multitronic
881/881GL/ServoAccess
Installation, operation and maintenance instructions
Please note the additional
information:
Installation instructions for panic
and emergency exit door locks
MBW10.
Declaration of
performance
881/881GL
7V08 / DIN 18251-3, Class 3
Type 3+11
www.fuhr.de
www.fuhr.de

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the multitronic 881 and is the answer not in the manual?

Questions and answers

Related Manuals for FUHR multitronic 881

Summary of Contents for FUHR multitronic 881

  • Page 1 WWW.FUHR.DE multitronic 881/881GL/ServoAccess Installation, operation and maintenance instructions Please note the additional information: Installation instructions for panic and emergency exit door locks MBW10. Declaration of performance 881/881GL 7V08 / DIN 18251-3, Class 3 Type 3+11 www.fuhr.de www.fuhr.de...

  • Page 2: Table Of Contents

    6.1 THE Control unit 6.2 The radio receiver 6.3 The drive unit’s multi-functional jack 7 Wiring diagram 8 Control via FUHR radio access control systems 8.1 The programming keys 8.2 Tuning in and deleting user radio keys 9 Maintenance and care 9.1 Contact device...

  • Page 3: Introduction

    • By using the FZG free-running profile cylinder’s key (depending on the drive-gear position; 4 turns) • Optionally by means of a FUHR radio access system e.g. transponder, finger print scanner or similar access control systems Unlocking (opening) from the inside: •...

  • Page 4: Important Information/Safety Instructions

    It is therefore imperative that the profile-related routing drawing provided with the FUHR multitronic set is adhered to. Please contact your sales partner or the manufacturer in the event of discrepancies or queries.

  • Page 5: Basic Components | Setting Possibilities

    Adjustment of one-piece/ Latch conversion standard strike plates SW 4 90° SW 2 Contact magnet SW 4 Standard One-piece multitronic 881 strike plate strike plates type 11 type 4/10/11 type 4/10/11 WWW.FUHR.DE...

  • Page 6: Certifications | Labelling Of The Locks

    WARNING! Please note at all costs! The CE-conformity according to DIN EN 1125 or DIN EN 179 is only given, when the FUHR panic locks 881/881GL / ServoAccess are installed with the tested and certificated components. Further information can be found on our website www.fuhr.de.
  • Page 7 881/881GL/ServoAccess Further certifications/tests: Certified in accordance with DIN 18251-3. Tested in accordance with EN 14846. Certified in accordance with QM342. Under testing WWW.FUHR.DE...

  • Page 8: Scope Of Supply Of A Multitronic-Set

    The components shown here do not necessarily correspond to the scope of supply of your door. What the delivery contents really include depends on the respective version. Multipoint locking system multitronic 881 One-piece keep or individual keeps incl. electromotive drive unit Profile related version, incl.
  • Page 9 3-channel radio key as remote control, 2 m. cover plate 1 pc. with red buttons = master key 6 pcs. double cable guides 2 pcs. with turquoise buttons 2 pcs. end caps Profile-related routing drawing Cable protection sleeves 3 pcs. WWW.FUHR.DE...

  • Page 10: Installation Examples

    • Connects up to external indicator LED Art. no. VNZ80067 System components: Multipoint locking system Profile related Concealed or surface-mounted cable junction FUHR multitronic 881/ 881 one-piece keep + Art. no. VNZ80090/VNZ80089 GL /ServoAccess magnetic contact for the drive unit incl.
  • Page 11 Opening impulse from two-way intercom system or access control system: a) Potential-free impulse: yellow cable / green cable b) Energised impuls (6-12 V AC o. 6-24 V DC): yellow cable on / red cable on The white cable has no function in this installation version. WWW.FUHR.DE...

  • Page 12: Version 2 - Standard - With Tappet Contact/Without Control Unit

    • Connects up to external indicator LED Art. no. VNZ80067 System components: Multipoint locking system Profile related Profile related tappet contacts FUHR multitronic 881/ 881 one-piece keep + Cable connector (length 4000 mm) with GL /ServoAccess magnetic contact preassembled multi-functional jack for the drive unit incl.
  • Page 13 • in case of an electrical impulse: to terminal 7 to be connected to the white cable. Note the connector pin assignment on the drive unit! *The DC power supply can also be operated with an AC opening impulse. WWW.FUHR.DE...

