & Components Gestures and Device Settings  The Synaptics Gestures Suite application allows you to use a specific gesture (ac- Show Video tion) on the surface of the Touchpad to perform specific actions to manipulate doc- uments, objects and applications. You can get a clearer view of the gestures in- volved by clicking the...
Page 51 Features & Components Scrolling The Two-Finger scrolling feature works in most scrollable windows and allows you to scroll horizontally and vertically. Place two fingers, slightly separated, on the Touchpad surface and slide both fingers in the direction required (in a straight con- Figure 2 - 5 tinuous motion).
Page 52 Features & Components Rotating Use the Pivot Rotate gesture to rotate objects (e.g. photos) in 90 degree increments. Place a finger down on the left “target” zone and keep it stationary. Place another finger near the middle of the Touchpad and slide it in a circular motion around the stationary finger (clockwise or counterclockwise) to rotate the object.
Page 53: Audio Features
Features & Components Audio Features  You can configure the audio options on your computer from the Sound control Sound Volume panel in Windows, or from the Realtek HD Audio Manager icon in the taskbar/ Adjustment control panel (right-click the taskbar icon to bring up an audio menu).
Page 54: Optimizing Audio Recording
Features & Components Optimizing Audio Recording Follow these instructions to optimize your audio recording. Double-click the taskbar icon to bring up the Realtek HD Audio Manager. Click the Microphone tab. Click the Noise Suppression button to prevent any background noise or feedback.
Page 55: Adding A Printer
Features & Components Adding a Printer  The most commonly used peripheral is a printer. The following conventions will Parallel Printer help you to add a printer; however it is always best to refer to the printer manual for specific instructions and configuration options. After setting up the print- er attach the parallel ca- USB Printer...
Page 56 Features & Components 2 - 14...
Page 57: Power Management
Power Management Chapter 3: Power Management  Overview OS Note Power management To conserve power, especially when using the battery, your computer power man- functions will vary slight- agement conserves power by controlling individual components of the computer ly depending on your (the monitor and hard disk drive) or the whole system.
Page 58: The Power Sources
Power Management The Power Sources The computer can be powered by either an AC/DC adapter or a battery pack. AC/DC Adapter Use only the AC/DC adapter that comes with your computer. The wrong type of AC/ DC adapter will damage the computer and its components. Attach the AC/DC adapter to the DC-in jack at the rear of the computer.
Page 59: Turning On The Computer
Power Management Turning On the Computer  Now you are ready to begin using your computer. To turn it on simply press the pow- Forced Off er button on the front panel. If the system “hangs”, When the computer is on, you can use the power button as a Stand by/Hibernate/ and the Ctrl + Alt + Del Shutdown hot-key button when it is pressed for less than 4 seconds (pressing and key combination doesn’t...
Page 60: Power Plans
Power Management Power Plans  The computer can be configured to conserve power by means of power plans. You Resuming can use (or modify) an existing power plan, or create a new one. Operation The settings may be adjusted to set the display to turn off after a specified time, and Table 3 - 1, on to send the computer into Sleep after a period of inactivity.
Page 61 Power Management Each Windows power plan will also adjust the processor performance of your ma- chine in order to save power. This is worth bearing in mind if you are experiencing any reduced performance (especially under DC/battery power). Choose High performance (you may need to click Show additional plans to view the High performance plan) for maximum performance when the computer is pow- ered from an AC power source.
Page 62: Power-Saving States
Power Management Power-Saving States You can use power-saving states to stop the computer’s operation and restart where you left off. Win 7 uses the Sleep, Hibernate and Shut Down power-saving states. Sleep In Sleep all of your work, settings and preferences are saved to memory before the system sleeps.
Page 63: Hibernate
Power Management Hibernate Hibernate uses the least amount of power of all the power-saving states and saves all of your information on a part of the hard disk before it turns the system off. If a power failure occurs the system can restore your work from the hard disk; if a power failure occurs when work is saved only to memory, then the work will be lost.
Page 64: Configuring The Power Buttons
Power Management Configuring the Power Buttons  The power/sleep button (Fn + F4 key combo) and closed lid may be set to send the Password computer in to a power-saving state. Click Choose what the power buttons do on Protection the left menu in Power Options to bring up the menu.
Page 65: Resuming Operation
Power Management Resuming Operation  You can resume operation from power-saving states by pressing the power button, or in some cases pressing the sleep button (Fn + F4 key combo). Closing the Lid If you have chosen to Power Status To Resume Icon Color...
Page 66: Energy Star Power Saving
Power Management Energy Star Power Saving  This system supports Energy Star power management features that place comput- ers (CPU, hard drive, etc.) into a low-power sleep modes after a designated period Taskbar Icon of inactivity. If you want to enable Energy Star power saving then follow these in- If the taskbar icon does structions: not appear then click the...
Page 67: Battery Information
Power Management Battery Information  Follow these simple guidelines to get the best use out of your battery. Low Battery Battery Power Warning Your computer’s battery power is dependent upon many factors, including the pro- When the battery is criti- grams you are running, and peripheral devices attached.
Page 68: Conserving Battery Power
Power Management Conserving Battery Power  • Use a power plan that conserves power (e.g Power saver), however note that this may have an affect on computer performance. Wireless Hot Keys • Lower the brightness level of the LCD display. The system will decrease LCD The computer’s wireless brightness slightly to save power when it is not powered by the AC/DC adapter.
