  • Page 1 Installationsanleitung Installation Instructions AC-SENSOR FLEX...

  • Page 2: Intended Use

    Operation outside of the specifi ed technical data can damage or destroy the device (see „Technical data“ at the end of this guide). PAGE 18 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...

  • Page 3: Product Description

    Current ratio settings clamps DIP-switches S1, S2, S3 for activation of Reset switch CT-clamp measurement CAN connection MyReserve (RJ45) Grid-side connections House-side connections Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 19...

  • Page 4: Display Elements

    Ensure that the conductors that are connected to the ACS or should be disconnected from it are de-energized. PAGE 20 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 5 Make sure that the pins H (pin 1), L (pin 2) and GROUND (pin 6) are connected to MyRe- serve Command and the AC sensor with the same assignment. pin assignment (any connector) pin assignment DELOCK 86287 RJ45 Stecker Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 21...

  • Page 6: Direct Measurement

    DIP switch settings for S4 (ensure all four switches are ON (to the left)) under the case cover S2 S3 • Close/secure the case cover using the enclosed cable ties. single ACS (1-phase, 3-phase) PAGE 22 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 7 ACS and MyReserve Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 23...
  • Page 8 ACS, MyReserve and EnergyManager PAGE 24 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 9 Connect the ACS according to the relevant wiring diagram (“single ACS”, “ACS and MyReserve”). • Select fuse protection for the power supply cables according to the conductor cross section. single ACS (1-phase) Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 25...
  • Page 10 ACS (3-phase) PAGE 26 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 11 ACS and MyReserve Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 27...
  • Page 12 NOTE The CT clamps must have a secondary current of ≤ 1 A and a minimum output power of 0.2 VA. PAGE 28 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 13 CT clamps and the clamps is status connection of the secondary winding connected in a wrong direction Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 29...

  • Page 14: Technical Data

    Technical data Disposal The ACS must be disposed of in accordance with the locally applicable waste disposal regulations for electronic scrap. PAGE 30 | Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH...
  • Page 15 Version: 07/2020 | Rev. 002 | AZ-TM-PME-1626 | Subject to changes | © 2020 SOLARWATT GmbH | PAGE 31...

  • Page 16: Any Questions

    Typ und Seriennummer des Gerätes, welches die Messwerte vom ACS am CAN-Bus empfängt • möglichst detaillierte Fehlerbeschreibung www.solarwatt.de Any Questions? If you are experiencing technical problems with the product, please use the service hotline. We will need the following information to assist you further: •...