  • Page 14: Version 3 - Standard - With Tappet Contact And Switching Power Supply Unit On The Frame/ Without Control Unit

    • Connects up to external indicator LED Art. no. VNZ80067 System components: Multipoint locking system Profile related Profile related tappet contacts FUHR multitronic 881/881 one-piece keep + Cable connector (length 4000 mm) with GL /ServoAccess magnetic contact preassembled multi-functional jack for the drive unit incl.
  • Page 15 1 to: • auf in case of potential-free impulse: to terminal 4 Power supply unit • in case of an electrical impulse: to terminal 7 WWW.FUHR.DE...

  • Page 16: Version 4 - Standard - All-Inclusive For Installation In The Door

    881/881GL/ServoAccess VERSION 4 – STANDARD – ALL-INCLUSIVE FOR INSTALLATION IN THE DOOR Functions: • Opens via FUHR radio-controlled access control modules • Connects up to a swing door opener such as radio key, fingerprint scanner or transponder • Connects up to time switches (permanently-open function) •...
  • Page 17 881/881GL/ServoAccess Principle of connection WWW.FUHR.DE...

  • Page 18: Version 5 - Project - All-Inclusive With Din Rail Components

    881/881GL/ServoAccess VERSION 5 – PROJECT – ALL-INCLUSIVE WITH DIN RAIL COMPONENTS Functions: • Opens via FUHR radio-controlled access control modules • Connects up to a swing door opener such as radio key, fingerprint scanner or transponder • Connects up to time switches (permanently-open function) •...
  • Page 19 881/881GL/ServoAccess Principle of connection WWW.FUHR.DE...

  • Page 20: Version 6 - Project - All-Inclusive With Control Box

    881/881GL/ServoAccess VERSION 6 – PROJECT – ALL-INCLUSIVE WITH CONTROL BOX Functions: • Opens via FUHR radio-controlled access control modules • Connects up to a swing door opener such as radio key, fingerprint scanner or transponder • Connects up to time switches (permanently-open function) •...
  • Page 21 881/881GL/ServoAccess Principle of connection Junction box with 4 cable feeds, dimensions: H200xB112xT94 881-control unit‘s circuit board with radio receiver Rail-mounted mains adapter Input voltage 100 - 240 VAC Output voltage 12 VDC Voltage regulator 10.8-13.8 VDC black white WWW.FUHR.DE...

  • Page 22: Installation Instructions

    881/881GL/ServoAccess Installation instructions ROUTING AND DRILLING OPERATIONS The routings for the FUHR multipoint locking system multitronic 881 are carried out in accordance with the routing drawing provided. In addition to the conventional routings for FUHR multipoint locking systems, for example on multisafe 855, only 2 additional routings in the door leaf and the door frame are required.
  • Page 23 The cable-laying for version A is described in the follow- ing installation steps. 4.1.2 ROUTING FOR THE ELECTRONIC DRIVE UNIT IN THE DOOR LEAF Routing in compliance with the separate routing drawing between the main lock and the bottom additional locking point. WWW.FUHR.DE...
  • Page 24 Drilling in the frame profile, laterally at the same height as the tappet contact device Care must be taken to ensure that the sur- face-contact device and the tappet contact device are aligned accurately horizontally. Refer to chapter 4.1.3. ø12 mm WWW.FUHR.DE...
  • Page 25 4.1.6 ROUTING FOR THE SWITCHING POWER SUPPLY UNIT IN THE DOOR FRAME ON THE INSTALLATION VERSIONS 3 AND 4 Routing on the hinge side of the frame profile Deburr the through-hole & insert the rubber protective nozzle! Exemplary routing. Please ask for the parti- cular profile-related routing dimensions. WWW.FUHR.DE...
  • Page 26 It is imperative that all screws are hand-tightened (maximum torque 1 Nm), as some components are made of PVC and may be damaged by the excessive force that a cordless screwdriver can exert. It is essential that the surface-contact device and the tappet contact device are aligned accurately. WWW.FUHR.DE...