Page 69: Battery Life
Power Management Battery Life Battery life may be shortened through improper maintenance. To optimize the life and improve its performance, fully discharge and recharge the battery at least once every 30 days. We recommend that you do not remove the battery yourself. If you do need to re- move the battery for any reason (e.g.
Page 70: Proper Handling Of The Battery Pack
Power Management Proper handling of the Battery Pack  • DO NOT disassemble the battery pack under any circumstances • DO NOT expose the battery to fire or high temperatures, it may explode Caution • DO NOT connect the metal terminals (+, -) to each other Danger of explosion if battery is incorrectly re- placed.
Page 71: Battery Faq
Power Management Battery FAQ How do I completely discharge the battery? Use the computer with battery power until it shuts down due to a low battery. Don’t turn off the computer even if a message indicates the battery is critically low, just let the computer use up all of the battery power and shut down on its own.
Page 72 Power Management Click Change plan settings (after creating it) and click Change plan settings > Change advanced power settings. Figure 3 - 9 Change Plan Settings / Change Advanced Power Settings 3 - 16 Battery Information...
Page 73 Power Management Scroll down to Battery and click + to expand the battery options. Choose the options below (click Yes if a warning appears): Figure 3 - 10 Power Options Advanced Settings - Battery • Low battery levels = 0% •...
Page 74 Power Management How do I fully charge the battery? When charging the battery, don’t stop until the LED charging indicator light changes from orange to green. How do I maintain the battery? Completely discharge and charge the battery at least once every 30 days or after about 20 partial discharges.
Page 75: Drivers & Utilities
Drivers & Utilities Chapter 4: Drivers & Utilities What to Install This chapter deals with installing the drivers and utili- ties essential to the operation or improvement of some You will need to attach a DVD drive to the computer of the computer’s subsystems.
Page 76: Driver Installation
Drivers & Utilities Driver Installation Check the driver installation order from Table 4 - 1, on page 4 - 3 (the drivers must be installed in Insert the Device Drivers & Utilities + User’s Manual this order) which is the same as that listed in the disc into an attached DVD drive and click Install Driv- Drivers Installer menu below.
Page 77 Drivers & Utilities Manual Driver Installation Click Browse CD/DVD (button) in the Drivers Install- Driver - Windows 7 Page # er application and browse to the executable file in the Chipset Page 4 - 5 appropriate driver folder. Video Page 4 - 5 Windows Update Page 4 - 5 After installing all the drivers make sure you enable...
Page 78: Updating/Reinstalling Individual Drivers
Drivers & Utilities Updating/Reinstalling Individual Drivers User Account Control If you wish to update/reinstall individual drivers it If a User Account Control prompt appears as part of may be necessary to uninstall the original driver.To do the driver installation procedure, click Continue or this go to the Control Panel in the Windows OS and Allow, and follow the installation procedure as direct- double-click the Programs and Features icon (Pro-...
Page 79: New Hardware Found
Drivers & Utilities New Hardware Found Driver Installation Procedure If you see the message “New Hardware Found” dur- Insert the Device Drivers & Utilities + User’s Manual ing the installation procedure (other than when out- disc into your attached CD/DVD drive and click In- lined in the driver install procedure), click Cancel stall Drivers (button).
Page 80: Cardreader
Drivers & Utilities CardReader Intel MEI Driver 1. Click 4.Install CardReader Driver > Yes. 1. Click 7.Install MEI Driver > Yes. 2. Click Install > Finish. 2. Click Next > Yes > Next > Next. 3. Click Finish to restart the computer. Touchpad Audio 1.
Page 81: Windows Experience Index
Drivers & Utilities Windows Experience Index  After the drivers are installed follow this procedure to ensure an accurate rating from the Windows Experi- Windows 7 Update ence Index: After installing all the drivers make sure you enable Win- dows Update in order to get all the latest security up- 1.
Page 82: Optional Drivers
Drivers & Utilities Optional Drivers Wireless LAN Module See the pages indicated for the driver installation pro- See the introduction in “Wireless LAN Module” on cedures for any modules included in your purchase op- page 7 - 2, and check the installation procedure. tion.
Page 83: Overview
BIOS Utilities Chapter 5: BIOS Utilities  Overview BIOS Screens Note that BIOS This chapter gives a brief introduction to the computer’s built-in software: screens pictured these pages are intend- Diagnostics: The POST (Power-On Self Test) ed for guidance in set- ting up your system’s BIOS.
Page 84: The Power-On Self Test (Post)
BIOS Utilities The Power-On Self Test (POST)  Each time you turn on the computer, the system takes a few seconds to conduct a POST Screen POST, including a quick test of the on-board RAM (memory). 1.BIOS information As the POST proceeds, the computer will tell you if there is anything wrong. If there 2.CPU type is a problem that prevents the system from booting, it will display a system summary 3.Memory status...
Page 85: Failing The Post
BIOS Utilities Failing the POST Errors can be detected during the POST. There are two categories, “fatal” and “non- fatal”. Fatal Errors These stop the boot process and usually indicate there is something seriously wrong with your system. Take the computer to your service representative or authorized service center as soon as possible.
Page 86: The Setup Utility
BIOS Utilities The Setup Utility  The Phoenix Setup Utility tells the system how to configure itself and manage basic BIOS Settings features and subsystems (e.g. port configuration). Warning Entering Setup Incorrect settings can cause your system to To enter Setup, turn on the computer and press F2 during the POST. The prompt malfunction.
Page 87: Setup Screens
BIOS Utilities Setup Screens  The following pages contain additional advice on portions of the Setup. Setup Menus Along the top of the screen is a menu bar with menu headings. When you select a Setup menus heading, a new screen appears. Scroll through the features listed on each screen to shown in this section are make changes to Setup.
