Quantum Q-LOGIC 3e Manual page 20

20 BASIC OPERATION INSTRUCTIONS
Seat Icons continuted
Item Icon Name
S11 N/A
S12 N/A
Auxillary Functions
Item Icon Name
M2 Settings
M3 Select
M4 Previous
M5 Next
M6 Change plus
M7 Change
minus
M8 Brightness
M9 Beep
M10 Horn
M11 BT Main
Menu
Icon Visual
Icon Visual
Settings menu icon, selected with forward input. Left or right input
lead to Bluetooth or information menu icon. Shown as well: Select/
Next/Previous
Select menu item. Highlighted if activated by input device forward
input.
Navigates through menu and settings items. Highlighted if activated
by input devices right input (all).
Navigates through menu and settings items. Highlighted if activated
by input device right input (all).
Highlighted if activated by input device forward input.
Highlighted if activated by input device reverse input.
Large brightness change icon. Shown as well: Next/Previous/
Change plus/minus
Large beep volume change icon. Shown as well: Next/Previous/
Change plus/minus
Large horn volume change icon. Shown as well; Next/Previous/
Change Plus/minus.
Main Bluetooth, press up to enable.
Comments
Seat right leg up. Seat left leg up remains in place
Seat right leg down. Seat left leg remains in place..
Comments