  • Page 27: Installation

    The installation requires exceptional care. This applies particularly to the electronic components, as routing and drilling swarf, abrasion points, defective cables and damaged contacts etc. can lead to the device malfunctioning. Avoid positioning fixing materials (e.g. frame-fixing screws) in areas where electronic components are located! WWW.FUHR.DE...
  • Page 28 4.2.2 INSTALLATION OF THE TAPPET CONTACTS DIN right DIN left The electricity and data transfer control unit of the FUHR autotronic can be used for left handed as well as right handed doors. On right handed doors the tappet contact device is installed as supplied.
  • Page 29 3. Insert the cable and FUHR autotronic 834 multipoint locking system into the routed recess. Leave a spare cable loop below the green drive unit’s coupler in the profile in order to be able to remove the lock at a later stage.
  • Page 30 4. Crop and screw-fix the cover plate according to the door width or height. Ensure that the screws are screw-fixed through the cable guides’ elongated holes. Non-compliance can lead to damaged cables. 5. Put on the end caps and screw-fix through the cable guides. WWW.FUHR.DE...
  • Page 31 In order to ensure proper contact and durable operation, the contact surface has been pre-treated with contact lubricant. Please do not remove this lubricant film! DIN right = bottom Adhere regular maintenance DIN left instructions in compliance with chapter 9.1. WWW.FUHR.DE...
  • Page 32 Please ensure that the cables are neither kinked, trapped nor damaged by sharp profile edges. 5. Screw-fix the control unit casing into the frame profile. Ensure that the cables are not damaged when screw-fixing. 6. Replace the control unit casing’s cover cap. click CLICK WWW.FUHR.DE...
  • Page 33 4.2.8 INSTALLATION OF THE SWITCHING POWER SUPPLY UNIT (TRANSFORMER) IN THE DOOR FRAME The FUHR multitronic’s switching power supply unit can be used for left handed as well as right handed doors. On right handed doors the switching power supply unit is installed as supplied.

  • Page 34: Commissioning

    In the event of any problems arising, please proceed in accor- dance with chapter 11. 6. If the FUHR multitronic lock is fully operational, the two- pin earthed plug can be removed and the door can be despatched.

  • Page 35: External Connection Options

    External connection options The FUHR multitronic control unit is equipped with a multitude of input and output sockets to connect additional compon- ents such as e.g. transponder, eye scan, finger print, code locks, electrical swing door opener, alarm systems, facility manage- ment systems etc.

  • Page 36: The Control Unit

    • Cable connected – via an external or optional available switch (see chapter 6.1.1) • Wireless via radio signal – via a radio key or with another FUHR access control system (see chapter 6.1.2) A combined application of both variants is not recommended, or should only be carried out by qualified personnel and checked beforehand on the basis of individual customer requirements.
  • Page 37 Opening with day latch function If a continuous signal is applied to this input (e.g. activated via a time switch) the FUHR multitronic lock will open. Upon opening the door leaf or after 5 seconds, only the lock’s latch protrudes. All bolts remain with- drawn as long as the continuous signal is applied.
  • Page 38 6.1.4 WIRELESS CONTROL OF THE PERMANENTLY-OPEN FUNCTION VIA RADIO SIGNAL | TUNING IN A RADIO KEY Instead of the radio key VNZ80293 shown here as an example, any other FUHR radio access control system can be taught in for activation.
  • Page 39 20 sec. 5. If you want to activate or deactivate the day-latch function, press the send button on the radio key once. » When the day-latch function is activated, the red and green LED of the control unit flash slowly. WWW.FUHR.DE...
  • Page 40 11 + 12 for function 2. Connect the access control system with potential-free impulse ( ≤ 1 sec.) to terminals 9 + 10 for function 1. Con- nect the swing door opener to terminals 3 + 4. WWW.FUHR.DE...

  • Page 41: The Radio Receiver

    It has a transparent programming button with red control LED (2) for pairing the FUHR radio transmitters and a 3-wire connection cable (3), which is connected to the green plug of the motor drive.

  • Page 42: The Drive Unit's Multi-Functional Jack

    B y means of either the access control system’s control  unit or by pressing a switch, a brief potential-free con- tact triggers opening the FUHR multitronic lock. Input – energised impulse (< 1 sec.) – e.g. for code locks 5 + 7 or transponder systems, that are mounted directly on the door leaf.

  • Page 43: Wiring Diagram

    881/881GL/ServoAccess Wiring diagram Power supply via FUHR switching power supply unit min. 12 V DC (residual ripple < 250 mVpp) Mains (230 V AC) Main control unit Electrical swing door opener (AC/DC) Alarm output (opens if dry reed contact is open)

  • Page 44: Control Via Fuhr Radio Access Control Systems

    With the help of the master radio key, 25 user radio control keys or any other FUHR access system can be tuned in. All radio keys are copy protected by means of a ‘rolling code system’. The middle button of the master key has alrea- dy been programmed to the control unit or the radio receiver module in the factory.