Page 88: Main Menu
BIOS Utilities Main Menu Figure 5 - 2 Main Menu System Time & Date (Main Menu) The hour setting uses the 24-hour system (i.e., ØØ = midnight; 13 = 1 pm). If you can change the date and time settings in your operating system, you will also change these settings.
Page 89: Sata Aggress Link Power (Advanced Menu)
BIOS Utilities SATA Aggress Link Power (Advanced Menu) This item is only available if AHCI is set as the SATA Mode. Aggressive Link Pow- er Management (ALPM) allows the SATA AHCI controller to put the link to the disk into a very low power mode when the IO is not being used. The controller au- tomatically puts the link back into an active power mode when required.
Page 90: Advanced Menu
BIOS Utilities Advanced Menu Figure 5 - 3 Advanced Menu Legacy USB Support (Advanced Menu) Choose “Enabled” if you intend to use USB devices in systems which do not nor- mally support USB functionality (e.g. DOS). The default setting is “Enabled” and does not need to be changed if you intend to use your USB devices in Windows.
Page 91: Boot-Time Diagnostic Screen (Advanced Menu)
BIOS Utilities Boot-time Diagnostic Screen (Advanced Menu) Use this menu item to enable/disable the Boot-time Diagnostic Screen or POST screen (see “The Power-On Self Test (POST)” on page 5 - Legacy OS Boot (Advanced Menu) If “Enabled” the system will attempt to load the Legacy OS (e.g. Vista/Windows XP) first.
Page 92: Security Menu
BIOS Utilities Security Menu  Security Menu changes make here affect the access to the Setup utility itself, and also access to your ma- chine as it boots up af- ter you turn it on. These settings do not affect your machine or network passwords which will be set in...
Page 93: Set User Password (Security Menu)
BIOS Utilities Set User Password (Security Menu)  You can set a password for user mode access to the Phoenix SecureCore Setup Utility. This will not affect access to the computer OS, (only the Setup utility) unless Password Warning you choose to set a Password on Boot (see below). Many menu items in the Phoenix If you set a boot pass- SecureCore Setup Utility cannot be modified in user mode.
Page 94: Boot Menu
BIOS Utilities Boot Menu  BIOS Screens Note that BIOS screens pictured these pages are intend- ed for guidance in set- ting up your system’s BIOS. BIOS versions are sub- ject to constant change and revision, therefore your computer’s actual screens appear slightly different from...
Page 95: Exit Menu
BIOS Utilities Exit Menu Figure 5 - 6 Exit Menu Choosing to Discard Changes, or Exit Discarding Changes, will wipe out any changes you have made to the Setup. You can also choose to restore the original Set- up defaults that will return the Setup to its original state, and erase any previous changes you have made in a previous session.
Page 96 BIOS Utilities 5 - 14...
Page 97: Overview
Upgrading The Computer Chapter 6: Upgrading The Computer Overview  This chapter contains information on upgrading the computer. Follow the steps out- Warranty Warning lined to make the desired upgrades. If you have any trouble or problems you can con- tact your service representative for further help.
Page 98: When Not To Upgrade
Upgrading The Computer When Not to Upgrade  These procedures involve opening the system’s case, adding and sometimes replac- ing parts. Power Safety Warning You should not perform any of these upgrades if: Before you undertake upgrade proce- • Your system is still under warranty or a service contract dures, make sure that •...
Page 99: Removing The Battery
Upgrading The Computer Removing the Battery  If you are confident in undertaking upgrade procedures yourself, for safety reasons Warranty Warning it is best to remove the battery. Turn off the computer, and turn it over. Please check with your Slide the latch in the direction of the arrow (or latches &...
Page 100: Upgrading The Hard Disk Drive
Upgrading The Computer Upgrading the Hard Disk Drive  The hard disk drive can be taken out to accommodate other 2.5" serial (SATA) hard HDD System disk drives with a height of 9.5mm (h) (see “Storage” on page C - 2).
Page 101 Upgrading The Computer Grip the tab and slide the hard disk in the direction of the arrow Lift the hard disk up in the direction of arrow  Remove screws and then remove the cover tab. Reverse the process to install a new hard disk drive. Hard Disk Screws &...
Page 102: Upgrading The System Memory (Ram)
Upgrading The Computer Upgrading the System Memory (RAM) The computer has two memory sockets for 204 pin Small Outline Dual In-line (SO- DIMM) DDRIII (DDR3) type memory modules (see “Memory” on page C - 2 details of supported module types). The total memory size is automatically detected by the POST routine once you turn on your computer.
Page 103 Upgrading The Computer Press the four keyboard latches at the top of the keyboard to elevate the keyboard from its normal position (you may need to use a small screwdriver to do this). Figure 6 - 5 Keyboard Latches Carefully lift the keyboard up, being careful not to bend the keyboard cable Figure 6 - 6 Keyboard Release Upgrading the System Memory (RAM) 6 - 7...
Page 104 Upgrading The Computer Carefully move aside the WLAN module cable from the right RAM slot, and gently pull the two release latches on the sides of the memory socket to release the memory module(s). Figure 6 - 7 WLAN Cable ...
Page 105 Upgrading The Computer The RAM module will pop-up, and you can remove it. Figure 6 - 9 RAM Module Removal 7 10  Contact Warning Be careful not to touch the metal pins on the module’s connecting Pull the latches to release the second module if necessary. edge.
