SKYDANCE R9 Manual

Ultrathin RF Remote Controller
Model No.: R9
1 zone RGB or RGBW/27 key/Wireless remote 30m distance/CR2032 batter y
Features
● Apply to RGB or RGBW LED controller.
● Each remote can match one or more receiver.
● C 2032 atter y powered. R b
● Operate with LED indicator light.
Technical Parameters
Input and Output
Output signal RF 2.4GHz ( )
Working voltage 3VDC CR2032
( )
Working current ＜5mA
Standby current ＜2μA
Standby time 2 year
Remote distance 30m(Barrier-free space)
Environment
O O
Operation temperature Ta: -30 C ~ +55 C
IP rating
IP20
User Manual Ver 1.1.1
LVD RED
Safety and EMC
EMC standard (EMC) EN301 489,EN 62479
Safety standard(LVD)
EN60950
Radio Equipment(RED)
EN300 328
Certification CE,EMC,LVD,RED
Warranty
5 years
Warranty
Weight
Net weight 0 . 034k g
Gross weight
0 . 058k g
Key function
Pull out the plastic battery barrier sheet from the battery compartment located on the bottom of the remote
before key operation.
Speed+
Speed-
Mode+
Mode-
R/G/B /- +
"1"/Red， "6"/Cyan
"2"/Green， "7"/Orange
"3"/Blue， "8"/Grape
"4"/Yellow， "9"/Grass green
"5"/Purple， "0"/Natural white
Mode+/-: Short press switch dynamic mode built in controller
long press 2s Mode+ run mode cycle, long press 2s Mode- run the first mode.
Speed+/-: Adjust dynamic mode speed,
short press 10 levels, long press 2s get the fastest / slowest speed.
Bright+/-: Adjust brightness,
short press 10 levels, long press 1-6s for continuous 256 levels adjustment.
R/G/B+/ : Adjust R/G/B brightness respectively, -
short press 10 levels, long press 1-6s for continuous 256 levels adjustment to achieve millions of colors.
White: Adjust white color,
For RGB light, short press turn on/off white(RGB mix),
long press 1-6s adjust saturation continuously.
For RGBW light, press W key will adjust W channel brightness.
short press turn on/off W channel,
long press 1-6s adjust W channel brightness continuously.
Scene: Short press recall the scene, long press 2s save
the LED indicator will light up longer when save OK.
R9 Ultrathin RF Remote Controller
Bright+
Bright-
On/Off
Scene
White
Special function key
,
the current color into the scene .
Page 1
