  • Page 1 Installationsanleitung Installation Instructions MYRESERVE BACKUP POWER...

  • Page 2: About This Guide

    © SOLARWATT GmbH 2019 system or through any acts of unqualified or non- SOLARWATT-certified electricians. This li- PAGE 18 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...
  • Page 3 (e.g. large consumers, which would exceed detailed planning of the system is required. SWITCH PV-module MyReserve consumers Fronius Symo Hybrid DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 19...

  • Page 4: Prohibited Use

    By applying mains voltage to the CAN bus terminals or an operation outside of the specifi ed technical data (see Chapter 13) the SwitchBox may be damaged or destro- yed. PAGE 20 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...

  • Page 5: System Components

    M12/M20 Membrane (pressure equalization) 8 M25 with sealing insert - CAN MyReserve M32/M40 - X2 House M32/M40 - X3 Backup M32 - x4 Inverter DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 21...
  • Page 6 • Socket for UPS • Mounting material Mounting the SwitchBox • Mount the SwitchBox to the wall with suitable fastening material PAGE 22 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...
  • Page 7 Fronius Symo Hybrid Manager (= inverter communication terminal) - terminal -X6 • • if available: connection to the EnergyManager - terminal X7 DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 23...
  • Page 8 The power socket of the UPS marked red in the figure is not supplied during a power failure. Therefore, use one of the other socket slots for connection with the MyReserve Command. PAGE 24 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...
  • Page 9 • Activate the backup power function on the inverter display (see fi gure) • Conduct technician wizard according to the Fronius Symo Hybrid Installation guide Excerpt from installation instructions Fronius Symo Hybrid DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 25...
  • Page 10 • Connect to the inverter (Fronius system monitoring) • Select menu item settings PAGE 26 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...
  • Page 11 (after that, you will be asked for the service password which was set in the technician wizard) • Make backup power settings as shown below DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 27...
  • Page 12 • Select settings under the menu item plant overview • Carry out the confi guration according to the following fi gure PAGE 28 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...

  • Page 13: Possible Errors

    Installation and operating instructions MyReserve (min. Rev 006) • Installation instructions Fronius Symo Hybrid • Operating instructions Fronius Symo Hybrid • Installation Instructions MyReserve SwitchBox (by enwitec) DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 29...

  • Page 14: Technical Data

    338 x 622 x 161 mm Weight ca 11 kg Max. fuse size max. 63 A IP rating IP65 Grid types TN(C)-S/TN-S/TT-Netze PAGE 30 | Version: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH...
  • Page 15 Disposal The switchbox and all its components must be disposed in accordance with local regulations for the disposal of electronic scrap. DATE: 07/2019 | Rev. 000 | AZ-TM-PME-1693 | Subject to changes | © 2019 SOLARWATT GmbH | PAGE 31...
  • Page 16 MYRESERVE CERTIFIED SAFETY. HIGHEST EFFICIENCY. GUARANTEED PERFORMANCE. Do you have any questions? Your customer advisor or our technical support will be happy to help you. SOLARWATT GmbH | Maria-Reiche-Str. 2a | 01109 Dresden | Germany Tel. +49 351 8895-333 www.solarwatt.com...