Page 106: Changing The Optional Lcd Back Covers
Upgrading The Computer Changing the Optional LCD Back Covers  If your purchase option includes the specially designed LCD back cover option, then Rubber Screw follow the instructions below to change the covers (note these covers are not appli- Covers cable to all models in this series - consult your service center for details).
Page 107 Upgrading The Computer Carefully slide the cover forward in the direction of the arrows & illustrated below Figure 6 - 11 Slide the Cover Forward Remove the LCD back cover Figure 6 - 12 Remove the LCD Back Cover Changing the Optional LCD Back Covers 6 - 11...
Page 108 Upgrading The Computer Align the replacement cover with the dotted line as illustrated below (and as marked on the cover). Figure 6 - 13 Replacing the LCD Back Cover Slide the cover forward until it clicks firmly into place Run your hands around the sides and front of the cover to make sure it is firmly aligned in place (carefully press down to make sure the fit is secure).
Page 109: Overview
Modules & Options Chapter 7: Modules & Options  Overview Driver Installation & Module Power This chapter contains information on the following modules, which may come with your computer, depending on the configuration purchased. If you are unsure please Make sure any modules (e.g.
Page 110: Wireless Lan Module
Modules & Options Wireless LAN Module  If you have included an Intel® Wi-Fi Link 1000 Series (802.11 b/g/n) or 3rd Party Wireless Device 802.11b/g/n WLAN module in your purchase option, make sure that the Wireless Operation Aboard LAN module is on before installing the driver. Aircraft Use the Fn + F11 key combination (see “Function Keys &...
Page 111: Intel® Wi-Fi Link Series Driver Installation
Modules & Options Intel® Wi-Fi Link Series Driver Installation  If you see the message “Found New Hardware” click Cancel to close the window. 1. Make sure the module is powered on, then insert the Device Drivers & Util- Intel(R) PROSet/ ities + User’s Manual disc into the CD/DVD drive.
Page 112: Connecting To A Wireless Network
Modules & Options Connecting to a Wireless Network  Make sure the Wireless LAN module is turned on. Network and Click the taskbar wireless icon , and then double-click an access point to con- Sharing Center nect to or click to Open Network and Sharing Center if you do not see a network you want to connect to in the taskbar menu (a list of options will appear allowing You can also use the Net- setting changes, and creating a new network).
Page 113 Modules & Options You may need to enter a security key for any access point to which you are trying to connect. Click to select a network location (e.g. Home, Work or Public). Click “View or change settings in Network and Sharing Center” to access further options for the connection.
Page 114 Modules & Options Click the taskbar icon to see any currently connected networks.  To disconnect from the wireless network you can click the taskbar wireless icon , click the active connection and then click Disconnect (button). Security Enabled Networks You should try to make sure that any network you are connecting to is a se-...
Page 115: Windows Mobility Center
Modules & Options Windows Mobility Center  The Windows Mobility Center control panel provides an easy point of access for information on battery status, power plans used and wireless device status etc. Wireless Hot Keys To access the Windows Mobility Center: The computer’s wireless function keys will not func- Click Start, and click Control Panel (or point to Settings and click Control...
Page 116: Pc Camera Module
Modules & Options PC Camera Module  The PC Camera application captures video files and takes pictures. Before installing Latest PC Camera the driver, make sure that the optional PC Camera is on. Use the Fn + F10 key com- Driver Information bination (see “Function/Hot Key Indicators”...
Page 117: Pc Camera Driver Installation
Modules & Options PC Camera Driver Installation  1. Make sure the module is powered on, and then insert the Device Drivers & Utilities + User’s Manual disc into the CD/DVD drive. PC Camera Screen 2. Click Option Drivers (button). Refresh 3.
Page 118 Modules & Options PC Camera Audio Setup If you wish to capture video & audio with your camera, it is necessary to setup the audio recording options in Windows. Click Start, and click Control Panel (or point to Settings and click Control Panel). Click Sound (Hardware and Sound).
Page 119 Modules & Options Camera Application  The camera application is a video viewer for general purpose video viewing and test- ing, and for capturing video files to .avi format. Pre-Allocating File Size/Space Run the camera application from the desktop shortcut (it is recommended that you set the capture file before the capture process - see “Set Capture File”...
Page 120 Modules & Options Reducing Video File Size Note that capturing high resolution video files requires a substantial amount of disk space for each file. After recording video, check the video file size (right-click the file and select Properties) and the remaining free space on your hard disk (go to My Computer, right-click the hard disk, and select Properties).
Page 121 Modules & Options Eliminating Screen Flicker  If you find that the video screen in the camera program is flickering, you can try to adjust the setting in the Video Capture Filter options. Latest PC Camera Driver Information Run the camera application from the desktop shortcut. Go to Options and scroll down to select Video Capture Filter..
Page 122 Modules & Options Zoom The WebCam program allows you to zoom the camera in and out (note the zoom function is not available in all camera model applications). Run the camera application from the desktop shortcut. Go to Zoom and select Zoom Out/Zoom In. Figure 7 - 6 Zoom/Setting ...
Page 123: G/Hspa Module
Modules & Options 3.75G/HSPA Module  If you have included an optional 3.75G/HSPA (High Speed Packet Access) module (see “Communication” on page C - 3 for specification details) in your purchase op- 3.75G/HSPA Module Options tion, you will have the appropriate software provided for your module. Follow the instructions overleaf to install the USIM card (supplied by your service provider), There are two optional and then install the appropriate application.
