Installation and connection

Installation and connection
To ensure proper operation, connect
the appliance to the power and water
supply correctly. Observe the specified
criteria and the installation instructions.

Scope of supply

After unpacking all parts, check for any
damage in transit and completeness of
the delivery.
If you have any complaints, contact IKEA
or our Customer Service.
Note: The appliance was tested at the
factory to check it is in working order. It
is possible that water has left marks on
the appliance. These marks will disap-
pear after the first wash cycle.
The delivery consists of the following:
Dishwasher
●
Operating instructions
●
Installation Instructions
●
Installation material
●
Steam guard plate
●
Mains cable
●
Quick reference guide
●
Installing and connecting the
appliance
You can position your built-under or in-
tegrable appliance in a fitted kitchen
between wooden and plastic walls. If
you subsequently install your dish-
washer as a free-standing appliance,
you must stop it from tipping over, e.g.
by screwing it to the wall or installing it
under a continuous worktop that is se-
curely connected to adjacent cabinets.
Follow the safety instructions.
1.
→ Page 5
Follow the instructions for electrical
2.
connection. → Page 15
Check the Scope of supply and the
3.
condition of the appliance.
Consult the installation instructions
4.
for the installation dimensions re-
quired.
Make the appliance level using the
5.
height-adjustable feet.
Make sure that the appliance is
standing on the floor securely.
Install the drainage connection.
6.
→ Page 14
Install the drinking water connection.
7.
→ Page 15
Connect the appliance to the power
8.
supply.

Drainage connection

Connect your appliance to drainage
connection so dirty water is discharged
via the wash cycle.
Installing the drainage
connection
Consult the installation instructions
1.
supplied for the steps required here.
Connect the wastewater hose to the
2.
outlet connection of the siphon using
the enclosed parts.
When doing so, check that the
3.
wastewater hose is not kinked,
crushed or twisted.
Also check that there is no cover in
4.
the drainage system preventing the
wastewater from being discharged.
14
