Quantum Q-LOGIC 3e Manual page 19

Seat
Seat Icons
Item Icon Name
S1 Main Seat Tilt
Forward
S2 Main Seat Tilt
Backward
S3 Main Seat
Recline
Forward
S4 Main Seat
Recline
Backward
S5 Main Seat
elevate up
S6 Main Seat
elevate down
S7 Main Seat
AFP, Legs out
S8 Main Seat,
AFP, Legs in
S9 Main Seat
Legs up
S10 Main Seat
Legs down
Seatback
Seating
Rear (legs)
Feet (legs)
Icon Visual
Seating and seatback icon, both highlighted.
forward highlighted.
Seating and seatback icon, both highlighted.
backward highlighted.
Seatback icon highlighted. Direction arrows, forward highlighted.
Seatback icon highlighted. Direction arrows, backward highlighted.
Seating highlighted. Direction arrows, up highlighted.
Seating highlighted. Direction arrows, down highlighted.
Used, if both legs operate at the same time:
-AFP
-Legs
-Left leg & right leg combined
Foot platform, consisting of 2 elements (1 rear, 1 feet), both
highlighted. Arrows, forward highlighted.
Used, if both legs operate at the same time:
-AFP
-Legs
-Left leg & right leg combined
Foot platform, consisting of 2 elements (1 rear, 1 feet), both
highlighted. Arrows, forward highlighted.
Consisting of 2 elements (1 rear, 1 feet) feet highlighted. Left side
chair view. Arrows, reverse highlighted (same placement as 4.1)
Consisting of 2 elements (1 rear, 1 feet) feet highlighted. Left side
chair view. Arrows, reverse highlighted (same placement as 4.2)
BASIC OPERATION INSTRUCTIONS
Comments
Direction arrows,
Direction arrows,