Page 124 Modules & Options USIM Card Installation  Turn off the computer, and turn it over. Slide the latch in the direction of the arrow (or latches & in the direction Power Safety of the arrow if you are using for 62.16WH battery). Warning Slide the latch in the direction of the arrow, and hold it in place.
Page 125 Modules & Options Insert the USIM card as illustrated below until it clicks fully into position. Figure 7 - 8 SIM Card Insertion  USIM Card Orientation Note that the USIM card’s readable side (with the gold-colored contacts) should face upwards as il- lustrated.
Page 126 Modules & Options Before installing the application, make sure that the 3.75G/HSPA module is ON  (installing the driver with the module off will not allow the software to detect the module hardware correctly). Use the Fn + key combination (see Table 1 - 2, on 3.75G/HSPA page 1 -...
Page 127: Mobile Partner
Modules & Options Mobile Partner  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the Mobile Partner application. The Mobile Partner Wireless Device application allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
Page 128: Mobile Partner Application
Modules & Options Mobile Partner Application  You will need to contact your service provider to obtain the exact details of how ex- actly to configure the settings on this page. Mobile Partner Help Profile Management To get help on Mobile Partner configuration Power on the 3.75G/HSPA module using the Fn +...
Page 129 Modules & Options Connecting to the Service Provider Power on the 3.75G/HSPA module using the Fn + key combination. Access the Mobile Partner application from the Start menu (Start > Programs/ All Programs > Mobile Partner), or by double-clicking the Mobile Partner icon on the desktop The software will run and you can select the Profile Name from the menu.
Page 130 Modules & Options When the connection is successful you can move the cursor over the network icon in the taskbar to display the connection information. Figure 7 - 12 Connected Taskbar Notification You can then access the internet, download e-mail etc. as per any internet connection.
Page 131 Modules & Options 11. The module will still be on, and you will need to press the Fn + key combination to turn it off. 12. If you click the Mobile Partner close icon a message will be displayed asking you to click OK to confirm the program exit and to terminate the connection.
Page 132: Text Messaging Service
Modules & Options Text Messaging Service In addition to standard internet services you may also send and receive SMS text messages using the Mobile Partner program, if your service supports SMS. Reading SMS Messages An icon will blink at the bottom of the Mobile Partner interface to notify you of any new messages received.
Page 133: Bandluxe Hsdpa Utility
Modules & Options BandLuxe HSDPA Utility  With the 3.75G/HSPA module and USIM card (supplied by your service provider) installed you may then install the BandLuxe HSDPA Utility. The BandLuxe HS- Wireless Device DPA Utility allows you to directly access your HSPA internet service from the com- Operation Aboard puter.
Page 134: Bandluxe Hsdpa - Connection Manager
Modules & Options BandLuxe HSDPA - Connection Manager The connection information is stored on the USIM card supplied by the service pro- vider (where this is not the case you may need to create a profile - see “Creating a Profile”...
Page 135 Modules & Options The system will connect to your network (you may need to set your network connection to home, work or public on the first connection). The connected icon will appear at the top of the utility screen. Figure 7 - 16 Connected You can then access the internet, download e-mail etc.
Page 136 Modules & Options While you are connected the taskbar icon will display the connected icon , and the taskbar will display the connected icon Figure 7 - 18 Taskbar Icon (Connected) To disconnect from the service provider, click the Disconnect icon, or click the close icon at the top right of the utility, and click Yes to confirm.
Page 137: Creating A Profile
Modules & Options Creating a Profile Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu > Profile. Figure 7 - 19 Menu - Profile The default profile will display the service provider’s name from the USIM card.
Page 138 Modules & Options Click New (button) and input any Network Settings required by your service  provider (all fields may not need to be filled in). The profile name is used to identify your profile if a number of profiles are used. Password You will need to check with your service provider to confirm if the User Name and Password are required.
Page 139 Modules & Options Click the newly created profile in the profile window and then click Default (button)  to set the profile as the default connection (note that only one profile may be stored as the default connection). 10. The newly created profile will now be stored as the default connection when you New SIM Card click Connect in the Connection Manager Home screen.
Page 140: Choosing A Profile
Modules & Options Choosing a Profile If you need to switch stored profiles follow the instructions below: Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 > Connection Manager). Click the Menu >...
Page 141: Editing A Profile
Modules & Options Editing a Profile  If you need to edit stored profiles follow the instructions below: Get the Latest Access the Connection Manager from the Start menu (Connection Manager Access Point Name ), or (Start > Programs/All Programs > BandLuxe > BandLuxe Database HSDPA Utility R11 >...
Page 142: Text Messaging Service (Sms)
Modules & Options Text Messaging Service (SMS)  In addition to standard internet services you may also send and receive SMS text messages using the Connection Manager, if your service supports SMS. Incoming Messages Inbox If the program is open The Inbox will contain any received SMS.
Page 143 Modules & Options Sent  The Sent folder contains any successfully sent SMS. Select the message and press the Delete to erase the record. Contact List Types Outbox Select a contact The Outbox folder contains any completed but unsent SMS. Select the message and from the SIM card.
Page 144 Modules & Options Template A template can store text that is used regularly in messages, and can be easily insert- ed in to any new SMS. Click Template (button) to view any stored templates. Click to highlight a template and click Select (button) to insert it into the message. Click New (button) to create a new template, and Save (button) to add it to the existing list.
Page 145: Setting
Modules & Options Setting  The Setting menu allows you to edit the programs basic parameters. Access the Connection Manager from the Start menu (Connection Manager Language ), or (Start > Programs/All Programs > BandLuxe > BandLuxe The Connection Manager HSDPA Utility R11 >...
