  • Page 1 Battery vision Inverter vision three 1.0 IMPORTANT: Check whether these instructions are up-to-date. You can find the current version and all language variants under this QR code: Quickstart Guide Schnellstartanleitung Guide de démarrage rapide Guida rapida Snelstartgids Guía rápida de instalación...
  • Page 2 Per istruzioni dettagliate sull‘installazione e l‘uso, scansionare il codice QR qui sotto. Scan de QR-code hieronder voor gedetailleerde installatie en gebruiksinstructies. Para obtener instrucciones detalladas de instalación y funcionamiento, escanee el siguiente código QR. Subject to change | Solarwatt GmbH...
  • Page 3 SYSTEM DESIGN Subject to change | Solarwatt GmbH...
  • Page 4 DEVICE DESIGNS AND PACKING LISTS Battery vision top pack 1.0 (2.6 kWh) View from the left side B-Start Switch Power Switch power B-start Bracket mounting hole BMS Status LED SoC LEDs Battery fixing hole Status LED DC Switch View from the right side...
  • Page 5 • DC- and AC-cable for inverter S move up; increase value • LAN cable for inverter (optional) T move down; decrease value • grounding cable for inverter U confirm • circuit breaker V return/exit Subject to change | Solarwatt GmbH...
  • Page 6 Minimum installation space Installation height (without footstands) (min. working area in front: 1,200) max. 63 (view from above) min. 48 max. 63 Installation width, depth distance to the wall: 38 mm Flexible distance to the floor Subject to change | Solarwatt GmbH...
  • Page 7 DIMENSIONS INVERTER VISION ONE [MM] 228 mm 630 mm 1,5 m Battery connection distance standard cable length: to battery 1,5 m Minimum installation space (min. working area in front: 1,200) Subject to change | Solarwatt GmbH...
  • Page 8 (footstands are provided in the box of the top pack) Fix top pack first with fixing bracket (2) Stack packs, stack top pack last then fix packs with screws (1) Connect grounding cable (5) Subject to change | Solarwatt GmbH...
  • Page 9 Connect ground terminal via cable lug (19) Screw in the antenna (18) METER INSTALLATION AND WIRING Install the meter (20) on the household cabinets‘s top hat rail connect meter acc. to wiring diagram p. 3 Subject to change | Solarwatt GmbH...
  • Page 10 BMS - Inverter (1,5 m) 14 AC connector Cable requirements: 6 DC cable battery (1,5 m) 12 PV connectors 4 -6 mm² MC4, Stäubli (MC4 Stäubli) 4.0 - 16.0 mm² Network: Standard LAN cable Subject to change | Solarwatt GmbH...
  • Page 11 INVERTER ASSEMBLY AND WIRING detail 1 detail 2 Inverter interfaces Battery 24 25 PIN meter PIN RJ 45 plug for the inverter Connect Battery (6, 4) Connect meter (16) Subject to change | Solarwatt GmbH...
  • Page 12 Fix the lock nut. Plug the AC cable into the BACKUP/GRID port, Reposition the safety clip. Fix the safety clip. Subject to change | Solarwatt GmbH...
  • Page 13 START Turn battery DC switch (top pack) ON B-start You do not need an inverter password for the initial installation. For subsequent settings, the password is 0000. Press battery POWER button (top pack) Subject to change | Solarwatt GmbH...
  • Page 14 • Set maximum charging current (A) • Setup load management (in preparation) Download Pro app and login with your Pro Find and install the inverter via Pro app for account using the following features Subject to change | Solarwatt GmbH...
  • Page 15 Press battery POWER button (top pack) • select STOP B-start Turn off • AC breaker Grid Turn battery DC switch (top pack) OFF • AC breaker Backup (if locally required) DC SWITCH Turn inverter DC switch OFF Subject to change | Solarwatt GmbH...
  • Page 16 +33 (0) 4 69 85 17 70 15 Chemin du Saquin info.france@solarwatt.com 69130 Ecully solarwatt.fr Se avete domande, non esitate a contattarci. Solarwatt Italia S.R.L. | Viale della info.italy@solarwatt.com Navigazione Interna n°52 solarwatt.it 35129 Padova Hebt u vragen? Neem gerust contact met ons op.