  • Page 45: Tuning In And Deleting User Radio Keys

    » If the new radio key has been accepted by the control unit or the radio receiver module, the green LED (controller) lights up for 1 second and the red LED (radio receiver module) for 4 seconds. 4. Repeat from step 1, should you wish to tune in another radio key. WWW.FUHR.DE...
  • Page 46 The deleteprocess is aborted if the 20 second time limit is exceeded. » If the transmission code has been successfully deleted, the green LED lights up for 1 second and then goes out. 4. Repeat from step 1, should you wish to delete another radio key. WWW.FUHR.DE...
  • Page 47 LED (control unit) lights up for 1 s and the red LED (radio receiver module) lights up for 4 seconds. Note: If the master key is not recognised during the tuning-in and delete processes, the respective function is aborted. WWW.FUHR.DE...

  • Page 48: Maintenance And Care

    The further points raised here provide supplementary information to the FUHR Product Liability Infor- mation for door locks, see www.fuhr.de. The importance of their compliance must be pointed out to builders and users alike. In the event of non-compliance with these imperative instructions, faultless system operation cannot be warranted.

  • Page 49: Contact Device

    Lubricants from other sup- pliers are not suitable and therefore inad- missible. (The contact lubricant can be reordered under Art. no. VNZ80077.) WWW.FUHR.DE...

  • Page 50: Battery Change Of The Radio Keys

    1. Carefully open the radio key housing with a coin (3-channel radio key) or a narrow object, e.g. a slotted screwdriver (4-channel radio key). 2. Push out the battery. 3. New battery (type: CR 2032). The plus symbol must point upwards. 4. Press the radio key housing together again. WWW.FUHR.DE...

  • Page 51: Technical Data

    Security: Rolling code Channels: Power supply: 1 x 3 V battery, CR 2032 Operating control: Red light emitting diode (LED) Temperature range: -10°C to +50°C Dimensions without wall bracket: 60 x 38 x 14 mm Weight: Approx. 25 g WWW.FUHR.DE...

  • Page 52: Multitronic Control With Radio Receiver

    50 x 206 x 15.5 mm Weight: Approx. 500 g. (only electrical locking unit) Power supply: 12 V DC Signalling: 1 piezo buzzer Temperature range: -10 °C to +50 °C Relay contact load capacity: 60 V DC/1 A/30 W WWW.FUHR.DE...

  • Page 53: Multitronic Switching Power Supply Unit (Installation In The Door Frame)

    Max. 2 % Current limiting: Refer to the characteristic line in the diagram Efficiency: Type 79 % Connections: 300 mm x 0.75 mm Dimension: 230 x 25 (29) x 35 mm Weight: Approx. 350 g. (including cable) U/I characteristic line: WWW.FUHR.DE...

  • Page 54: Troubleshooting

    881/881GL/ServoAccess 11 Troubleshooting In the event that your FUHR multitronic lock should fail to function properly, please refer to the table below to find and rectify the fault. IMPORTANT! The entire FUHR multitronic lock has been subject to extensive inspections by the manu- facturer.

  • Page 55: Use With The Radio Receiver Module

    However, if the LED does not light up despite the trans- mission of an opening signal, the radio receiver or the motor lock has not yet been connected to the operating voltage of 12 V DC or the cables on the motor plug have been connected incorrectly. WWW.FUHR.DE...

  • Page 56: Optional Accessories

    881/881GL/ServoAccess 12 Optional accessories Further accessories you will find on www.fuhr.de. 12.5 SmartConnect easy 12.1 Radio fingerprint scan- ner multiscan go Convenient door opening and mo- Biometric system for con ve nient, nitoring via smartphone. Intelligent keyless access control. With 2 access control system via WLAN.
  • Page 57 12.13 Built-in transmitter for intercom systems For installation in intercom systems. Sends a signal to open the door when powered with a voltage between 5-24 V AC or 6-32 V DC. With pre- assembled connection cable. Art. no. VNZ80123 WWW.FUHR.DE...
  • Page 58 881/881GL/ServoAccess CARL FUHR GmbH & Co. KG Carl-Fuhr-Straße 12 D-42579 Heiligenhaus Tel.: +49 2056 592-0 Fax: +49 2056 592-384 www.fuhr.de · info@fuhr.de...

This manual is also suitable for:

Multitronic 881glMultitronic servoaccess