Page 146 Modules & Options SMS - Preference Click the New SMS Notify checkbox to be automatically notified when a new SMS arrives. If enabled a the incoming message notification will appear in the taskbar, Figure 7 - 29 Incoming SMS Notification and an envelope icon will appear in the upper left corner of the Home screen when a new message arrives.
Page 147 Modules & Options This menu allows you to edit the USIM card Personal Identification Number (PIN) and Enable/Disable the PIN if necessary. Press Apply after making any changes. A SIM card must be inserted for this function to be activated. Figure 7 - 31 Setting - SIM If a PIN code is enabled, the input will be requested during USIM card initialization.
Page 148 Modules & Options Radio Set the appropriate network search options from the dual mode setting menu. Click Apply (button) after making any changes. Figure 7 - 32 Setting - Radio Note: 2G/3G/3.5G data transferring will be disconnected when you apply a new Ra- dio setting.
Page 149 Modules & Options Network - Network Selection  Edit the network selection settings from this menu. The Standard (auto) setting will search for networks in the order specified in the Prefer list. Click Standard (auto) Network Setting > Next to view and adjust the Prefer list. The Prefer list is displayed at the top of the Note that the network set- screen, and the bottom of the screen lists all available networks.
Page 150 Modules & Options The Manual setting allows you to choose a network from all available. Click Man- ual > Next to view the list. Click to highlight a network from the list, and click Se- lect (button) to choose the network, or Cancel (button) to make no change. Figure 7 - 34 Setting - Network Manual...
Page 151: Statistics & Information
Modules & Options Statistics & Information The Statistics screen displays a graph of recent upload and download activity. No data will be displayed if there is no current connection. Access the Connection Manager from the Start menu (Connection Manager ), or (Start > Programs/All Programs > BandLuxe > BandLuxe HSDPA Utility R11 >...
Page 152: Bluetooth Module
Modules & Options Bluetooth Module  There are two Bluetooth module options available for this computer. If your pur- Wireless Device chase option includes the Combination Wireless LAN & V3.0 Bluetooth module Operation Aboard then install the driver as instructed overleaf. Follow the instructions on page 7 - 50 Aircraft to configure the Bluetooth settings.
Page 153: Bluetooth Combo Driver Installation
Modules & Options Bluetooth Combo Driver Installation  Note this driver is required only for the combo Bluetooth and WLAN module only. High Speed Bluetooth 1. Make sure the module is powered on, then insert the Device Drivers & Util- Data Transfer ities + User’s Manual disc into the CD/DVD drive.
Page 154: Bluetooth & Wlan Combo Settings
Modules & Options Bluetooth & WLAN Combo Settings  This information applies to the combo Bluetooth and WLAN module only. Bluetooth Module & Make sure the Bluetooth module is powered on. Resuming From Sleep Double-click the My Bluetooth application on the desktop (or access it from the Mode Programs/All Programs menu).
Page 155 Modules & Options Click General Setings to change the computer name that other Bluetooth devices will see, and click the tickbox to Allow Bluetooth devices to find this computer Click OK to confirm the settings. Figure 7 - 37 General Settings Bluetooth Module 7 - 47...
Page 156 Modules & Options Click File Transfer Setings to Enable sharing of my files with other Bluetooth devices. Click OK to confirm the settings. Figure 7 - 38 File Transfer Settings 7 - 48 Bluetooth Module...
Page 157: Bluetooth Networking Setup
Modules & Options Bluetooth Networking Setup This information applies to the combo Bluetooth and WLAN module only. Make sure the Bluetooth module is powered on. Double-click the My Bluetooth application on the desktop (or access it from the Programs/All Programs menu). Click My Bluetooth Settings (see Figure 7 - 36 on page 7 - 46).
Page 158: Bluetooth & Wlan Combo Module Configuration
Modules & Options Bluetooth & WLAN Combo Module Configuration  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Bluetooth Module & Make the device discoverable (to do this check your device documentation). Resuming From Sleep Mode To Turn the Bluetooth Module On...
Page 159 Modules & Options You will then be presented with a menu of options to select from. Figure 7 - 41 Bluetooth Device Options Click the appropriate button to connect to the device. Bluetooth Module 7 - 51...
Page 160 Modules & Options You may need to allow the connection from your device, and you will then need to provide a passcode from the device. You can then enter the passcode on the computer and click OK to establish the connection.
Page 161: Standard Bluetooth Configuration In Windows 7
Modules & Options Standard Bluetooth Configuration in Windows 7  Setup your Bluetooth Device so the Computer Can Find it Turn your Bluetooth device (e.g. PDA, mobile phone etc.) on. Add a Device Make the device discoverable (to do this check your device documentation). Click Start, and click Con- trol Panel and then click To Turn the Bluetooth Module On...
Page 162 Modules & Options To Add a Bluetooth Device  Access the Bluetooth Devices control panel and click Add a device. Double-click the device you want to pair with the computer. Pairing Options If a device has been pre- viously connected then the pairing option menu will appear when you at- tempt subsequent con-...
Page 163 Modules & Options Enter the code into your Bluetooth enabled device and follow any on-screen instructions to complete the pairing.  Figure 7 - 45 Pairing Codes Pairing Code Example The example outlined here shows a connection to a mobile device. Other devices e.g. computers, may have a slightly different connection proce- dure, and may require you to confirm a pairing code is correct on both devices.
Page 164 Modules & Options To Change Settings for the Bluetooth Device  Click the taskbar icon and select Show Bluetooth Devices. Right-click on the device you want to change and click Properties to: Bluetooth Help • Change the name of the device (click Bluetooth, type a new name and click OK). •...
Page 165: Overview
Troubleshooting Chapter 8: Troubleshooting Overview Should you have any problems with your computer, before consulting your service representative, you may want to try to solve the problem yourself. This chapter lists some common problems and their possible solutions. This can’t anticipate every problem, but you should check here before you panic. If you don’t find the answer in these pages, make sure you have followed the instructions carefully and observed the safety precautions in the preface.
Page 166: Basic Hints And Tips
Troubleshooting Basic Hints and Tips Many of the following may seem obvious but they are often the solution to a problem when your computer ap- pears not to be working. • Power - Is the computer actually plugged into a working electrical outlet? If plugged into a power strip, make sure it is actually working.
Page 167: Backup And General Maintenance
Troubleshooting Backup and General Maintenance • Always backup your important data, and keep copies of your OS and programs safe, but close to hand. Don’t forget to note the serial numbers if you are storing them out of their original cases, e.g. in a CD wal- let.
Page 168: Viruses
Troubleshooting Viruses • Install an Anti-Virus program and keep the definitions file (the file which tells your program which viruses to look for) up to date. New computer viruses are discovered daily, and some of them may seriously harm your computer and cause you to lose data. Anti-Virus programs are commercially available and the defini- tions file updates are usually downloadable directly from the internet.
Page 169: Upgrading And Adding New Hardware/Software
Troubleshooting Upgrading and Adding New Hardware/Software • Do not be tempted to make changes to your Windows Registry unless you are very sure of what you are doing, otherwise you will risk severely damaging your system. • Don’t open your computer or undertake any repair or upgrade work if you are not comfortable with what you are doing.
Page 170 Troubleshooting • Thoroughly check any recent changes you made to your system as these changes may affect one or more system components, or software programs. If possible, go back and undo the change you just made and see if the problem still occurs. •...
Page 171: Problems And Possible Solutions
Troubleshooting Problems and Possible Solutions Problem Possible Cause - Solution You turned on the power but it doesn’t Battery missing / incorrectly installed. Check the battery bay, make sure the work. battery is present and seated properly (the design of the battery only allows it to go in one way).
Page 172: Troubleshooting
Troubleshooting Problem Possible Cause - Solution The computer feels too hot. Make sure the computer is properly ventilated and the Vent/Fan intakes are not blocked. If this doesn’t cool it down, put the system into Hibernate mode or turn it off for an hour. Make sure the computer isn’t sitting on a thermal surface (see “Overheating”...
Page 173 Troubleshooting Problem Possible Cause - Solution You forget the boot password. If you forget the password, you may have to discharge the battery of the CMOS. Contact your service representative for help.  Password Warning If you choose to set a boot password, NEVER forget your password. The consequences of this could be serious. If you cannot remember your boot password you must contact your vendor and you may lose all of the information on your hard disk.
Page 174 Troubleshooting Problem Possible Cause - Solution The system freezes or the screen goes The system’s power saving features have timed-out. Use the AC/DC adapter, dark. press the sleep (Fn + F4) key combination, or press the power button if no LEDs are lit.
Page 175 Troubleshooting Problem Possible Cause - Solution The Wireless LAN indicators The WLAN module is turned off in the Windows Mobility Center. The show that the WLAN module is powered computer’s wireless function keys will not function properly if Wireless is turned on, however the module does not connect.
Page 176: Bluetooth Connection Problems
Troubleshooting Bluetooth Connection Problems If you are experiencing problems connecting to some Bluetooth devices (in particular certain mobile phones and headsets) it maybe necessary to download and install the Windows Mobile Device Center software (for Win- dows Vista and Windows 7). Go to the Microsoft website and search for the Microsoft Windows Device Center Driver for Windows Vista (64-bit or 32-bit) and Windows 7 (64-bit or 32-bit), and then download the driver.
Page 177 Troubleshooting Right-click Bluetooth Peripheral Device and click on Update Driver Software. Click Browse my computer for driver software. Click Let Me pick from a list of device drivers on my computer. Figure 8 - 2 - Browse my computer.../Let me pick from... Select Bluetooth Radios from the list.
Page 178 Troubleshooting 10. A list of drivers will appear with Manufacturer on one side and Model in the other. 11. Choose Microsoft Corporation (make sure you choose the full name Microsoft Corporation and do not choose Microsoft - Note that you must have installed the Microsoft Windows Device Center Driver for Microsoft Corporation to appear in the list).
Page 179 Troubleshooting 15. The Device Manager should now display the Windows Mobile-based device support under Bluetooth Radios. 16. You will need to repeat the process for any other Bluetooth Peripheral Devices listed under Other Devices. Figure 8 - 5 - Device Manager - Bluetooth Radio Bluetooth Connection Problems 8 - 15...
Page 180 Troubleshooting 8 - 16...
Page 181 Interface (Ports & Jacks) Appendix A: Interface (Ports & Jacks) Overview The following chapter will give a quick description of the interface (ports & jacks) which allow your computer to communicate with external devices, connect to the internet etc. Item Description Card Reader Port The card reader allows you to use some of the latest digital storage cards.
Page 182 Interface (Ports & Jacks) Item Description Headphone-Out Jack Headphones or speakers may be connected through this jack. Note: Set your system’s volume to a reduced level before connecting to this jack. Microphone-In Jack Plug an external microphone in to this jack to record on your computer. RJ-45 LAN Jack This port supports LAN (Network) functions.
Page 183: Intel Video Driver Installation
Appendix B: Intel Video Driver Controls  The basic settings for configuring the LCD are outlined in “Video Features” on DVMT Notes page 1 - DVMT is not local video Intel Video Driver Installation memory. Make sure you install all the drivers in the order indicated in Table 4 - 1, on page 4 - DVMT is not user-con- figurable.
Page 184: Intel® Graphics & Media Control Panel
Intel Graphics & Media Control Panel ® Advanced video configuration options are provided by the Intel Graphics and ® Media Control Panel. To access the control panel: Click Advanced settings in the Screen Resolution control panel in Windows. Click the Intel(R)... tab and click Graphics Properties (button). Right-click the desktop and select Graphics Properties from the menu.
Page 185 You may make changes to any of the graphics properties by clicking the appropriate  menu tab on the left of the menu and adjusting the settings on the right. Options & Support Click Options & Sup- port and select an item from the sub-menu to bring up the help and support topics.
Page 186: Display Devices & Options
Display Devices & Options  Besides the built-in LCD you can also use an external monitor/flat panel display/TV connected to the external monitor port or to the HDMI-Out port (High-Definition Function Key Combination Multimedia Interface) as your display device. The table below outlines the display options.
Page 187: Attaching Other Displays
Attaching Other Displays  If you prefer to use a monitor or flat panel display, connect it to the external monitor Multiple Display port or HDMI-Out port on the right of the computer. At least one other dis- To Clone Displays: play must be attached in Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 188 To Enable Extended Desktop:  Attach your display to the external monitor port or HDMI-Out port, and turn it on. Go to the Intel(R) G&M control panel and click Display > Multiple Displays. Display Settings Click Operating Mode and select Extended Desktop from the menu. Extended Desktop Click Apply, and OK to confirm the settings change.
Page 189: Configuring An External Display In Windows 7
Configuring an External Display in Windows 7  You can also use the Screen Resolution control panel in Windows 7 to configure an Function Key external display. Combination Attach your display to the external monitor port or HDMI-Out port, and turn it on. You can use the Fn + Go to the Screen resolution control panel (see “Video Features - Win 7”...
Page 190 You can configure the displays from the Multiple Displays menu. Figure B - 6 Screen Resolution Multiple Display Options (Win 7) • Duplicate these displays - Shows an exact copy of the main display desktop on the other display(s). • Extend these displays - Treats both connected displays as separate devices. •...
Page 191 Using the Windows Logo Key + P Key Combination to Switch Displays You can also use the + P key combination to quickly change display configura- tion and modes (this is particularly useful when attaching a projector) in Windows 7. Attach your display to the external monitor port or HDMI-Out port, and turn it on.
Page 192: Hdmi Audio Configuration
HDMI Audio Configuration HDMI (High-Definition Multimedia Interface) carries both audio and video signals and you will can configure the audio output as per the instructions below when an HDMI enabled device is connected to the HDMI-Out port. Windows Audio Setup for HDMI Connect a device with HDMI support to the HDMI-Out port.
Page 193 Adjust the HDMI settings from the control panel tabs. Click OK to close the Sound control panel. Figure B - 9 HDMI Device Properties HDMI Audio Configuration B - 11...
Page 194 HDMI Notes  • Connect a device with HDMI support to the HDMI-Out port BEFORE attempt- ing to play audio/video sources through the device. Other Applications If you are using a third HDMI Video Configuration party application Connect an HDMI cable from the HDMI-Out port to your external display. play DVDs etc.
Page 195 Specifications Appendix C: Specifications  Latest Specification Information The specifications listed in this Appendix are correct at the time of going to press. Certain items (particularly processor types/ speeds and CD/DVD device types) may be changed, updated or delayed due to the manufacturer's release schedule. Check with your service center for details.
Page 196: Processor
Specifications Processor Memory Storage Intel® Core™ i3-330UM Processor: Dual Channel DDR3 One Changeable 2.5", 9.5 mm (h) HDD with SATA (Serial) Interface (1.20GHz) Two 204 Pin SO-DIMM Sockets Supporting DDRIII (DDR3) *1066MHz/ 32nm (32 Nanometer) Process External Super Multi/Blu-ray Optical 1333MHz Technology, 3MB L3 Cache &...
Page 197: Interface
Specifications Interface Communication Power Management Three USB 2.0 Ports 10/100/1000Mb Base-TX Ethernet LAN Supports Wake on LAN One HDMI-Out Port (High-Definition Supports Wake on USB Intel® WiFi Link 1000 Series (802.11b/g/ Multimedia Interface) Energy Star 5.0 Compliant n) Wireless LAN PCIe interface Half Mini- One External Monitor Port Card Module (Factory Option) Power...
Page 198: Environmental Spec
Specifications Design Feature Magic Of Film Art II Changeable LCD Back Covers (For Model B Computers) Environmental Spec Temperature ° ° Operating: C - 35 Non-Operating: -20°C - 60°C Relative Humidity Operating: 20% - 80% Non-Operating: 10% - 90% Dimensions & Weight Model A: 330mm (w) * 221mm (d) * 25.5mm (h), 1.55 kg...

Clevo S3101 User Manual

Quick Start Guide

Features & Components

Power Management

Drivers & Utilities

Modules & Options

BIOS Utilities

Upgrading the Computer

Troubleshooting

Intel Video Driver Controls

Specifications

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Clevo S3101

Summary of Contents for Clevo S3101

Table of Contents
